DataLogic Gryphon GM4500 Barcode Scanner Model Overview
The GRYPHON™ I GBT/GM4500 2D scanner by Datalogic is a premium, award-winning wireless scanner designed for general-purpose applications. Featuring state-of-the-art imaging technology with a Megapixel sensor and white-illumination 2D capability, it ensures outstanding performance in any environment. The innovative wireless charging system enhances reliability and reduces maintenance costs, making it a perfect choice for retail, healthcare, and light manufacturing sectors. With its ergonomic design and user-friendly features, including motion-sensing technology and disinfectant-ready enclosures, the Gryphon 4500 promises seamless operation and top-tier productivity.
Key Features
1 MP optics for superior scanning and depth of field
Wireless charging with inductive technology
Datalogic's Motionix™ for automatic mode switching
Omnidirectional reading of 1D and 2D codes
Disinfectant-Ready enclosures for easy cleaning in healthcare settings
Specifications
Dimensions: 16.6 x 6.8 x 10.9 cm
Weight: 235 g
Battery: Lithium-Ion, 3250 mAh
Communication: Bluetooth® 4.0 or Datalogic STAR Cordless
The Gryphon™ 4500 series represents the premium range of hand held scanners from Datalogic for general purpose applications. Designed with people in mind, the Gryphon 4500 series stands out with its elegant and cutting edge design, the unchallenged ergonomics, and features the most advanced Megapixel sensor with white-illumination 2D technology for outstanding performance.
WIRELESS COMMUNICATIONS
Featuring Bluetooth® wireless technology (GBT model) or narrow band radio communications with Datalogic's STAR Cordless System™ (GM model), the Gryphon 4500 wireless readers provide maximum flexibility to solve any end user application with the best technical solution.
WIRELESS CHARGING
One of the most important technical innovations that the Gryphon 4500 wireless scanners achieve is the battery recharge through an inductive charging system, which enhances the reliability of the entire solution, lowering the total cost of ownership because it eliminates the need for contacts' cleaning and maintenance procedures. The maximum reliability offered by the Gryphon wireless charging technology means 24/7 activities with no stops for maintenance or repair and top-level operating productivity and performance.
SIMPLE TO USE AND DEPLOY
The Gryphon I 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes. High Density (HD) models are available for reading smaller, condensed codes as well as a dedicated version with red illumination optics to support Digital Watermarking.
Datalogic's Motionix™ motion-sensing technology enables the scanner to intuitively switch into hand held mode when the device is picked up. When placed back into the stand, it seamlessly returns to stand mode. The adjustable position cradle provides the flexibility to use the scanner in presentation or stand mode while it's charging.
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top Best Barcode Scanner Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top Bluetooth Barcode Scanner Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top Cables, Connectors, and Adapters Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top Docks and Cradles Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top Imager Barcode Scanner Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top Miscellaneous Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top QR Barcode Scanner Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top Scanner Accessories Purchased With Datalogic GM4500-BK-910K1
Cable, Datalogic Gryphon 4500,RS-232, 9 Pin Female, Straight, CAB-350 (Power Supply available on pin 9 of the connector or through external power supply), 6 ft.
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
In Stock
$692.27
Top iPhone, iPad and Android Barcode Scanner Purchased With Datalogic GM4500-BK-910K1
Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Bluetooth, Black. Kit inc. Scanner, WLC4090-BK-BT base and USB cable 90A052258
What barcode types can the DataLogic GM4500 scanner read?
The DataLogic GM4500 features an omnidirectional 2D area imager that reads all common 1D and 2D barcodes, including Code 39, EAN-13, PDF417, Data Matrix, and QR codes. This makes it ideal for general purpose warehouse and logistics applications where you need flexibility across multiple barcode formats. We offer the GM4500 in several configurations to match your specific scanning needs.
Does the GM4500 have wireless charging capability?
Yes, the GM4500 is the first Datalogic scanner to feature an innovative contactless wireless charging system through the included WLC4090-BK-910 charging base. This wireless charging enhances overall system reliability and eliminates wear from traditional charging contacts. The kit available from us includes the scanner, wireless charging cradle, and USB cable for immediate deployment.
What wireless connectivity options does the GM4500 support?
The GM4500 supports both Bluetooth 4.0 wireless technology and Datalogic's proprietary STAR cordless system operating at 910 MHz (as indicated by the -910 designation in the model number). This dual connectivity provides maximum flexibility for different warehouse environments and integration requirements. Contact us today to discuss which wireless option best fits your operation.
How durable is the GM4500 for warehouse environments?
The GM4500 withstands drops from 1.8 meters and operates reliably in temperatures from 0 to 50°C, making it well-suited for demanding warehouse and logistics environments. It also features a 35 IPS motion tolerance for fast-moving scanning applications. These specifications ensure consistent performance in typical industrial settings where we see it deployed most often.
What is the maximum reading range of the GM4500?
Reading range varies by barcode type and resolution. For example, in Standard Range mode, Code 39 at 10 mils reads from 0.8 to 22.8 inches, while EAN-13 at 13 mils reads from 0.4 to 27.9 inches. The GM4500 also offers High Density resolution options for reading smaller barcodes at closer distances. Visit barcodesinc.com for detailed specification sheets covering all barcode types and ranges.
Is the GM4500 kit ready to use out of the box?
Yes, the GM4500-BK-910K1 kit includes everything needed to get started: the scanner, the WLC4090-BK-910 wireless charging base, and a USB cable. The kit is designed for immediate deployment in your warehouse or logistics operation without requiring additional purchases. We stock this complete kit and can help with setup and integration—contact us today for assistance.
