Full specifications (PDF)
Encryption:
- Master/Session
- DUKPT
- Triple DES
VeriFone M090-307-05-R Payment Terminal
Part Number:
M090-307-05-R
Model:
MX830
VeriFone MX830 Payment Terminal Model Overview
The VeriFone MX830 Performance Plus payment device is the ultimate solution for multi-lane retail environments. Designed for durability and efficiency, it provides rapid transaction handling and advanced security features. With a user-friendly interface and optional touchscreen capability, the MX830 enhances customer engagement while delivering promotional messages directly to consumers. Its rugged design withstands heavy usage, ensuring reliable performance, while optional upgrades for contactless payments and graphical displays allow retailers to adapt to future demands.
Key Features
- Intuitive interface with recessed keypad for secure PIN entry.
- High-performance processor for efficient handling of transactions.
- Backlit, 16-shade grayscale display to attract consumer attention.
- Modular design to upgrade with contactless payment technology.
- Durable construction with scratch-resistant glass and laser-etched keys.
- Multi-track magnetic card reader for swift and reliable payments.
Specifications
- Processor: 32-bit 200 MHz
- Operating System: Embedded Linux with VeriFone security enhancements
- Memory: 32 MB SDRAM + 32 MB Flash
- Display: 16-shade grayscale, backlit, 14 VGA resolution
- Touch Screen: Optional, with chemically-hardened glass
- Connectivity: USB, Ethernet, Serial Interfaces
- Security: PCI PED approved, EMV Level 1 & 2 compliant, Triple DES encryption
- Dimensions: Compact design for efficient usage
VeriFone M090-307-05-R Payment Terminal Overview
The MX 830 has a familiar intuitive interface and tactile keypad for private PIN entry. More than a PCI PED approved payment system, it helps retailers reach out to consumers with timely, targeted branding and promotional messages on its extremely high-resolution grayscale display. It is the most versatile, economical and durable performer that stands up to heavy use.
Technical Information
Processor & Chipset
Processor Type:
ARM9
Memory
Standard Memory:
32 MB
Flash Memory:
32 MB
Display & Graphics
Screen Mode:
QVGA
Touchscreen:
No
Network & Communication
Ethernet Technology:
Fast Ethernet
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
Serial:
Yes
Keyboard/Keypad
Number of Keys:
17
Software
Operating System:
Linux
Physical Characteristics
Weight (Approximate):
2.55 lb
Miscellaneous
Additional Information:
- Supports animated graphics to capture consumers' attention for advertising quick grab items and delivering other messages
- Economical, powerful payment device for multi-lane and point-of-service environments
Certifications & Standards:
- PCI PED approved
- EMV Level 1 & Level 2 Type Approvals
- Interac
- ISO 14443 AB
Environmentally Friendly:
Yes
Environmental Compliance:
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
Warranty
Limited Warranty:
13 Month
Item Numbers
UNSPSC:
43211720
Recommended Accessories
Category
- Payment Terminal Accessories (2)
Recommended Accessories for Model: VeriFone M090-307-05-R Payment Terminal
Top Payment Terminal Accessories Purchased With VeriFone M090-307-05-R
-
Please Call for Pricing or to Purchase -
VeriFone M090-307-05-R-VSI AccessoryMX830, BASE INTEGRATED PIN PADS WITH VSI FIRMWARE LOADED, REPLACED M090-307-02-R-VSIItem on backorder — chat for lead time$379.08
Frequently Asked Questions
What security encryption does the VeriFone M090-307-05-R support?
The VeriFone M090-307-05-R supports Master/Session, DUKPT, and Triple DES encryption to protect payment transactions. It is PCI PED approved and holds EMV Level 1 & Level 2 Type Approvals, ensuring compliance with current payment security standards. Contact us today to learn more about our security-certified payment terminals.
What connectivity options are available on this VeriFone payment terminal?
This terminal offers multiple connectivity options including Fast Ethernet (10/100BaseT), USB (both Device and Host capability), and Serial interfaces (RS-232, RS-485, and IBM Tailgate). It also supports Power over Ethernet as an option, and WiFi can be added as a field-upgradeable module. We offer flexible configuration options to fit your network environment.
Is the VeriFone M090-307-05-R durable for heavy-use environments?
Yes, the M090-307-05-R is designed for durability with laser-etched keys that preserve letters and numbers, and a touch screen with specially hardened glass that resists scratching. The non-mechanical stylus has no moving parts or electronics to fail, and field-replaceable modules allow you to add contactless payment or emerging technologies without replacing the entire device. Available from us for demanding retail and hospitality environments.
Can contactless payment capability be added to this terminal?
Yes, the VeriFone M090-307-05-R supports ISO 14443 AB certified contactless payments as an optional, field-upgradeable module. This allows you to preserve your initial investment while adding emerging payment technologies when needed. Visit barcodesinc.com to explore contactless-enabled configurations.
What payment card readers does this VeriFone terminal include?
The M090-307-05-R includes a triple-track, bi-directional magnetic card reader with software-controllable LED prompt. A smart card reader (supporting up to 3 SAMs with software-controllable LED prompt) is available as a factory option. Both readers are designed for secure, reliable transaction processing in high-volume environments.
What is the processor and memory specification for the VeriFone M090-307-05-R?
The terminal features a 32-bit 200 MHz processor running Embedded Linux with VeriFone security enhancements on the MX platform. It includes 32 MB of RAM and supports field-upgradeable memory via USB Flash memory drives for flexible application management. Contact us today for detailed technical specifications and deployment planning.
The VeriFone M090-307-05-R Payment Terminal is also known as
VFN-M090-307-05-R
or M09030705R.
