Intermec EasyCoder PX4i – Barcode Label Printer – 203 dpi – Thermal Transfer

Part Number: PX4B010000300020
Model: EasyCoder PX4i

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Industrial
Printing Technology
Thermal Transfer
Interface Options
Ethernet
Print Resolution
203 dpi

Product Description:

  Direct Thermal-Thermal Transfer printer, 4.4" print width, 12"/sec speed, 203 dpi, 16MB RAM, 4MB Flash, US power cord, IPL firmware, EasyLAN Ethernet interface, Rotating unwinding media hanger, No option 1, No option 2 and TT 203 dpi

Intermec EasyCoder PX4i Barcode Label Printer Model Overview

Designed for easy integration into manufacturing environments, the EasyCoder PX4i printer can be mounted in virtually any position. The versatile form factor facilitates the addition of add-ons such as an automatic label applicator. Up to seven wired and wireless connectivity interfaces can be used simultaneously eliminating connectivity restrictions and supporting additional devices. The EasyCoder PX4i printer can operate as stand alone devices executing user-defined programs thereby eliminating the need for a PC. The EasyCoder PX4i can operate production line machinery including scanners, scales and other printers and conveyors as well as access information directly from the network host, is fully programmable and is able to change with the application as needed. Ships with full-featured version of LabelShop START label design software.
Intermec PX4B010000300020 Barcode Label Printer Overview

The PX4I Label Printers are rugged, metal, high-performance printers designed to excel in demanding 24/7 duty applications.The open, modular design ensures the printer is easy to adapt, maintain and service. The PX4I Label Printer print instantly from first to last label . This is ideal for on demand and compliance labeling applications with variable data requiring immediate results. The combination of powerful individually controlled microstep motors, generously dimensioned power supply, and new sophisticated thermal management printhead ensures high quality labels each and every time. Designed for easy integration into manufacturing environments, the PX4I Label Printers can be mounted in virtually any position. The versatile form factor facilitates the addition of add ons such as an automatic label applicator. The PX4I Label Printers are the first bar code label printer to integrate Intermec Readiness Indicator (IRI) light. Participating in concert with other Intermec SmartSystem devices, the EasyCoder PX series printer communicates with the SmartSystem Console which displays status, provides access to configuration, eases installation of new printers, and assists in identifying printer consumables that require replenishment. The PX4I printers can operate as stand alone devices executing user defined programs thereby eliminating the need for a PC. These printers can operate production line machinery, including scanners, scales, other printers and conveyor as well as access information directly from the network host. The printers are fully programmable and are able to change with the application as needed, providing additional functionality and continued investment protection. These printers are not restricted by printer command languages. They can communicate with and replace competitive and older Intermec printers without any changes to host programming or label format design. The PX Label Printers are true high-performance, 24/7-duty printers for those who expect more from their industrial printers.

Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
12 in/s
Maximum Print Resolution (dpi):
300
Maximum Print Width:
4.30"
Barcode Symbology Supported:
  • Codabar
  • Code 11
  • Code 39
  • Code 93
  • MSI PLESSEY
  • Code 128
  • Code 128-A
  • Code 128-C
  • DUN-14/16
  • UPC/EAN
  • EAN 128
  • EAN-128 Subset A
  • EAN-128 Subset C
  • Industrial 2 of 5
  • Interleaved 2 of 5
  • Interleaved 2 of 5 A
  • Matrix 25
  • Planet Code
  • POSTNET
  • Straight 2 of 5
  • UCC 128
  • RSS
  • HIBC Code 39
  • HIBC Code 128
  • JIS-ITF
  • Code 16K
  • Code 49
  • Data Matrix
  • Maxi Code
  • PDF-417
  • QR Code
  • Micro PDF-417
  • EAN.UCC Composite
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
16 MB
Memory Technology:
SDRAM
Flash Memory:
4 MB
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
Media Types & Handling
Media Type:
  • Roll Fed
  • Die-cut Label
  • Continuous Label
  • Fanfold
  • Tag
  • Ticket
Media Size:
4.70" x Roll Paper
Maximum Roll Diameter:
8.38"
Maximum Label Width:
4.72"
Maximum Label Length:
13.42 ft
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
IPL2
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Height:
9.4"
Width:
10.8"
Depth:
19"
Miscellaneous
Package Contents:
  • Power Cord
  • User & Installation manuals
  • Printer Companion CD
  • Cleaning Card
  • Sample Media
  • Product registration card
  • Declaration of Conformity
Cables Included:
AC
Additional Information:
  • Max Print Width: DT 4.4 in TT 4.3 in
  • Print Speed: 4 - 12 ips variable
  • Graphics: Supports PCX file format
  • Wand Interface for Wand Barcode Scanners
  • Display: Back-lit LCD for 2 x16 characters & 3 LED indicator lamps
Platform Supported:
PC
Certifications & Standards:
  • CE (EN55022 Class A)
  • FCC Class A
  • UL
  • CSA
  • C-Tick
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108
