Full specifications (PDF)
Connectivity Technology:
Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes.
- Aztec Code
- China Han Xin Code
- Data Matrix
- MaxiCode
- Micro QR Code
- QR Code
- Australian Post
- British Post
- China Post
- IMB
- Japanese Post
- KIX Post
- Planet Code
- Postnet
- Royal Mail Code (RM4SCC)
- EAN/JAN Composites
- GS1 DataBar Composites
- GS1 DataBar Expanded Stacked
- GS1 DataBar Stacked
- GS1 DataBar Stacked Omnidirectional
- MacroPDF
- MicroPDF417
- PDF417
- UPC A/E Composites
- Digimarc Barcodes
Light Source:
Laser
Image Sensor Type:
Imager
Depth of Field:
- 5.0 to 15.0 cm / 2.0 to 5.9 in @ Code 39
- 0.5 to 25.0 cm / 0.2 to 9.8 in @ Code 39
- 2.0 to 27.0 cm / 0.8 to 10.6 in @ Data Matrix
- 2.0 to 23.5 cm / 0.8 to 9.3 in @ Data Matrix
- 1.0 to 40.0 cm / 0.4 to 15.7 in @ EAN-13
- 3.0 to 12.0 cm / 1.2 to 4.7 in @ EAN-13
- 0.5 to 31.0 cm / 0.2 to 12.2 in @ PDF417
- 2.0 to 25.0 cm / 0.8 to 9.8 in @ PDF417
Scan Pattern:
- Area
- Omni-directional
Scanner Range:
High Density
Scanning Distance:
15.70"
Features:
- Beep
- Vibration
- Notification LED
Cable Type Included:
USB
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Motion Tolerance:
35 in/s
Image Formats:
- BMP
- JPEG
- TIFF
Maximum Ambient Light:
100000 lux
Drop Specification:
- 3Withstands repeated drops from 1.8 m / 6.0 ft onto a concrete surface.
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
3 mil
Maximum Element Resolution (Code 39):
5 mil
Minimum Element Resolution (DataMatrix):
5 mil
Maximum Element Resolution (DataMatrix):
10 mil
Minimum Element Resolution (PDF417):
4 mil
Maximum Element Resolution (PDF417):
10 mil
Image Sensor Resolution:
1280 x 800
Illumination Type:
LED
Illumination Color:
White
Air Electrostatic Discharge (+/-):
16kV
