Datalogic 94R211101 Data Terminal

Part Number: 94R211101
Model: Rhino II
3-year Premium Plus ($961.96)
3-year Premium ($686.96)
No Support
Add to My Shopping List Add to Compare
$3,648.17
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Wireless
Processor Core
Quad-core (4 Core)
Processor Speed
1 GHz
Standard Memory
1 GB

Product Description:

  Data Terminal, Datalogic Rhino II Rugged Vehicle Mount Computer, Resistive Standard, Freescale, Quad-core (4 Core) 1 GHz, 1GB RAM/32GB Flash Memory, 10.4" Display, XGA, 1024 x 768, IEEE 802.11a/b/g/n/Serial/USB, 12-48 Vdc, Internal Antenna, 4GB RAM/32GB Flash, Laird M2SD50, QMX, Windows Embedded Compact 7
Explore all Datalogic Rhino II Data Terminals
Add to Quote
Datalogic 94R211101 Data Terminal
Datalogic 94R211101 Data Terminal
Datalogic 94R211101 Data Terminal
Datalogic 94R211101 Data Terminal
Datalogic 94R211101 Data Terminal Datalogic 94R211101 Data Terminal Datalogic 94R211101 Data Terminal

Full specifications (PDF)

Datalogic Rhino II Data Terminal Model Overview

The Rhino IITM Vehicle Mounted Computer is the ultimate rugged solution for warehouse management, designed to perform in the harshest environments. With both 10" and 12" display options, this computer features a robust design sealed to IP65/IP67 standards, making it ideal for cold storage and outdoor use. Its integrated display heater ensures functionality even in extreme cold, while the capacitive touch screen offers glove support for maximum usability. Tailored for enhanced productivity, the Rhino II minimizes errors during critical warehouse operations such as receiving, picking, and shipping.
Key Features:
  • Choice of Microsoft Operating Systems or Android™ 7.1
  • 10 inch or 12 inch high resolution color display
  • Anti-glare multi-touch screen with gloves support
  • IP65/IP67 protection class
  • Wide operating temperature range: -20 to 55 °C
  • Support for tethered and cordless barcode scanners
  • Multiple mounting options for versatile usage
  • EASEOFCARE Service Plans available for protection

Specifications:
  • Wireless Communications:
    • WLAN: IEEE 802.11 a/b/g/n
    • Bluetooth® Wireless Technology v4.0
  • Dimensions:
    • 10 inch: 27.8 x 22.3 x 6.4 cm
    • 12 inch: 32.4 x 25.1 x 7.1 cm
  • Operating Temperature:
    • Operating: -20 to 55 °C
    • Freezer model: -30 °C
  • Interfaces:
    • 1 x Ethernet 10/100/1000 Mbps
    • 3 x USB 2.0 Type A
    • 1 x USB 3.0 Type A
  • Weight:
    • 10 inch Standard Models: 3.6 Kg
    • 12 inch Standard Models: 4.7 Kg
  • Warranty: 1-Year Factory Warranty
Datalogic 94R211101 Data Terminal Overview

The Rhino II™ vehicle mount computers, available in both 10" and 12" display sizes, set the standard for ruggedness in the warehouse. A sealed design tested to IP65/IP67 ensures operation in the toughest environments. A dedicated freezer-rated model with integrated display heater allows use in and out of cold storage. The capacitive touch models feature 3 mm anti-glare armored glass, while still allowing use of gloves.

Tailored for warehouse management, the Rhino vehicle mount computer increases productivity with its easy integration of PowerScan or other automated data collection devices.

The Rhino II offers a wide choice of Operating Systems: Windows Embedded Compact 7 (WEC7), Windows Embedded Standard 7, Windows 10 IoT Enterprise and the new Android™ 7.1

Full specifications (PDF)
Technical Information
Connectivity Technology:
Wireless
Processor & Chipset
Processor Core:
Quad-core (4 Core)
Processor Speed:
1 GHz
Memory
Standard Memory:
1 GB
Flash Memory:
32 GB
Memory Card Supported:
SDHC
Display & Graphics
Screen Size:
10.4"
Graphics Modes:
XGA
Touchscreen:
Yes
Touchscreen Type:
Projected Capacitive
Display Resolution:
1024 x 768
Network & Communication
Bluetooth:
Yes
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11a/b/g/n
Interfaces/Ports
Network (RJ-45):
Yes
Serial:
Yes
USB:
Yes
Power Description
Power Source:
Power Supply
Software
Operating System:
Windows Embedded Compact 7
Physical Characteristics
Weight (Approximate):
7.94 lb
Miscellaneous
Certifications & Standards:
  • CE
  • FCC
  • IP65
  • IP67
  • EN 60721-3-5: 1998
Environmentally Friendly:
Yes
Environmental Compliance:
  • Restriction of Hazardous Substances (RoHS)
  • Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43211505

