VeriFone M420-053-04-NAA-5 Payment Terminal
Full specifications (PDF)
VeriFone V200c Payment Terminal Model Overview
The Verifone V400c is a sleek and sophisticated countertop device designed for businesses that demand efficient, high-performance payment solutions. Perfect for retail, banking, hospitality, and more, this countertop device enhances customer interactions with its vibrant color touchscreen, which supports signature capture. With robust security features including end-to-end encryption, you can focus on providing excellent service while ensuring customer data remains secure.
Key Features:
- Vibrant color touchscreen with signature capture capability
- Faster processing for advanced multimedia usage
- Single cable design minimizes counter clutter
- Supports multiple payment methods: NFC/contactless, EMV, MSR, and mobile wallets
- Multiple peripheral ports and dual SAM slots
- PCI PTS 5.x Approved
- Powered by Verifone Cloud Services for enhanced customization and diagnostics
Specifications:
- Display: 3.5" Color LCD, Capacitive Multi-touch Screen (Resolution: 320 x 480 HVGA)
- Operating System: Verifone Secure OS, Engage VOS2
- Processor: ARM Cortex A9, 600 MHz
- Security: PCI PTS 5.x Approved
- Connectivity: Dial-up, LAN 10/100 Base-T, RS232, USB Type-A
- Card Readers: Magstripe ISO 7810, 7811, 7813; Smart Card EMVCO Approved
- Power: Adapter 11.6VDC, 1.55A
- Dimensions: 190mm L x 80mm W x 70mm H; Weight: 381g
- Operating Temperature: 0° to 50° C (32° to 122° F)
- Storage Temperature: -20° to 60°C (-4° to 140° F)
- Relative Humidity: 5% to 90%, Non-condensing
- Card Slots: 2 SAM
Frequently Asked Questions
What payment card readers does the VeriFone M420 support?
The VeriFone M420-053-04-NAA-5 includes a triple-track magnetic card reader with bi-directional capability and a smart card reader supporting up to 3 SAMs (Security Access Modules). It also features ISO 14443 AB certified contactless payment capability, making it compatible with EMV, magstripe, and contactless transactions. All card readers include software-controllable LED prompts for user guidance.
What connectivity options are available on this VeriFone payment terminal?
This model offers multiple connectivity options including Ethernet (10/100BaseT), Bluetooth, WiFi, and dial connectivity. It supports USB device and host capability for flexible integration into your payment infrastructure. The terminal also features RS-232 and RS-485 serial interfaces, with Power over Ethernet available as an option for simplified installation.
How much memory does the VeriFone M420 have?
The VeriFone M420-053-04-NAA-5 is equipped with 512MB RAM and 512MB Flash storage, providing ample capacity for payment applications and transaction processing. Memory is field-upgradeable via USB Flash memory drives, allowing you to expand storage as your business needs evolve.
What security certifications does this VeriFone terminal have?
The M420 is PCI PED approved and holds EMV Level 1 and Level 2 Type Approvals, ensuring compliance with industry payment security standards. It features advanced encryption including Triple DES and DUKPT, along with Master Session security protocols to protect payment data during transmission and processing.
What is the display type and resolution on the VeriFone M420?
The terminal features a 5.0-inch color LCD capacitive multi-touch screen with LED backlight and 854 x 480 FWVGA resolution. The display uses chemically hardened glass with capacitive technology for durability and responsiveness during high-volume transaction environments.
Can I add signature capture and contactless payment to this terminal?
Yes, both signature capture and contactless payment modules are field-upgradeable options on the M420. The contactless module is ISO 14443 AB certified, and signature capture can be added with an optional non-mechanical stylus pen, allowing you to customize the terminal to your specific business requirements without requiring a complete device replacement.
