Ubiquiti Networks NBE-M5-19 Point to Multipoint Wireless

Part Number: NBE-M5-19
Model: NanoBeam M
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11n
ISM Band
No
UNII Band
Yes
UNII Minimum Frequency
5.73 GHz

Product Description:

  Due to Ubiquiti supply chain constraints, products not listed as in-stock will have extended lead times. Ubiquiti NanoBeam NBE-M5-19 IEEE 802.11n 300 Mbit/s Wireless Bridge - 1 x Network (RJ-45) - Ethernet, Fast Ethernet - Pole-mountable, Wall Mountable - 1 Pack
Explore all Ubiquiti Networks NanoBeam M Point to Multipoint Wirelesses
Add to Quote
Ubiquiti Networks NBE-M5-19 Point to Multipoint Wireless
Ubiquiti Networks NBE-M5-19 Point to Multipoint Wireless
Ubiquiti Networks NBE-M5-19 Point to Multipoint Wireless Ubiquiti Networks NBE-M5-19 Point to Multipoint Wireless
Full specifications (PDF)

Ubiquiti Networks NanoBeam M Point to Multipoint Wireless Model Overview

Starting with the first-generation NanoBridge, Ubiquiti Networks pioneered the all-in-one design for an airMAX® product functioning as a CPE (Customer Premises Equipment). Now Ubiquiti Networks launches the latest generation of CPE, the NanoBeam. Available for the 2.4 and 5 GHz frequency bands, the NanoBeam directs RF energy in a tighter beamwidth. With the focus in one direction, the NanoBeam blocks or spatially filters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Ubiquiti Networks NBE-M5-19 Point to Multipoint Wireless Overview
Starting with the frst-generation NanoBridge®, Ubiquiti Networks™ pioneered the all-in-one design for an airMAX® product functioning as a CPE (Customer Premises Equipment). Now Ubiquiti Networks launches the latest generation of CPE, the NanoBeam™.

Improved Noise Immunity

The NanoBeam directs RF energy in a tighter beamwidth. With the focus in one direction, the NanoBeam blocks or spatially flters out noise, so noise immunity is improved. This feature is especially important in an area crowded with other RF signals of the same or similar frequency.
Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11n
ISM Band:
No
UNII Band:
Yes
UNII Minimum Frequency:
5.73 GHz
UNII Maximum Frequency:
5.85 GHz
Total Number of Antennas:
1
Antenna Gain (Isotropic):
19 dBi
Wireless Transmission Speed:
300 Mbit/s
Wireless Security:
WPA2
Features:
  • MIMO Technology
  • Quality of Service (QoS)
  • LED Indicator
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE (RJ-45) Port:
No
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management & Protocols
Management:
  • airControl
  • Web Based Management
  • DHCP
Power Description
Input Voltage:
24 V DC
Physical Characteristics
Form Factor:
  • Pole-mountable
  • Wall Mountable
Height:
7.4"
Width:
7.4"
Depth:
4.9"
Weight (Approximate):
1.17 lb
Miscellaneous
Package Contents:
  • High-Performance airMAX Bridge
  • Pole Mounting Kit
Certifications & Standards:
  • FCC
  • IC
  • CE
Environmentally Friendly:
Yes
Item Numbers
GTIN: 0657379380860, 0810354022470, 0810354024962, 0818263736532
UPC: 657379380860, 810354022470, 810354024962, 818263736532
EAN: 0657379380860, 0810354022470, 0810354024962, 0818263736532
UNSPSC: 43222631