Recommended Accessories

Category

  • Computer Accessories (3)
  • Data Networking Device (3)
  • Datalogic Fixed/Vehicle Mount Data Terminal (38)
  • Forklift Fixed/Vehicle Mount Data Terminal (23)
  • General Software (5)
  • Mobile Computer Accessories (4)
  • Network Antennas (1)
  • Spare Parts (4)
  • Terminal Accessories (1)
  • Vehicle Fixed/Vehicle Mount Data Terminal (23)

Recommended Accessories for Model: Datalogic 94R211101 Data Terminal

Top Computer Accessories Purchased With Datalogic 94R211101

Top Data Networking Device Purchased With Datalogic 94R211101

  • Datalogic 94R722255 Data Networking
    Datalogic 94R722255 Data Networking
    Datalogic Rhino II Rugged Vehicle Mount Computer, 12" CAP HB, VDC 12-48V, INT ANT, UPS, 64GB, CFAST, SUMMIT PE15N, I5 CORE 8GB, WIN 10 IOT
    Item on backorder — chat for lead time
    $7,079.63
    Add to Quote
  • Datalogic 94R211235 Data Networking
    Datalogic 94R211235 Data Networking
    Datalogic Rhino II Forklife Screen, 10" RES STD, VDC 12-48V INT ANT, 32GB, SUMMIT PE15N, QC, 4GB, WIN IOT
    Item on backorder — chat for lead time
    $4,185.33
    Add to Quote
  • Datalogic 94R211225 Data Networking
    Datalogic 94R211225 Data Networking
    Datalogic Rhino II Forklife Screen, 10" RES STD, VDC 12-48V INT ANT, 32GB, SUMMIT PE15N, DC, 4GB, WIN IOT
    Item on backorder — chat for lead time
    $3,886.84
    Add to Quote

Top Datalogic Fixed/Vehicle Mount Data Terminal Purchased With Datalogic 94R211101

See All Datalogic Fixed/Vehicle Mount Data Terminal for Datalogic 94R211101 Data Terminal >

Top Forklift Fixed/Vehicle Mount Data Terminal Purchased With Datalogic 94R211101

  • Datalogic 94R511225 Data Terminal
    Datalogic 94R511225 Data Terminal
    Data Terminal, Datalogic Rhino II Rugged Vehicle Mount Computer, Capacitive Standard, Freescale, Quad-core (4 Core) 1 GHz, 1GB RAM/32GB Flash Memory, 12.1" Display, XGA, 1024 x 768, IEEE 802.11a/b/g/n/Serial/USB, Windows 10 IoT, 12-48 Vdc, Internal Antenna, Summit PE15N, E3826 DC
    Item on backorder — chat for lead time
    $3,663.57
    Add to Quote
  • Datalogic 94R521235 Data Terminal
    Datalogic 94R521235 Data Terminal
    Data Terminal, Datalogic Rhino II Rugged Vehicle Mount Computer, Capacitive Standard, Freescale, Quad-core (4 Core) 1 GHz, 12.1" Display, 12-48 Vdc, 1024 x 768, Internal Antenna, Windows 10 IoT, Enterprise Quad Core/1.9GHz Processor, 4GB RAM/32GB Flash, Laird M2SD50, Summit PE15N, 802.11a/b/g/n, Wi-Fi, Bluetooth 4.0, DC Power Cable
    Item on backorder — chat for lead time
    $4,725.13
    Add to Quote
  • Datalogic 94R511101 Data Terminal
    Datalogic 94R511101 Data Terminal
    Data Terminal, Datalogic Rhino II Rugged Vehicle Mount Computer, Capacitive Standard, Freescale, Quad-core (4 Core) 1 GHz, 1GB RAM/32GB Flash Memory, 12.1" Display, XGA, 1024 x 768, IEEE 802.11a/b/g/n/Serial/USB, Windows Embedded Compact 7, 12-48 Vdc, Internal Antenna, Laird M2SD50, QMX
    Item on backorder — chat for lead time
    $3,783.72
    Add to Quote
See All Forklift Fixed/Vehicle Mount Data Terminal for Datalogic 94R211101 Data Terminal >

Top General Software Purchased With Datalogic 94R211101

  • Datalogic 94A101121 Software
    Datalogic 94A101121 Software
    Software, Datalogic Rhino II, StayLinked SmartTE With 1 Year Maintenance, 1 License, Compatible with PC and Mac
    In Stock
    $170.41
    Add to Quote
  • Datalogic 95A101135 Software
    Datalogic 95A101135 Software
    Software, Datalogic Joya Touch A6, Ivanti Android Velocity TE Client, 1 License, Powered by Wavelink, WL # 140-LI-VELOCTE, Requires Maintenance P/N ZSS5VELTE1
    Item on backorder — chat for lead time
    $232.20
    Add to Quote
  • Datalogic ZSS5VELTE1 Software
    Datalogic ZSS5VELTE1 Software
    Software, Datalogic Joya Touch A6, Ivanti Android Velocity TE Client, 1 Year of Maintenance Included, Powered By Wavelink, WL # 140-MA-VELOCTE
    In Stock
    $112.25
    Add to Quote
See All General Software for Datalogic 94R211101 Data Terminal >

