Ubiquiti Networks ROCKETM5 Point to Point Wireless

Part Number: ROCKETM5
Model: Rocket M
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11n
Frequency Band
5 GHz
ISM Band
No
UNII Band
Yes

Product Description:

  Ubiquiti Rocket M M5 IEEE 802.11n 150 Mbit/s Wireless Access Point - 5 GHz - 31.1 Mile Maximum Outdoor Range - MIMO Technology - 1 x Network (RJ-45) - Ethernet, Fast Ethernet - Pole-mountable.
Explore all Ubiquiti Networks Rocket M Point to Multipoint Wirelesses
Add to Quote
Ubiquiti Networks ROCKETM5 Point to Point Wireless
Ubiquiti Networks ROCKETM5 Point to Point Wireless
Ubiquiti Networks ROCKETM5 Point to Point Wireless
Ubiquiti Networks ROCKETM5 Point to Point Wireless Ubiquiti Networks ROCKETM5 Point to Point Wireless Ubiquiti Networks ROCKETM5 Point to Point Wireless
Full specifications (PDF)

Ubiquiti Networks Rocket M Point to Multipoint Wireless Model Overview

Featuring mix-and-match industrial design, the Rocket is a Ubiquiti Networks airMAX BaseStation that supports speeds of up to 150+ Mbps real TCP/IP throughput. It is ideal for deployment in Point-to-Point (PtP) bridging or Point-to-MultiPoint (PtMP) airMAX applications. The Rocket is available in several frequency models: 900 MHz, 2.4 GHz, 3/3.65 GHz, and 5 GHz, to support your specific application. You have the freedom to locate, deploy, and operate the Rocket in these unlicensed bands (subject to local country regulations).
Ubiquiti Networks ROCKETM5 Point to Point Wireless Overview
Integrated AirMax Technology

Unlike standard WiFi protocol, Ubiquiti's Time Division Multiple Access (TDMA) AirMax protocol allows each client to send & receive data using pre-designated time slots scheduled by an intelligent AP controller.

This "time slot" method eliminates hidden node collisions & maximizes air time efficiency. It provides many magnitudes of performance improvements in latency, throughput, & scalability compared to all other outdoor systems in its class.

Intelligent QoS Priority is given to voice/video for seamless access.

Scalability High capacity and scalability.

Long Distance Capable of high speed 50km+ links

Latency Multiple features dramatically reduce noise.
Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11n
Frequency Band:
5 GHz
ISM Band:
No
UNII Band:
Yes
UNII Minimum Frequency:
5.47 GHz
UNII Maximum Frequency:
5.83 GHz
Total Number of Antennas:
2
Number of External Antennas:
2
Antenna Connector:
RP-SMA Connector
Outdoor Antenna Range:
31.1 Mile
Wireless Transmission Speed:
150 Mbit/s
MIMO Technology:
Yes
Features:
  • Quality of Service (QoS)
  • MIMO Technology
  • Rugged
  • Water Proof
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE (RJ-45) Port:
No
PoE PD Port:
Yes
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management & Protocols
Management:
  • Web Based Management
  • airOS
  • airControl
Physical Characteristics
Form Factor:
Pole-mountable
Height:
6.7"
Width:
3.1"
Depth:
1.2"
Weight (Approximate):
1.10 lb
Miscellaneous
Package Contents:
  • Rocket M5 Wireless Access Point
  • Pole Mounting Kit
  • PoE Supply
Certifications & Standards:
  • FCC Part 15.247
  • IC RS210
  • CE
IEEE Standards:
  • 802.11a
  • 802.11n
Environmentally Friendly:
Yes
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0602003745980, 0609728684396, 0709257386287, 0810354025051, 0818238983411
UPC: 602003745980, 609728684396, 709257386287, 810354025051, 818238983411
EAN: 0602003745980, 0609728684396, 0709257386287, 0810354025051, 0818238983411
UNSPSC: 43222640
