VeriFone M132-509-01-R Payment Terminal

VeriFone M177-509-01-R Payment Terminal A newer version of this item is available.
It is replaced by the VeriFone M177-509-01-R Payment Terminal.
VeriFone MX925 - VeriFone MX 925 Payment Terminal - 7" - Color - ARM ARM11 400 MHz - 256 MB RAM - Triple DES, Master/Session, DUKPT, Interac, AES - Fast Ethernet - Wireless LAN - Near Field Communication - Network, USB, Serial, SerialUSB - Serial - Pin Pad, Signature Capture
VeriFone MX925 Payment Terminal Model Overview
With the largest and highest resolution display in the industry, the MX925 creates an entirely new dimension in consumer POS experiences. The remarkable 7" WVGA color display is large enough to comfortably accommodate signature capture on one half of the screen while receipts are tallied or branding and promotional offers are presented on the other. A powerful processor and generous memory easily handle any multimedia demands.
VeriFone M132-509-01-R Payment Terminal Overview
Multimedia Display to Boost Sales

The MX 925 helps influence consumers' buying decisions by enabling merchants to show consumers targeted video and promotional presentations at the point of sale. With clear, colorful multimedia promotions shown on a stunning 7" color display - the largest and highest-resolution display in the industry - merchants can dazzle customers with graphics of the latest products and offers.

The high-speed powerful processor and generous memory allocation supports full studio showcase promotions and video advertisements to help boost sales and levels of service. The MX 925 engages consumers with streamed media and visual promotions to encourage consumer ­­­interaction and support loyalty and promotional programs - ultimately improving consumer satisfaction and increasing revenue.

Key Benefits:

Total Multi-payment Solution

The MX 925 supports multiple payment types: mag-stripe, EMV, PIN debit as well as NFC/contactless and non-traditional payment schemes like mobile wallets.

Evolving Payment Technology

The MX 925 delivers revenue opportunities by securing payments and supporting highly profitable, next-generation value-added services. It is an ideal platform for a variety of value-added services, such as administrating loyalty programs, gift card issuance and top-up services.

Opportunities Beyond Payment

A 7" color screen efficiently accommodates signature capture, along with scrolling account activity, branding and promotional offers.

Technical Information
Encryption:
  • Triple DES
  • Master/Session
  • DUKPT
  • Interac
  • AES
Signature Capture:
Yes
Pin Pad:
Yes
Processor & Chipset
Processor Manufacturer:
ARM
Processor Type:
ARM11
Processor Speed:
400 MHz
Memory
Standard Memory:
256 MB
Flash Memory:
256 MB
Display & Graphics
Screen Size:
7"
Display Color:
Color
Screen Mode:
WVGA
Touchscreen:
Yes
Screen Resolution:
800 x 480
Network & Communication
Ethernet Technology:
Fast Ethernet
Wireless LAN:
Yes
Near Field Communication:
Yes
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
Serial:
Yes
Built-in Devices
Built-in Devices:
  • Magnetic Stripe Reader
  • Contactless Reader
  • Smart Card Reader
Keyboard/Keypad
Number of Keys:
13
Software
Operating System:
Linux
Power Description
Input Voltage:
  • 120 V AC
  • 230 V AC
Physical Characteristics
Height:
2.2"
Width:
8.6"
Depth:
9.1"
Weight (Approximate):
1.98 lb
Miscellaneous
Certifications & Standards:
  • PCI PTS 3.X
  • PCI PTS 4.0
  • EMVCo L1 and L2
Warranty
Limited Warranty:
13 Month
Item Numbers
GTIN: 0039479327936, 0816909002560
UPC: 039479327936, 816909002560
EAN: 0039479327936, 0816909002560
UNSPSC: 43211720
Questions? Get help from
a POS Expert!

What is your POS application?

The VeriFone M132-509-01-R Payment Terminal is also known as VFN-M132-509-01-R or M13250901R.
