Ubiquiti Networks ES-8-150W Ethernet Switch

Part Number: ES-8-150W
Model: EdgeSwitch 8 150W
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Total Number of Network Ports
8
Uplink Port
No
Modular
Yes
Stack Port
No

Product Description:

  Ubiquiti Managed PoE+ Gigabit Switch with SFP - 8 Ports - Manageable - 2 Layer Supported - Modular - Twisted Pair, Optical Fiber - Standalone, Desktop, Wall Mountable.
Explore all Ubiquiti Networks EdgeSwitch 8 150W Network Switches
Add to Quote
Ubiquiti Networks ES-8-150W Ethernet Switch
Ubiquiti Networks ES-8-150W Ethernet Switch
Ubiquiti Networks ES-8-150W Ethernet Switch Ubiquiti Networks ES-8-150W Ethernet Switch
Full specifications (PDF)

Ubiquiti Networks EdgeSwitch 8 150W Network Switch Model Overview

Build and expand your network with Ubiquiti Networks EdgeSwitch, part of the EdgeMAX line of products. The EdgeSwitch is a fully managed, PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability. Sharing a total of 150W, eight Gigabit Ethernet ports offer auto-sensing IEEE 802.3af/at PoE/PoE+ or 24V passive PoE to simplify your infrastructure.
Ubiquiti Networks ES-8-150W Ethernet Switch Overview

Gigabit Connectiviy

The compact EdgeSwitch features a versatile port configuration: eight Gigabit Ethernet ports that support PoE+ and two SFP ports for fiber connectivity. It can be placed on a desktop or mounted on a wall.

Convenient PoE+ Support

Sharing a total of 150W, eight Gigabit Ethernet ports offer auto-sensing IEEE 802.3af/at PoE/PoE+ or 24V passive PoE to simplify your infrastructure.

Optical Fiber Backhaul

The EdgeSwitch provides fiber connectivity options for your growing networks. Two SFP ports provide uplinks of up to 1 Gbps.

Powerful Performance

The EdgeSwitch delivers robust switching performance with its total, non-blocking throughput of up to 10 Gbps.

Switching Capacity

The EdgeSwitch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.

Advanced UI

The comprehensive UI is easy to learn and allows administrators to configure and monitor features in a graphical user interface. For advanced users, a Command-Line Interface (CLI) is available through telnet and SSH.

Full specifications (PDF)
Interfaces/Ports
Total Number of Network Ports:
8
Uplink Port:
No
Modular:
Yes
Stack Port:
No
Port/Expansion Slot Details:
  • 8 x Gigabit Ethernet Network
  • 2 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
  • Twisted Pair
  • Optical Fiber
Ethernet Technology:
Gigabit Ethernet
Network Technology:
  • 10/100/1000Base-TX
  • 1000Base-X
I/O Expansions
Number of Total Expansion Slots:
2
Expansion Slot Type:
SFP
Shared SFP Slot:
No
Number of SFP Slots:
2
Network & Communication
Layer Supported:
2
Management & Protocols
Manageable:
Yes
Power Description
Power Source:
Power Supply
Physical Characteristics
Form Factor:
  • Standalone
  • Desktop
  • Wall Mountable
Height:
1.7"
Width:
9.3"
Depth:
8"
Weight (Approximate):
3.79 lb
Miscellaneous
Package Contents:
  • Managed PoE+ Gigabit Switch with SFP
  • Mount Brackets
Item Numbers
GTIN: 0029882947296, 0696552137457, 0810354025679, 0810354025686, 0817882023214, 0818214490698, 0818240960264, 0818251057366, 0993246217052
UPC: 029882947296, 696552137457, 810354025679, 810354025686, 817882023214, 818214490698, 818240960264, 818251057366, 993246217052
EAN: 0029882947296, 0696552137457, 0810354025679, 0810354025686, 0817882023214, 0818214490698, 0818240960264, 0818251057366, 0993246217052
UNSPSC: 43222612
