Ubiquiti Networks NBE-16-WM Network Antennas

The Ubiquiti NBE-16-WM is a window mount accessory for Ubiquiti wireless access points, designed for outdoor installations. It supports both pole-mount and wall-mount configurations, with a pole-mount kit included for flexible deployment options.

The NBE-16-WM features a 16 dBi gain antenna with dual linear polarization and operates across 5150–5875 MHz frequency bands. It includes a single 10/100 Ethernet port for connectivity and consumes a maximum of 6W power via 24V PoE, with dimensions of 140 x 140 x 54 mm and a weight of 0.320 kg.

Yes, the NBE-16-WM is built for outdoor deployment with UV-stabilized plastic enclosure and passes rigorous environmental testing including salt fog, vibration, temperature shock, UV, and wind-driven rain tests per IEC and MIL-STD standards. It survives wind speeds up to 200 km/h (125 mph) with a wind loading of 21.4 N at that speed.

The NBE-16-WM operates reliably in temperatures from -40 to 70° C (-40 to 158° F) and humidity levels from 5 to 95% noncondensing, making it suitable for diverse climate conditions.

The NBE-16-WM supports flexible channel sizes of 5, 8, 10, 20, 30, and 40 MHz, allowing you to optimize bandwidth allocation based on your network requirements and regulatory constraints.

The NBE-16-WM holds FCC, IC, and CE wireless approvals and is RoHS compliant. It also provides ESD/EMP protection rated at ±24 kV for both air and contact discharge, ensuring reliable operation in electrically challenging environments.
