Datalogic GBT4500-BK-DGM-WLC Barcode Scanner

Datalogic Gryphon GBT4500 - Cordless Barcode Scanner, Datalogic Gryphon GBT4500, 2D Imager, Single Dot, General Purpose, Handheld, Wireless Charging, Bluetooth, SCANNER ONLY, Black, Digimarc Barcodes Supported

Connectivity

Cordless

Form Factor

Handheld

Interface Options

Bluetooth

Scanner Capability

Scanner Type

Imager

1 MP optics for superior scanning and Depth of Field
Datalogic distinctive technology with highly visible white-illumination and 4-Dot aimer with center cross for targeted scanning
Datalogic's 'Green Spot' technology, exclusive 3GL™ (3 Green Lights) and Vibration for superior good-read feedback
Motionix™ motion-sensing technology for seamless reading mode transitions
Image capture and document scanning capabilities
Omnidirectional reading of 1D, 2D and postal codes plus stacked, composite codes and dot codes; Digital Watermarks on specific models
Choice of Bluetooth wireless technology version or Datalogic's STAR Cordless System (radio frequencies available in 433 MHz or 910 MHz)
Wireless battery charging system
Choice of WLC4090 adjustable position cradle with Scan-While-Charging capability or WLC4190 sleek desk/wall cradle with USB Type C connectivity
Disinfectant-Ready enclosures withstand daily cleaning with harsh disinfectant solutions
Specific black models with enclosures treated with anti-microbial additives available (ISO22196 compliant)
EASEOFCARE Service Plans offer a wide range of service options to protect your investment, ensuring maximum productivity and ROI

Need a different version? See all Datalogic Gryphon I GBT4500 Barcode Scanners

$501.58

Chat Now for Qty Discount

3-year Premium Plus ($68.01)

3-year Premium ($18.51)

No Support

Add to Quote

Datalogic GBT4500-BK-DGM-WLC Barcode Scanner

Overview

Full specifications (PDF)

Datalogic Gryphon I GBT4500 Barcode Scanner Model Overview

Designed for general purpose applications, the GBT4500 2D wireless scanners are the latest in Datalogic's popular Gryphon series. For the first time Datalogic brings an innovative, contactless, wireless charging system that enhances the reliability of the entire solution. Designed with an omnidirectional imager that allows for quick scanning on all common 1D and 2D barcodes. With either Bluetooth wireless technology or Datalogic's STAR cordless system these barcodes scanners provide maximum flexibility to any end user application.

Datalogic GBT4500-BK-DGM-WLC Barcode Scanner Overview

IMAGING TECHNOLOGY

The Gryphon 4500 series represents the premium range of handheld scanners from Datalogic for value added applications. Designed with people in mind, the Gryphon 4500 series stands out with its elegant and cutting edge design, the unchallenged ergonomics, and features the most advanced Megapixel sensor with white-illumination 2D technology for outstanding performance.

SIMPLE TO USE AND DEPLOY

The Gryphon I 4500 omnidirectional imager provides snappy reading performance on all common 1D and 2D codes as well as postal, stacked, and composite codes like PDF417. High Density (HD) models are also available for reading smaller, condensed codes. A dedicated version with red illumination optics reads Digital Watermarking. For mobile marketing or ticketing applications, this imager also offers excellent performance when reading bar codes from mobile devices. The enhanced optics offer improved motion tolerance and first pass decoding of fast moving codes.

READY TO BE REGULARLY CLEANED AND DISINFECTED

Most working environments now have requirements that scanners need to be regularly cleaned and disinfected. The Gryphon 4500 series utilizes Disinfectant-Ready enclosures, designed to withstand regular daily cleaning with harsh disinfectant solutions commonly used in a healthcare environment.

WIRELESS COMMUNICATIONS AND WIRELESS CHARGING

Featuring Bluetooth® wireless technology (GBT models) or narrow band radio communications with Datalogic's STAR Cordless System™ (GM models), the Gryphon 4500 wireless readers provide maximum flexibility to solve any end user application with the best technical solution. One of the most important technical innovations that the Gryphon 4500 wireless scanners achieve is the battery recharge through an inductive charging system, lowering the total cost of ownership because it eliminates the need for contacts' cleaning and maintenance procedures. The maximum reliability offered by the wireless charging technology means 24/7 activities with no stops for maintenance or repair and toplevel operating productivity and performance.

Detailed Specs

Full specifications (PDF)

Technical Information

Connectivity Technology:

Wireless

Scanning Capability:

Barcode Symbology Supported:

1D / Linear Codes:

Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes.

2D Codes:

Aztec Code
China Han Xin Code
Data Matrix
MaxiCode
Micro QR Code
QR Code
Dot Code

Postal Codes:

Australian Post
British Post
China Post
IMB
Japanese Post
KIX Post
Planet Code
Postnet
Royal Mail Code (RM4SCC)

Stacked Codes:

EAN/JAN Composites
GS1 DataBar Composites
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
MacroPDF
MicroPDF417
PDF417
UPC A/E Composites

Digital Watermarking:

Digimarc Barcodes

Light Source:

Laser

Image Sensor Type:

Imager

Scan Pattern:

Omni-directional

Reading Angle (Skew):

65°

Reading Angle (Pitch):

65°

Reading Angle (Roll):

360°

Motion Tolerance:

35 in/s

Image Formats:

BMP
JPEG
TIFF

Maximum Ambient Light:

100000 lux

Drop Specification:

Withstands repeated drops from 1.8 m / 6.0 ft onto a concrete surface.

Minimum Print Contrast:

15%

Image Sensor Resolution:

1280 x 800

Illumination Type:

LED

Illumination Color:

Red

Network & Communication

Bluetooth:

Yes

Radio Frequency:

Yes

Power Description

Input Current:

330 mA

Battery Information

Battery Included:

Yes

Battery Chemistry:

Lithium Ion (Li-Ion)

Battery Capacity:

3250 mAh

Environmental Conditions

Operating Temperature:

122°F (50°C)

Storage Temperature:

-40°F (-40°C) to 158°F (70°C)

Humidity (Non-condensing):

95%

Physical Characteristics

Form Factor:

Handheld

Product Color:

Black

Miscellaneous

Ingress Protection (IP) Rating:

IP52

Application/Usage:

Light/Clean Manufacturing
Retail
Healthcare
Transportation
Commercial Service

Warranty

Limited Warranty:

3 Year

Item Numbers

UNSPSC: 43211701
