What barcode types can the Honeywell HF800HD-R1-1V scanner read?
The HF800HD reads both 1D and 2D barcodes, including Code 39, UPC, PDF417, QR Code, DataMatrix, Maxicode, and Aztec codes. This versatility makes it ideal for warehouses and manufacturing environments that handle diverse barcode formats. We offer this model as a complete fixed-mount solution with vertical mounting hardware included.
What is the read distance and field of view for the HF800HD model?
The HF800HD is optimized for close-range to mid-range scanning, with typical performance reading 4mil Code 39 at 50-80mm (0°) and 25-55mm (90°), and 13mil UPC at 40-175mm (0°) and 25-150mm (90°). The HD designation indicates this is the high-definition model with standard focus capabilities. For specific application requirements, contact us today to ensure this model matches your scanning distance needs.
Is the HF800HD suitable for harsh warehouse and manufacturing environments?
Yes, the HF800HD is built for industrial use with an IP65 rating, zinc alloy housing, and operating temperature range of 0°C to 50°C. It features robust construction designed to withstand warehouse and manufacturing conditions while maintaining reliable performance. Available from us with mounting hardware for immediate deployment in demanding environments.
What connectivity and integration options does the HF800HD offer?
The HF800HD provides multiple communication ports including RS232, RS485, and Ethernet, allowing flexible integration into existing warehouse management and manufacturing systems. It supports Master/Slave network modes and includes 2 photoelectric dispersed inputs and outputs for triggering external devices and accessories. This makes it easy to integrate into your facility's automation infrastructure—contact us today for integration support.
How much power does the HF800HD require, and what are the power specifications?
The HF800HD operates on standard 10VDC-30VDC power with maximum consumption of 5W, making it efficient and easy to integrate into existing power infrastructure. The wide voltage range accommodates various industrial power supplies without requiring additional equipment. Visit barcodesinc.com or contact us today for power supply recommendations specific to your installation.
What mounting options are available for the HF800HD scanner?
The HF800HD is available in both horizontal (54.5×52.5×29mm, 210g) and vertical (73.2×52.5×29mm, 265g) configurations, with the R1-1V model including vertical mount hardware. The compact form factor and included mounting bracket make installation straightforward in conveyor lines, sorting systems, and manufacturing workstations. We offer this complete package ready for deployment—visit barcodesinc.com to order today.
The Honeywell HF800HD-R1-1V Barcode Scanner is also known as
HSM-HF800HDR11V
or HF800HDR11V.
