Ubiquiti Networks LOCOM2 Point to Multipoint Wireless

Part Number: LOCOM2
Model: NanoStation M
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Wireless LAN Standard
IEEE 802.11b/g
ISM Band
Yes
UNII Band
No
ISM Minimum Frequency
2.41 GHz

Product Description:

  Due to Ubiquiti supply chain constraints, products not listed as in-stock will have extended lead times. Ubiquiti NanoStation locoM2 IEEE 802.11b/g 300 Mbit/s Wireless Bridge - 49.2 ft Maximum Outdoor Range - 1 x Network (RJ-45) - Ethernet, Fast Ethernet - Pole-mountable
Explore all Ubiquiti Networks NanoStation M Point to Multipoint Wirelesses
Add to Quote
Ubiquiti Networks LOCOM2 Point to Multipoint Wireless
Ubiquiti Networks LOCOM2 Point to Multipoint Wireless
Ubiquiti Networks LOCOM2 Point to Multipoint Wireless
Ubiquiti Networks LOCOM2 Point to Multipoint Wireless Ubiquiti Networks LOCOM2 Point to Multipoint Wireless Ubiquiti Networks LOCOM2 Point to Multipoint Wireless
Full specifications (PDF)

Ubiquiti Networks NanoStation M Point to Multipoint Wireless Model Overview

The NanoStation M and NanoStation locoM by Ubiquiti Networks are game changing solutions for outdoor and indoor connectivity. Designed with cutting-edge industrial aesthetics and high-performance airMAX® technology, these compact devices provide efficient, cost-effective broadband equipment. Suitable for both Point-to-Multi-Point (PtMP) and Point-to-Point (PtP) applications, they deliver exceptional scalability and improved latency for seamless data transmission. Upgrade your network capabilities and experience reliable high-speed connections no matter the environment.


Key Features
  • Versatile Design: Ideal for both indoor and outdoor installations.
  • Powerful Integrated Antenna: High gain for long-distance communication.
  • Intelligent QoS: Prioritizes voice and video for improved streaming.
  • Remote Hardware Reset: Easily reset your device from a distant power supply.
  • Dual Ethernet Connectivity: Includes a secondary Ethernet port with software-enabled PoE output.

Specifications
  • Dimensions: 294 x 31 x 80 mm (NanoStation M5)
  • Weight: 400 g (NanoStation M5)
  • Power Supply: 24V, 0.5A PoE
  • Max. Power Consumption: 8W
  • Operating Frequency: 5 GHz
  • Gain: 14.6-16.1 dBi
  • Networking Interface: (2) 10/100 Ethernet Ports
  • Operating Temperature: -30 to 75° C
  • Operating Humidity: 5 to 95% Noncondensing
  • Wireless Approvals: FCC Part 15.247, IC RS210, CE
Ubiquiti Networks LOCOM2 Point to Multipoint Wireless Overview
Leading-Edge Industrial Design

Ubiquiti Networks™ set the bar for the world's first low-cost and efficient broadband Customer Premises Equipment (CPE) with the original NanoStation™. The NanoStationM and NanoStationlocoM take the same concept to the future with sleek and elegant form factors, along with integrated airMAX™ (MIMO TDMA protocol) technology.

The low cost, high performance, and small form factor of NanoStationM and NanoStationlocoM make them extremely versatile and economical to deploy.
Full specifications (PDF)
Technical Information
Wireless LAN Standard:
IEEE 802.11b/g
ISM Band:
Yes
UNII Band:
No
ISM Minimum Frequency:
2.41 GHz
ISM Maximum Frequency:
2.46 GHz
Antenna Gain (Isotropic):
8 dBi
Outdoor Antenna Range:
49.2 ft
Wireless Transmission Speed:
300 Mbit/s
Wireless Security:
  • WEP
  • WPA
  • WPA2
Features:
  • Quality of Service (QoS)
  • MIMO Technology
Interfaces/Ports
Ethernet Technology:
  • Ethernet
  • Fast Ethernet
Number of Network (RJ-45) Ports:
1
Network (RJ-11):
No
PoE (RJ-45) Port:
No
VGA:
No
HDMI:
No
Audio Line Out:
No
Serial Port:
No
USB:
No
Powerline:
No
Management & Protocols
Management:
  • airControl
  • Web Based Management
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Form Factor:
Pole-mountable
Height:
6.4"
Width:
3.1"
Depth:
1.2"
Weight (Approximate):
6.35 oz
Miscellaneous
Package Contents:
  • NanoStation locoM2 Wireless Bridge
  • Pole-Mount Kit
Certifications & Standards:
  • FCC Part 15.247
  • IC RS210
  • CE
IEEE Standards:
  • 802.3af
  • 802.11b
  • 802.11g
  • 802.11n
Environmentally Friendly:
Yes
Item Numbers
GTIN: 0033585518776, 0602003746277, 0602003746307, 0709257383040, 0810354022333, 0810354024924, 0817882023245, 0818231554434, 5053118068344, 8103540223334
UPC: 033585518776, 602003746277, 602003746307, 709257383040, 810354022333, 810354024924, 817882023245, 818231554434
EAN: 0033585518776, 0602003746277, 0602003746307, 0709257383040, 0810354022333, 0810354024924, 0817882023245, 0818231554434, 5053118068344, 8103540223334
UNSPSC: 43222631
