Intermec EasyCoder PX4i – Barcode Label Printer – 203 dpi – Thermal Transfer

Part Number: PX4B911000301020
Model: EasyCoder PX4i
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Industrial
Printing Technology
Thermal Transfer
Interface Options
Ethernet, Parallel
Print Resolution
203 dpi

Product Description:

  EasyCoder PX4i Direct Thermal-Thermal Transfer Printer (IPL, EasyLAN Ethernet Interface, Parallel Interface, No Option 2, 16MB RAM, 4MB Flash, Rotating Unwinding Media Hanger, Paper Rewind Self Strip + LTS and TT 203 dpi)
Explore all Intermec EasyCoder PX4i Barcode Label Printers
Add to Quote
Intermec PX4B911000301020 Barcode Label Printer
Intermec PX4B911000301020 Barcode Label Printer
Intermec PX4B911000301020 Barcode Label Printer
Intermec PX4B911000301020 Barcode Label Printer
Intermec PX4B911000301020 Barcode Label Printer Intermec PX4B911000301020 Barcode Label Printer Intermec PX4B911000301020 Barcode Label Printer Intermec PX4B911000301020 Barcode Label Printer
Full specifications (PDF)

Intermec EasyCoder PX4i Barcode Label Printer Model Overview

Designed for easy integration into manufacturing environments, the EasyCoder PX4i printer can be mounted in virtually any position. The versatile form factor facilitates the addition of add-ons such as an automatic label applicator. Up to seven wired and wireless connectivity interfaces can be used simultaneously eliminating connectivity restrictions and supporting additional devices. The EasyCoder PX4i printer can operate as stand alone devices executing user-defined programs thereby eliminating the need for a PC. The EasyCoder PX4i can operate production line machinery including scanners, scales and other printers and conveyors as well as access information directly from the network host, is fully programmable and is able to change with the application as needed. Ships with full-featured version of LabelShop START label design software.
Intermec PX4B911000301020 Barcode Label Printer Overview

The EasyCoder PX Series printer is rugged, metal, high performance printer designed to excel in demanding environments and support round the clock operations. The open, modular design ensures the printer is easy to adapt, maintain and service. Designed for easy integration into manufacturing environments, the PX series printer can be mounted in virtually any position. The versatile form factor facilitates the addition of add ons such as an automatic label applicator. The EasyCoder PX series printer can operate as stand alone device executing user defined programs thereby eliminating the need for a PC. The PX series printer print instantly from first to last label. This is ideal for on demand and compliance labeling applications with variable data requiring immediate results. The PX series printer is the first bar code label printer to integrate Intermec's Readiness Indicator (IRI) light. Part of the Intermec Smart System, this light provides a visual cue to the operating state of the printer. The EasyCoder PX series printer communicates with the Smart System Console which displays status, provides access to configuration, eases installation of new printers, and assists in identifying printer consumables that require replenishment

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
12 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
4.40"
Barcode Symbology Supported:
  • Codabar
  • Code 11
  • Code 39
  • Code 93
  • MSI PLESSEY
  • Code 128
  • Code 128-A
  • Code 128-C
  • DUN-14/16
  • UPC/EAN
  • EAN 128
  • EAN-128 Subset A
  • EAN-128 Subset C
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • Interleaved 2 of 5 A
  • Matrix 25
  • Planet Code
  • POSTNET
  • Straight 2 of 5
  • UCC 128
  • QR Code
  • HIBC Code 39
  • EAN.UCC Composite
  • JIS-ITF
  • Code 16K
  • Code 49
  • Data Matrix
  • Maxi Code
  • PDF-417
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
4 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Media Types & Handling
Media Type:
  • Roll Fed
  • Die-cut Label
  • Continuous Label
  • Fanfold
  • Tag
  • Ticket
Media Size:
Custom Size
Media Thickness:
9.84 mil
Maximum Roll Diameter:
8.38"
Label Core Size:
2.99"
Fonts & Emulation
Language Emulation:
IPL
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Height:
9.4"
Width:
10.8"
Depth:
19"
Miscellaneous
Additional Information:
  • Label Taken Sensor (LTS)
  • Graphics: Supports PCX file format
  • Wand interface for EasySet System
  • Max Print Width: DT 4.4 in & TT 4.3 in
  • Integral Self-Strip Unit with Liner Take-up
  • Display: Back-lit LCD for 2 x16 characters & 3 LED indicator lamps
Platform Supported:
PC
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108
