Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
1D
Barcode Symbology Supported:
- Full ASCII
- Discrete 2 of 5
- Codabar
- Code 128
- Code 11
- UPC
- Interleaved 2 of 5
- Code 128 Full ASCII
- Code 39 Trioptic
Light Source:
Laser
Scan Rate:
100 scan/s
Scan Pattern:
Single Line
Scanner Range:
Standard Range
Scanning Distance:
17"
Cable Type Included:
USB
Stand Included:
No
Reading Angle (Skew):
60°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
30°
Maximum Ambient Light:
86111 lux
Drop Specification:
Designed to withstand multiple drops at 5.0 ft./1.5 m to concrete
Minimum Print Contrast:
20%
Minimum Element Resolution (Code 39):
3 mil
Maximum Element Resolution (Code 39):
40 mil
