Zebra FS80-CM1207D00K Fixed Barcode Scanner
Part Number:
FS80-CM1207D00K
Model:
FS80
Full specifications (PDF)
Zebra FS80 Fixed Barcode Scanner Model Overview
The FS80 is a high-performance fixed industrial scanner designed for track-and-trace applications in industries requiring high speed, precision, and power.
Key Features:
- Multiple Sensor Options: Available in 5MP, 9MP, 12MP, and 16MP resolutions.
- High-Performance Imaging: Capable of reading barcodes on fast-moving objects at a distance.
- Advanced Illumination & Lens Selection:
- High-powered illumination for various lighting conditions.
- Multiple lenses for optimized field of view (FOV) and depth of field (DOF).
- Smart Processing:
- Uses Intel Atom multi-core processors for faster barcode decoding.
- Can support single-camera and multi-camera configurations.
- Simplified Deployment & Management:
- Reduces the need for multiple conventional scanners.
- Managed via Aurora Focus™ software, allowing easy configuration and monitoring.
- Future Features (Software Update Required):
- Leader & Follower network support
- JavaScript support
- Expanded communication protocols (Ethernet/IP, Modbus, Profinet)
Zebra Integrated Multifunction Light (ZIML)
A high-efficiency illumination system designed for Zebra's industrial scanning solutions.
- Available in Standard & Premium models.
- Features 360-degree status LED indicators and configurable built-in speaker (Premium model only).
- Dual laser aimer for accurate camera positioning (Premium model only).
- Multiple light colors: White, Red, and Infrared.
- Adjustable lens angles (20, 40, 60, 80 degrees) for varied applications.
Software & Compatibility
- Powered by Aurora Focus™ (Version 9.0 or newer).
- Deep Learning OCR (factory-installed or software upgrade).
- Anomaly detection not currently supported.
