Ubiquiti Networks NSM2 Point to Multipoint Wireless

Part Number: NSM2
Model: NanoStation M
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11n
Frequency Band
2.46 GHz
ISM Band
Yes
UNII Band
No

Product Description:

  Due to Ubiquiti supply chain constraints, products not listed as in-stock will have extended lead times. Ubiquiti NanoStationM NSM2 IEEE 802.11n 150 Mbit/s Wireless Access Point - 2.46 GHz - 8.1 Mile Maximum Outdoor Range - 2 x Network (RJ-45) - Ethernet, Fast Ethernet - PoE Ports - Pole-mountable
Explore all Ubiquiti Networks NanoStation M Point to Multipoint Wirelesses
Add to Quote
Ubiquiti Networks NSM2 Point to Multipoint Wireless
Ubiquiti Networks NSM2 Point to Multipoint Wireless
Ubiquiti Networks NSM2 Point to Multipoint Wireless
Ubiquiti Networks NSM2 Point to Multipoint Wireless
Ubiquiti Networks NSM2 Point to Multipoint Wireless Ubiquiti Networks NSM2 Point to Multipoint Wireless Ubiquiti Networks NSM2 Point to Multipoint Wireless Ubiquiti Networks NSM2 Point to Multipoint Wireless
Full specifications (PDF)

Ubiquiti Networks NanoStation M Point to Multipoint Wireless Model Overview

The NanoStation M and NanoStation locoM by Ubiquiti Networks are game changing solutions for outdoor and indoor connectivity. Designed with cutting-edge industrial aesthetics and high-performance airMAX® technology, these compact devices provide efficient, cost-effective broadband equipment. Suitable for both Point-to-Multi-Point (PtMP) and Point-to-Point (PtP) applications, they deliver exceptional scalability and improved latency for seamless data transmission. Upgrade your network capabilities and experience reliable high-speed connections no matter the environment.


Key Features
  • Versatile Design: Ideal for both indoor and outdoor installations.
  • Powerful Integrated Antenna: High gain for long-distance communication.
  • Intelligent QoS: Prioritizes voice and video for improved streaming.
  • Remote Hardware Reset: Easily reset your device from a distant power supply.
  • Dual Ethernet Connectivity: Includes a secondary Ethernet port with software-enabled PoE output.

Specifications
  • Dimensions: 294 x 31 x 80 mm (NanoStation M5)
  • Weight: 400 g (NanoStation M5)
  • Power Supply: 24V, 0.5A PoE
  • Max. Power Consumption: 8W
  • Operating Frequency: 5 GHz
  • Gain: 14.6-16.1 dBi
  • Networking Interface: (2) 10/100 Ethernet Ports
  • Operating Temperature: -30 to 75° C
  • Operating Humidity: 5 to 95% Noncondensing
  • Wireless Approvals: FCC Part 15.247, IC RS210, CE
Ubiquiti Networks NSM2 Point to Multipoint Wireless Overview
Leading-Edge Industrial Design

Ubiquiti Networks™ set the bar for the world's first low-cost and efficient broadband Customer Premises Equipment (CPE) with the original NanoStation™. The NanoStationM and NanoStationlocoM take the same concept to the future with sleek and elegant form factors, along with integrated airMAX™ (MIMO TDMA protocol) technology.

The low cost, high performance, and small form factor of NanoStationM and NanoStationlocoM make them extremely versatile and economical to deploy.
Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11n
Frequency Band:
2.46 GHz
ISM Band:
Yes
UNII Band:
No
ISM Minimum Frequency:
2.41 GHz
ISM Maximum Frequency:
2.46 GHz
Antenna Gain (Isotropic):
11 dBi
Outdoor Antenna Range:
8.1 Mile
Wireless Transmission Speed:
150 Mbit/s
Features:
  • MIMO Technology
  • LED Indicator
  • Quality of Service (QoS)
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
Number of Network (RJ-45) Ports:
2
Network (RJ-11):
No
PoE (RJ-45) Port:
Yes
PoE PD Port:
Yes
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management Port:
No
Management & Protocols
Management:
  • Web Based Management
  • airControl
Physical Characteristics
Form Factor:
Pole-mountable
Height:
11.6"
Width:
3.1"
Depth:
1.2"
Weight (Approximate):
14.11 oz
Miscellaneous
Package Contents:
  • NanoStationM NSM2 Wireless Access Point
  • Pole Mounting Kit
Certifications & Standards:
  • ETSI300-019-1.4
  • FCC Part 15.247
  • IC RS210
  • CE
IEEE Standards:
  • 802.11b
  • 802.11g
  • 802.11n
  • 802.3af
Environmentally Friendly:
Yes
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0460335000029, 0602003746345, 0609132712272, 0688474340688, 0688474340695, 0688474340749, 0700175495136, 0810354025006, 0817882023269, 0888063595554
UPC: 460335000029, 602003746345, 609132712272, 688474340688, 688474340695, 688474340749, 700175495136, 810354025006, 817882023269, 888063595554
EAN: 0460335000029, 0602003746345, 0609132712272, 0688474340688, 0688474340695, 0688474340749, 0700175495136, 0810354025006, 0817882023269, 0888063595554
UNSPSC: 43222631
