Ubiquiti Networks US-8-5 Ethernet Switch

Part Number: US-8-5
Model: UniFi Switch 8
Add to My Shopping List Add to Compare
$524.45
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Network Ports
8
Uplink Port
No
Modular
No
Stack Port
No

Product Description:

  Ubiquiti UniFi US-8-5 Ethernet Switch - 8 Ports - Manageable - Twisted Pair - Desktop - 1 Year Limited Warranty.
Explore all Ubiquiti Networks UniFi Switch 8 Ethernet Switches
Add to Quote
Ubiquiti Networks US-8-5 Ethernet Switch
Ubiquiti Networks US-8-5 Ethernet Switch
Ubiquiti Networks US-8-5 Ethernet Switch
Ubiquiti Networks US-8-5 Ethernet Switch Ubiquiti Networks US-8-5 Ethernet Switch Ubiquiti Networks US-8-5 Ethernet Switch
Full specifications (PDF)

Ubiquiti Networks UniFi Switch 8 Ethernet Switch Model Overview

Experience seamless connectivity with the Ubiquiti UniFi Switch 8, a robust 8-port managed gigabit switch designed for enterprise networks. Its compact design houses Gigabit Ethernet ports that ensure high-speed throughput of up to 8 Gbps, making it perfect for critical data transfer needs. Power over Ethernet (PoE) capabilities make it an ideal solution for powering devices like access points and cameras directly through the Ethernet cable. Easily manage your network with the intuitive UniFi Controller, giving you comprehensive oversight and configuration options.


Key features:

  • 8 Gigabit RJ45 Ports for high-speed network performance.
  • Non-Blocking Throughput of 8 Gbps
  • PoE Passthrough Port for powering devices.
  • Managed Capabilities via the UniFi Controller software.
  • Supports multi-site management for easier network oversight.

Specifications:

  • Model: US-8
  • Weight: 432 g (15.24 oz)
  • Dimensions: 148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21")
  • Total Non-Blocking Throughput: 8 Gbps
  • Switching Capacity: 16 Gbps
  • Forwarding Rate: 11.9 Mpps
  • Power Consumption: 12W (excluding PoE output)
  • PoE Ports: 4 ports supporting IEEE 802.3af/at
  • Operating Temperature: -5 to 45°C (23 to 113°F)
  • Certifications: CE, FCC, IC
Ubiquiti Networks US-8-5 Ethernet Switch Overview
Build and expand your network with Ubiquiti Networks® UniFi® Switch, part of the UniFi line of products. The new 8-port models feature Gigabit Ethernet ports in a compact form factor. The switches are fully manageable, delivering robust performance and intelligent switching
for your networks.

Switching Performance

The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps with a switching capacity of 16 Gbps.

PoE

The US-8 can be powered by 802.3af/at, 48V passive PoE, or the included power adapter. When the US-8 is powered by 802.3at PoE or the included power supply, port 8 supports 48V (2-pair) PoE passthrough to deliver up to 12W of power.
Full specifications (PDF)
Interfaces/Ports
Total Number of Network Ports:
8
Uplink Port:
No
Modular:
No
Stack Port:
No
Port/Expansion Slot Details:
8 x Gigabit Ethernet Network
Media & Performance
Media Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
10/100/1000Base-T
Management & Protocols
Manageable:
Yes
Power Description
Power Source:
Power Adapter
Redundant Power Supply Supported:
No
Physical Characteristics
Form Factor:
Desktop
Height:
1.2"
Width:
5.8"
Depth:
3.9"
Weight (Approximate):
15.24 oz
Miscellaneous
Country of Origin:
China
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0695975485985, 0817882020411, 0818214493576, 7111195638947
UPC: 033570574237, 695975485985, 817882020411, 818214493576
EAN: 0695975485985, 0817882020411, 0818214493576, 7111195638947
UNSPSC: 43222612

Recommended Accessories

Category

  • Data Networking Device Accessories (40)
  • Network Antennas (1)
  • Network Transceivers & SFP Modules (1)
  • PoE Injectors (10)
  • Ubiquiti Networks Wireless and Data Networking Products (40)

Recommended Accessories for Model: Ubiquiti Networks US-8-5 Ethernet Switch

Top Data Networking Device Accessories Purchased With Ubiquiti Networks US-8-5

See All Data Networking Device Accessories for Ubiquiti Networks US-8-5 Ethernet Switch >

Top Network Antennas Purchased With Ubiquiti Networks US-8-5

Top Network Transceivers & SFP Modules Purchased With Ubiquiti Networks US-8-5

Top PoE Injectors Purchased With Ubiquiti Networks US-8-5

See All PoE Injectors for Ubiquiti Networks US-8-5 Ethernet Switch >

Top Ubiquiti Networks Wireless and Data Networking Products Purchased With Ubiquiti Networks US-8-5

See All Ubiquiti Networks Wireless and Data Networking Products for Ubiquiti Networks US-8-5 Ethernet Switch >

Frequently Asked Questions

The Ubiquiti US-8-5 features 8 Gigabit Ethernet ports (10/100/1000 Mbps RJ45) in a compact form factor. These ports deliver high-speed connectivity with a total non-blocking throughput of 8 Gbps and a switching capacity of 16 Gbps, making it suitable for building and expanding enterprise networks.

The US-8-5 can be powered by 802.3af/at PoE, 48V passive PoE, or the included external AC/DC adapter (48V, 0.5A). Port 8 supports 48V PoE passthrough to deliver up to 12W of power to connected devices when the switch is powered by 802.3at PoE or the included power supply.

Yes, the US-8-5 includes PoE input on Port 1 and PoE passthrough output on Port 8, supporting multiple PoE modes (802.3af/at and 48V passive). This allows you to power devices like access points and cameras directly through the Ethernet cable while maintaining network connectivity.

The US-8-5 operates reliably in temperatures ranging from -5 to 45°C (23 to 113°F) and humidity levels of 5 to 95% noncondensing. It also meets ETSI300-019-1.4 standard for shock and vibration resistance, making it suitable for various deployment environments.

The US-8-5 is a fully manageable switch with Ethernet in-band management capabilities, allowing you to configure and monitor the switch remotely. It integrates with the UniFi Controller software for comprehensive network oversight and multi-site management from a centralized interface.

The US-8-5 features a security slot on its side that allows you to attach a lock to deter theft, and it includes built-in non-skid rubber feet to hold the switch firmly in place on your desk or rack. The compact steel enclosure (148.0 x 99.5 x 30.7 mm) weighs only 432 grams, making it easy to deploy in various locations.

The Ubiquiti Networks US-8-5 Ethernet Switch is also known as UBI-US85
