Datalogic Gryphon GM4500 Barcode Scanner Model Overview
The GRYPHON™ I GBT/GM4500 2D scanner by Datalogic is a premium, award-winning wireless scanner designed for general-purpose applications. Featuring state-of-the-art imaging technology with a Megapixel sensor and white-illumination 2D capability, it ensures outstanding performance in any environment. The innovative wireless charging system enhances reliability and reduces maintenance costs, making it a perfect choice for retail, healthcare, and light manufacturing sectors. With its ergonomic design and user-friendly features, including motion-sensing technology and disinfectant-ready enclosures, the Gryphon 4500 promises seamless operation and top-tier productivity.
Key Features
1 MP optics for superior scanning and depth of field
Wireless charging with inductive technology
Datalogic's Motionix™ for automatic mode switching
Omnidirectional reading of 1D and 2D codes
Disinfectant-Ready enclosures for easy cleaning in healthcare settings
Specifications
Dimensions: 16.6 x 6.8 x 10.9 cm
Weight: 235 g
Battery: Lithium-Ion, 3250 mAh
Communication: Bluetooth® 4.0 or Datalogic STAR Cordless
The Gryphon™ 4500 series represents the premium range of hand held scanners from Datalogic for general purpose applications. Designed with people in mind, the Gryphon 4500 series stands out with its elegant and cutting edge design, the unchallenged ergonomics, and features the most advanced Megapixel sensor with white-illumination 2D technology for outstanding performance.
WIRELESS COMMUNICATIONS
Featuring Bluetooth® wireless technology (GBT model) or narrow band radio communications with Datalogic's STAR Cordless System™ (GM model), the Gryphon 4500 wireless readers provide maximum flexibility to solve any end user application with the best technical solution.
WIRELESS CHARGING
One of the most important technical innovations that the Gryphon 4500 wireless scanners achieve is the battery recharge through an inductive charging system, which enhances the reliability of the entire solution, lowering the total cost of ownership because it eliminates the need for contacts' cleaning and maintenance procedures. The maximum reliability offered by the Gryphon wireless charging technology means 24/7 activities with no stops for maintenance or repair and top-level operating productivity and performance.
SIMPLE TO USE AND DEPLOY
The Gryphon I 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes. High Density (HD) models are available for reading smaller, condensed codes as well as a dedicated version with red illumination optics to support Digital Watermarking.
Datalogic's Motionix™ motion-sensing technology enables the scanner to intuitively switch into hand held mode when the device is picked up. When placed back into the stand, it seamlessly returns to stand mode. The adjustable position cradle provides the flexibility to use the scanner in presentation or stand mode while it's charging.
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top Best Barcode Scanner Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top Bluetooth Barcode Scanner Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top Cables, Connectors, and Adapters Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top Docks and Cradles Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top Imager Barcode Scanner Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top Miscellaneous Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top QR Barcode Scanner Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top Scanner Accessories Purchased With Datalogic GM4500-HC-910K10-B
Cable, Datalogic Gryphon 4500,RS-232, 9 Pin Female, Straight, CAB-350 (Power Supply available on pin 9 of the connector or through external power supply), 6 ft.
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$671.63
Top iPhone, iPad and Android Barcode Scanner Purchased With Datalogic GM4500-HC-910K10-B
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
What barcode types can the Datalogic GM4500-HC scan?
The GM4500-HC is an omnidirectional 2D area imager that reads all common 1D and 2D barcodes, including Code 39, EAN-13, Data Matrix, PDF417, QR codes, and postal codes plus stacked and composite codes. Its advanced imager technology delivers quick, reliable scanning across general purpose and healthcare applications. We offer this scanner with standard or high-density resolution options to match your specific barcode requirements.
Does the GM4500-HC support wireless connectivity?
Yes, the GM4500-HC-910K10-B model features 910 MHz cordless wireless technology with Datalogic's STAR system, providing maximum flexibility for mobile scanning operations. The scanner also supports Bluetooth wireless technology as an alternative connectivity option. Both wireless solutions include batch mode capability with over 1200 codes stored in memory, allowing workers to scan offline and sync data later.
What is the wireless charging system on the GM4500-HC?
The GM4500-HC features Datalogic's innovative contactless wireless charging system, which enhances reliability and eliminates wear from traditional charging connectors. The included WLC4090-HC-910 base station supports Datalogic's patented 2-position cradle with 'Scan-While-Charging' capability, allowing operators to charge the scanner while actively using it. This design significantly extends the lifespan of the entire solution.
Is the GM4500-HC suitable for healthcare environments?
Yes, the GM4500-HC is specifically designed for healthcare applications with disinfectant-ready enclosures treated with anti-microbial additives (ISO22196 and JISZ 2801 compliant). The scanner includes vibration feedback options ideal for quiet bedside patient care environments, and Datalogic's 'Green Spot' technology provides visual good-read confirmation without audible alerts. We offer this model as part of our healthcare barcode scanner lineup available from barcodesinc.com.
What is the reading range and depth of field for the GM4500-HC?
The GM4500-HC Standard Range model delivers variable reading distances depending on barcode type and size—for example, Code 39 at 10 mils reads from 0.8 to 22.8 inches, while EAN-13 at 13 mils reads up to 27.9 inches. The scanner features advanced motion tolerance optics rated at 35 inches per second and supports reading angles of ±65° pitch and yaw with 360° roll capability. Typical depth of field is determined by symbol length, scan angle, print contrast ratio, and ambient light conditions.
What accessories and configurations are included in the GM4500-HC kit?
The GM4500-HC-910K10-B BPOC (Barcode Point-of-Care) kit includes the scanner, WLC4090-HC-910 wireless charging base station, and USB cable (Part# 90A052278) for complete out-of-box deployment. Additional compatible accessories available from us include the RBP-GM40 removable battery pack for extended operations and the CHR-GM40-WT charging-only base station. Contact us today at barcodesinc.com to configure the right bundle for your warehouse or healthcare facility.
The Datalogic GM4500-HC-910K10-B Barcode Scanner is also known as
DTL-GM4500HC910K10B
or GM4500HC910K10B.
Full specifications (PDF)
