ADVANCED FIXED RFID READER FOR BUSINESS-CLASS ENVIRONMENTS
The faster your business moves, the more your business-critical applications will demand from an RFID reader. And these days, no one is slowing down their pace of business. So that's where Zebra began with the FX7500 Fixed RFID Reader. We created a new RFID radio technology, purposely designed for faster, more accurate read rates, and more consistent performance. Then we paired that radio with a new, more flexible Linux-based network architecture that integrates the tools and open-standard interfaces you need for fast, easy deployment with your RFID and back-end applications. The result is a fixed RFID reader that sets a new performance standard-delivering peak performance at all times with excellent reader sensitivity and better interference rejection, at a lower cost per read point.
Easy to Deploy, Simple to Manage-In Any Enterprise, Large or Small
Ever wished you could minimize the gap between your technology dream and its reality? Everything about the FX7500 is designed to get your RFID plan off the drawing board and into your business environment, without delays, complications or unexpected costs. Installation is dead simple. Hang the supplied bracket, then snap the reader in place. No outlet nearby? No problem. Integrated Power over Ethernet (PoE) lets you place the FX7500 where it is needed without installing extra outlets-ideal for large open areas.
Once plugged into the network, devices are auto-detected; for most applications, predefined configuration files and a built-in testing tool let you simply verify that your FX7500 readers are up, running and ready to operate. Port configuration options let you deploy exactly the number of read points you need-no need for expensive overlaps. For large scale global deployments, the FX7500 helps reduce costs by conforming out-of-the-box with major worldwide RFID standards and interfaces, including FCC and ETSI EN 302 208, LLRP and Reader Management. IPv6, FIPS and TLS compliance help ensure network security. A built-in USB host port* with select third party adaptors provides easy connectivity with Wi-Fi™ and Bluetooth® networks. Add the FX7500's Auto mode configuration and third-party application hosting capabilities, and you have an unbeatable workhorse that is adaptable to multiple application environments-the ideal platform for your RFID solution.
FEATURES | All-New High Performance Radio Technology
Higher sensitivity, improved interference rejection and echo cancellation means you get the best-in-class dense reader mode performance, up to 1200+ tags/sec in FM0 mode.
The FX7500 features Zebra's new NGE radio technology, which is software-based and designed from the ground up for faster, more accurate read rates and consistent performance even in challenging environments. This innovative radio architecture future-proofs your investment by allowing you to implement upgrades and improvements with minimal additional investment, while the Linux-based network architecture provides flexible integration with your RFID and back-end applications.
The FX7500 supports both PoE (Power over Ethernet) and PoE+ connectivity, along with a DC power supply option, giving you flexibility in how you deploy the reader in your facility. The 4-port configuration with 4 input/4 output connections allows you to integrate multiple antenna zones and control external devices as part of your RFID workflow.
Yes, the FX7500 is built as a rugged fixed RFID reader designed to deliver excellent reader sensitivity and better interference rejection, making it well-suited for demanding warehouse, distribution, and logistics operations where reliable performance is critical. Its advanced radio technology maintains peak performance even in challenging RF environments.
The FX7500 operates on 900 MHz UHF frequency and includes a Japan license station option, allowing you to deploy the reader across different geographic regions with appropriate regulatory compliance. This flexibility makes it suitable for both domestic US operations and international logistics networks.
The software-based radio design allows you to upgrade and improve reader performance through firmware updates rather than requiring hardware replacement, protecting your capital investment over time. Combined with open-standard interfaces and Linux-based architecture, this approach reduces your total cost of ownership while maintaining compatibility with evolving RFID applications and standards.
The FX7500 is designed for business-critical RFID applications including asset tracking, inventory management, people tracking, and product location monitoring in warehouses, distribution centers, and logistics operations. Its fast read rates, accuracy, and cost-effective per-read-point performance make it ideal for high-volume tracking environments where speed and reliability directly impact operational efficiency.
Full specifications (PDF)
