VeriFone M420-053-01-NAA-5 Payment Terminal
Full specifications (PDF)
VeriFone V200c Payment Terminal Model Overview
The Verifone V400c is a sleek and sophisticated countertop device designed for businesses that demand efficient, high-performance payment solutions. Perfect for retail, banking, hospitality, and more, this countertop device enhances customer interactions with its vibrant color touchscreen, which supports signature capture. With robust security features including end-to-end encryption, you can focus on providing excellent service while ensuring customer data remains secure.
Key Features:
- Vibrant color touchscreen with signature capture capability
- Faster processing for advanced multimedia usage
- Single cable design minimizes counter clutter
- Supports multiple payment methods: NFC/contactless, EMV, MSR, and mobile wallets
- Multiple peripheral ports and dual SAM slots
- PCI PTS 5.x Approved
- Powered by Verifone Cloud Services for enhanced customization and diagnostics
Specifications:
- Display: 3.5" Color LCD, Capacitive Multi-touch Screen (Resolution: 320 x 480 HVGA)
- Operating System: Verifone Secure OS, Engage VOS2
- Processor: ARM Cortex A9, 600 MHz
- Security: PCI PTS 5.x Approved
- Connectivity: Dial-up, LAN 10/100 Base-T, RS232, USB Type-A
- Card Readers: Magstripe ISO 7810, 7811, 7813; Smart Card EMVCO Approved
- Power: Adapter 11.6VDC, 1.55A
- Dimensions: 190mm L x 80mm W x 70mm H; Weight: 381g
- Operating Temperature: 0° to 50° C (32° to 122° F)
- Storage Temperature: -20° to 60°C (-4° to 140° F)
- Relative Humidity: 5% to 90%, Non-condensing
- Card Slots: 2 SAM
Frequently Asked Questions
What payment card types does the VeriFone M420 support?
The VeriFone M420 supports magnetic stripe cards (triple-track, bi-directional), smart cards with EMV Level 1 and Level 2 Type Approval, and optional contactless payments via ISO 14443 AB certified modules. This makes it compatible with most major payment schemes and card formats used in retail environments.
What are the memory specifications for the VeriFone M420-053-01-NAA-5?
The M420 features 128MB to 256MB of memory configuration with field-upgradeable capabilities via USB Flash memory drives. This memory capacity supports multiple payment applications and secure data storage for transaction processing.
What connectivity options are available on the VeriFone M420?
The M420 offers multiple connectivity options including Ethernet (10/100BaseT), USB (Device and Host capability), serial interfaces (RS-232 and RS-485), and optional field-upgradeable WiFi modules. Power over Ethernet is also available as an option, providing flexibility for various deployment scenarios.
Is the VeriFone M420 PCI compliant and what security features does it include?
Yes, the M420 is PCI PED approved and includes advanced security features such as Master Session encryption, DUKPT, and Triple DES. It also incorporates end-to-end SSL and TLS encryption to protect payment data during transactions.
What applications can run on the VeriFone M420?
The M420 runs on Embedded Linux with VeriFone security enhancements and supports multiple payment applications including Form Agent, IBM EFT, NCR EFT, and a secure browser. The device also supports third-party applications that can coexist securely at hardware and software levels.
What input methods does the VeriFone M420 offer for customer transactions?
The M420 features a recessed 13 laser-etched tactile key keypad plus 4 screen-addressable ATM-style keys for PIN entry and navigation. It also includes a capacitive touch screen with chemically hardened glass and optional field-upgradeable signature capture and stylus pen capabilities.
