The new fixed-mounting industrial reader HF800 delivers outstanding barcode reading capability for all types of 1D and 2D codes including those on printed labels and the most difficult direct part mark (DPM), making it perfect for production data tracking for PCB and precision electronic parts, food production process management and confirma-tion of logistics barcode on the external packing cartons for electric/mechanical parts.HF800 is equipped with imager with a resolution of 500K-pixel which is capable of collecting images at 60 fps. Its built-in red LED light source combined with exceptional DPM decoding algorithm enables HF800 to have powerful DPM resolution. In addition, its compact size makes it ideal for use in industrial environment with limited space. The IP65 protection rating also ensures that it can handle various harsh working environments. HF800 is also equipped with DataMax software, as well as AutoLearn function. The user can complete image setting with just one button, a significant convenience for any bar code reader.The device is integrated with network ports, RS232 port and RS485 port as well as I/O port input to meet the needs of users in different application environments. A 0-degree and 90-degree version for vertical or horizontal mounting can be selected based on the site’s actual working needs. Depending on the working distance, there are 3 different versions available– HD, SR and ER. The user can select a product that suits their needs for working distance and field of vision.
Features and Benefits
Powerful DPM decoding: 500K-pixel resolution imager with 60fps capability and built-in red LED light source to give it powerful decoding capability for DPM.
Suitable for use in harsh and complex environments: Its compact size makes it ideal in tight industrial environment, while its IP65 rating ensures that it can handle all types of harsh and complex work environments.
Simple and quick configuration: Equipped with DataMax software and AutoLearn functions, it allows image setting to be completed with just one button, thereby significantly increasing the convenience of configuring the reader.
Wide variety of ports: HF800 is integrated with network port, RS232 port and RS485 port, as well supports I/O port output.Numerous models to meet different application needs: Offers two versions – 0° and 90° – as well as 3 versions namely HD, SR and ER for different distances*; product combinations meet the needs of users for different applications.
Honeywell HF800ER-R1-1V Barcode Scanner Overview
The new fixed-mounting industrial reader HF800 delivers outstanding barcode reading capability for all types of 1D and 2D codes including those on printed labels and the most difficult direct part mark (DPM), making it perfect for production data tracking for PCB and precision electronic parts, food production process management and confirmation of logistics barcode on the external packing cartons for electric/mechanical parts.
HF800 is equipped with imager with a resolution of 500K-pixel which is capable of collecting images at 60 fps. Its built-in red LED light source combined with exceptional DPM decoding algorithm enables HF800 to have powerful DPM resolution. In addition, its compact size makes it ideal for use in industrial environment with limited space. The IP65 protection rating also ensures that it can handle various harsh working environments.
HF800 is also equipped with DataMax software, as well as AutoLearn function. The user can complete image setting with just one button, a significant convenience for any bar code reader.
What barcode types can the Honeywell HF800ER read?
The Honeywell HF800ER reads all standard 1D barcodes including Code 39 and UPC, as well as 2D codes such as QR Code, Data Matrix, Maxicode, and Aztec. It also supports PDF417 symbology, making it versatile for diverse industrial applications. We offer the HF800ER with extended range focus capability, ideal for applications requiring variable read distances.
Is the HF800ER suitable for harsh manufacturing environments?
Yes, the HF800ER is specifically designed for harsh industrial environments with an IP65 protection rating, which protects against dust and water ingress. Its compact design and durable zinc alloy housing make it ideal for production data tracking in PCB and precision electronic parts manufacturing where space is limited. The device operates reliably in temperatures from 0°C to 50°C.
What are the imaging specifications of the HF800ER?
The HF800ER features an 838×640 CMOS imager with 500k pixel resolution and a global shutter, capable of capturing images at 60 fps for high-quality data collection. This imaging performance enables reliable reading of small codes, including 4mil and 5mil Code 39 barcodes at various distances. The extended range (ER) model variant provides optimal performance for applications requiring longer read distances.
What connectivity and communication options does the HF800ER provide?
The HF800ER offers multiple communication interfaces including RS232, RS485, and Ethernet ports, supporting both Master and Slave network modes for flexible system integration. It includes two photoelectric dispersed inputs and outputs with programmable definitions, plus status indication via five-status LED and buzzer feedback. This makes it compatible with warehouse management systems and manufacturing execution systems available from us.
What power requirements does the HF800ER have?
The HF800ER operates on standard 10VDC to 30VDC power input with a maximum power consumption of 5W, making it efficient for continuous production environments. The wide voltage range accommodates various industrial power supply configurations. Contact us today for integration guidance on powering the HF800ER in your facility.
Does the HF800ER include aiming and feedback features?
Yes, the HF800ER includes both laser and LED aiming devices—0° laser indicator for horizontal mounting and 90° LED indicator for vertical mounting—to assist operators in targeting barcodes. It features a learning button for quick configuration settings and provides five-status LED plus audible buzzer feedback to confirm successful reads. The vertical mount is included with your purchase from us.
The Honeywell HF800ER-R1-1V Barcode Scanner is also known as
HSM-HF800ERR11V
or HF800ERR11V.
Full specifications (PDF)
