Intermec PM43c – Barcode Label Printer – 203 dpi – Thermal Transfer

Part Number: PM43CA1130000201
Model: PM43c
Add to My Shopping List Add to Compare
Discontinued See Replacement
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Industrial
Printing Technology
Thermal Transfer
Interface Options
Ethernet, Serial (RS-232), USB
Print Resolution
203 dpi

Product Description:

  Pm43c, Thermal Transfer Printer, Color Touchscreen, Usb, Serial, Ethernet, Lan, Long Door + Front Access, Fixed Hanger, 200 Dpi, Na Power Cord
Explore all Intermec PM43c Barcode Label Printers
Add to Quote
Intermec PM43CA1130000201 Barcode Label Printer
Intermec PM43CA1130000201 Barcode Label Printer
Intermec PM43CA1130000201 Barcode Label Printer
Intermec PM43CA1130000201 Barcode Label Printer Intermec PM43CA1130000201 Barcode Label Printer

Full specifications (PDF)

Intermec PM43c Barcode Label Printer Model Overview

The Intermec PM43c compact mid-range industrial label printers are ready to perform. Reduce workforce training and support with the tamper-proof, 10-language, color touch-screen or universal-icon interface. The PM43c is a third-generation Intermec industrial printer designed to maximize your uptime. Count on the PM43c to deliver quick deployment, the fastest print speed in its class, and proven reliability.
Intermec PM43CA1130000201 Barcode Label Printer Overview

PM43/PM43c mid-range industrial printers are ideal for a wide range of applications within the distribution center / warehouse and manufacturing environments.

Ready - Fastest to Deploy. Seamlessly Fits Any Environment.
  • Large, color, multilingual, tamper-proof touch screen, or icon user interface
  • "No-touch" configuration capabilities
  • The only CCX- and WiFi-certified fixed printer with standard IPv6 implementation
Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
12 in/s
Maximum Print Resolution (dpi):
200
Maximum Print Width:
4.25"
Barcode Symbology Supported:
  • UPC/EAN Shipping Container
  • UCC/EAN 128 Serial Shipping Container
  • LOGMARS
  • POSTNET
  • HIBCC
  • ISBT-128
  • GM1724
Application/Usage:
Desktop
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
128 MB
Memory Technology:
SDRAM
Flash Memory:
128 MB
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Display & Graphics
Touchscreen:
Yes
Media Types & Handling
Media Type:
  • Label
  • Tag
  • Linered Label
  • Linerless
  • Roll Fed
  • Fanfold
  • Gap
  • Notch
  • Black Mark
  • Continuous Label
Media Sensor:
Transmissive Media Sensor
Media Thickness:
10.40 mil
Maximum Roll Diameter:
8.38"
Maximum Label Width:
4.50"
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
  • Fingerprint
  • IPL
  • ZSim
  • DSim
  • XML
Power Description
Power Source:
AC Supply
Input Voltage:
  • 110 V AC
  • 220 V AC
Maximum Power Consumption:
300 W
Standby Power Consumption:
9 W
Physical Characteristics
Height:
7.1"
Width:
9.9"
Depth:
17"
Weight (Approximate):
27.65 lb
Miscellaneous
Power Cable Localization:
US
Package Contents:
  • PM43c Label Printer
  • US Power Cord
Platform Supported:
PC
Certifications & Standards:
  • PFC Regulation: IEC320/C14
  • CE (EN55022 Class A)
  • FCC Class A
  • UL/cUL
  • C-Tick
  • D Mark
  • CCC
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
1 Year
Item Numbers
GTIN: 0735548763239, 0783555125939
UPC: 735548763239, 783555125939
EAN: 0735548763239, 0783555125939
UNSPSC: 43212108