Top Mobile Computer Accessories Purchased With Datalogic 94R211101

See All Mobile Computer Accessories for Datalogic 94R211101 Data Terminal >

Top Network Antennas Purchased With Datalogic 94R211101

  • Datalogic 94ACC0163 Data Terminal
    Datalogic 94ACC0163 Data Terminal
    Antenna, Datalogic Rhino II, Roof Mount Dome, 4 dBi, 2.4 - 5.9 GHz, Top Cover, 3 Meter Cable, Certified for 10 Inch Models Only
    Item on backorder — chat for lead time
    $596.12
    Add to Quote

Top Spare Parts Purchased With Datalogic 94R211101

See All Spare Parts for Datalogic 94R211101 Data Terminal >

Top Terminal Accessories Purchased With Datalogic 94R211101

Top Vehicle Fixed/Vehicle Mount Data Terminal Purchased With Datalogic 94R211101

  • Datalogic 94R511225 Data Terminal
    Datalogic 94R511225 Data Terminal
    Data Terminal, Datalogic Rhino II Rugged Vehicle Mount Computer, Capacitive Standard, Freescale, Quad-core (4 Core) 1 GHz, 1GB RAM/32GB Flash Memory, 12.1" Display, XGA, 1024 x 768, IEEE 802.11a/b/g/n/Serial/USB, Windows 10 IoT, 12-48 Vdc, Internal Antenna, Summit PE15N, E3826 DC
    Item on backorder — chat for lead time
    $3,663.57
    Add to Quote
  • Datalogic 94R521235 Data Terminal
    Datalogic 94R521235 Data Terminal
    Data Terminal, Datalogic Rhino II Rugged Vehicle Mount Computer, Capacitive Standard, Freescale, Quad-core (4 Core) 1 GHz, 12.1" Display, 12-48 Vdc, 1024 x 768, Internal Antenna, Windows 10 IoT, Enterprise Quad Core/1.9GHz Processor, 4GB RAM/32GB Flash, Laird M2SD50, Summit PE15N, 802.11a/b/g/n, Wi-Fi, Bluetooth 4.0, DC Power Cable
    Item on backorder — chat for lead time
    $4,725.13
    Add to Quote
  • Datalogic 94R511101 Data Terminal
    Datalogic 94R511101 Data Terminal
    Data Terminal, Datalogic Rhino II Rugged Vehicle Mount Computer, Capacitive Standard, Freescale, Quad-core (4 Core) 1 GHz, 1GB RAM/32GB Flash Memory, 12.1" Display, XGA, 1024 x 768, IEEE 802.11a/b/g/n/Serial/USB, Windows Embedded Compact 7, 12-48 Vdc, Internal Antenna, Laird M2SD50, QMX
    Item on backorder — chat for lead time
    $3,783.72
    Add to Quote
See All Vehicle Fixed/Vehicle Mount Data Terminal for Datalogic 94R211101 Data Terminal >

Frequently Asked Questions

The Rhino II is purpose-built for warehouse management, increasing productivity through reduced errors during receiving, put-away, picking, and shipping activities. Its rugged design with IP65/IP67 sealed construction and cast aluminum case handles the toughest warehouse environments, while integrated power management and optional battery backup protect against data loss during operations.

Yes, DataLogic offers a dedicated freezer-rated model of the Rhino II with an integrated display heater that allows reliable operation both in and out of cold storage facilities. This specialized variant ensures the terminal functions properly in extended temperature conditions that would disable standard models.

The Rhino II is available in both 10" and 12" display sizes to accommodate different vehicle mounting and space constraints. The 94R211101 model features a 10.4" XGA resistive display with 1024 x 768 resolution, while capacitive touch models include 3mm anti-glare armored glass that allows operation with gloves.

The Rhino II supports IEEE 802.11a/b/g/n wireless networking along with Serial and USB connectivity options. It features an internal antenna and operates on 12-48 Vdc power, with an internal isolated power supply that eliminates the need for external pre-regulators.

This model features a Freescale quad-core processor running at 1 GHz with 4GB RAM and 32GB Flash memory storage. It runs Windows Embedded Compact 7 operating system, providing compatibility with existing warehouse management applications and proven mobile computing performance.

The Rhino II vehicle mount computer is designed to work seamlessly with handheld barcode scanners like DataLogic's PowerScan, allowing quick data entry and location confirmations during warehouse tasks. We offer both the terminal and compatible scanning solutions to create a complete warehouse data capture system—contact us today to configure the right solution for your operation.

The Datalogic 94R211101 Data Terminal is also known as 94R211101
