Zebra LS2208 – Barcode Scanner – Scanner Only

Part Number: LS2208-SR30007R
Model: LS2208
to get Free Ground Shipping on your order.
3-year Premium Plus ($85.35)
3-year Premium ($30.65)
No Support
$131.54

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D
Light Source
Laser
Scan Rate
100 scan/s

Product Description:

  General Purpose Scanners, Zebra LS2208, Laser Scanner, Standard Range, Corded, Twilight Black, Acadia

Zebra LS2208 Barcode Scanner Model Overview

The Zebra LS1203-HD handheld scanner offers exceptional value for daily scanning needs, specifically designed for electronics manufacturers to efficiently read small, high-density 1-D barcodes on PCB assemblies. Its user-friendly ergonomics and robust construction ensure comfort during extensive use while minimizing maintenance costs and downtime. With quick and accurate data capture capabilities right out of the box, employees can start using it with virtually no training. This scanner, recognized for its reliability, enhances productivity on the factory floor and supports integration with existing POS systems.
Key features:
  • Durable Construction: Single board construction designed to withstand 5 ft. drops.
  • Multiple Interfaces: Features RS232, USB, and keyboard wedge for flexibility.
  • Ergonomic Design: Lightweight and balanced for reduced user fatigue.
  • Intuitive Plug-and-Play: Quick setup and minimal training required.
  • High-Quality Scanning: Reads 1-D barcodes accurately in both triggered and Auto-Scan modes.

Specifications:
  • Dimensions: 2.4 in. H x 7.1 in. L x 2.4 in. W (6.2 cm H x 18 cm L x 6 cm W)
  • Weight: Approximately 4.3 oz. (122 g)
  • Operating Temp: 32° to 122°F (0° to 50°C)
  • Storage Temp: -40° to 158°F (-40° to 70°C)
  • Humidity: 5% to 95% relative humidity, non-condensing
  • Scan Rate: 100 scans per second
  • Decode Capability: Supports various 1-D barcode formats such as UPC/EAN and Code 39
  • Power Source: Host power or external power supply
  • Warranty: 3 years against defects in workmanship and materials
Zebra LS2208-SR30007R Barcode Scanner Overview

With over eight million sold, the LS2208 remains our best selling handheld laser scanner. The LS2208 has it all - enterprise class scanning in a very ergonomic and durable lightweight design that delivers all day comfort, an extra-long read range for easy scanning, plus support for everyday 1D bar codes, including high-density. With multiple interfaces, a universal cable and support for keyboards in 97 languages, the LS2208 delivers plug-and-play simplicity in virtually every corner of the world. The LS2208 - the well-proven scanner powering the checkout lines all around the world.

Durable construction

With its patented single board construction, patented frictionless liquid polymer scan element, scratch resistant tempered glass exit window and a stringent drop and tumble specification, the LS2208 delivers reliable all-day, every day operation.

Capture high-density bar codes for greater application flexibility

With just one scanner, you can capture the high density bar codes common on small items. Deploy in every corner of the world With support for 97 international keyboards, the LS2208 is ready for operation in your country, right out of the box.

Class-leading working range

Workers can capture everyday 13 mil UPC bar codes on items that are over 25 in./63.5 cm away, improving productivity and the customer checkout experience.

More decode feedback options

Choose from a variety of options to indicate the successful capture of a bar code: the Direct Decode Indicator (a blinking laser line), a beep tone, a red/green LED indicator - or any combination of the three.

All day comfort your workers can count on

The well-proven ergonomic and lightweight balanced design provides maximum comfort, even in the most scan intensive environments. The result Reduced user fatigue and increased worker productivity.

Flexible handheld or hands-free operation

The optional Intellistand TM enables presentation scanning and allows workers to automatically switch between hands-free and handheld modes in the time it takes to drop the LS2208 into the stand.

Multiple interfaces

No matter what host you need to connect to today or tomorrow, the future proof LS2208 is ready.

Truly plug-and-play

The universal cable connects to any computing environment, practically eliminating setup and training time.

Advanced Data Formatting (ADF)

Format data properly before it is sent to your host computer, eliminating the costly modification of host software

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
1D
Light Source:
Laser
Scan Rate:
100 scan/s
Scan Pattern:
Single Line
Scanner Range:
Short Range
Scanning Distance:
43.10"
Features:
  • Ergonomic Design
  • Beep
  • Notification LED
  • Data Formatter
Reading Angle (Skew):
10°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
60°
Maximum Ambient Light:
86080 lux
Drop Specification:

Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete

Minimum Print Contrast:
20%
Minimum Element Resolution (Code 39):
3 mil
Maximum Element Resolution (Code 39):
40 mil
Air Electrostatic Discharge (+/-):
15kV
Contact Electrostatic Discharge (+/-):
8kV
Interfaces/Ports
Host Interface:
  • Keyboard Wedge
  • USB
  • Serial
  • IBM 46XX
Power Description
Input Current:
175 mA
Standby Current:
90 mA
Environmental Conditions
Operating Temperature:
32°F (0°C) to 122°F (50°C)
Storage Temperature:
-40°F (-40°C) to 158°F (70°C)
Humidity (Non-condensing):
5% to 95%
Physical Characteristics
Form Factor:
Handheld
Color Family:
Black
Product Color:
Black
Durability:
Scratch Resistant
Height:
6"
Width:
2.5"
Depth:
3.3"
Weight (Approximate):
5.29 oz
Miscellaneous
Ingress Protection (IP) Rating:
IP30
Application/Usage:
  • Retail
  • Inventory
  • Loyalty Program
  • Education
  • Asset Tracking
  • Library
  • Self-checkout
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Warranty
Limited Warranty:
5 Year
Item Numbers
UNSPSC: 43211701
