VeriFone M090-107-01-R Payment Terminal

The VeriFone M090-107-01-R Payment Terminal has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
VeriFone MX870 - VeriFone MX870 Payment Terminal - 5.7" - Color - Active Matrix TFT LCD Display 200 MHz - 64 MB RAM - Ethernet - USB, NetworkUSB - PCI PED, Pin Pad, Signature Capture - Black
Discontinued Need Assistance?
Add to Quote
VeriFone MX870 Payment Terminal Model Overview
The VeriFone MX870 merges full-motion video, a 65,000 color display, high quality digital sound and highly secure payments capabilities into a single, easy-to-use system. Going well beyond standard PIN pad technology, the PCI PED approved MX870 meets stringent security requirements for the payment industry while enabling retailers to express their brand, reinforce advertising or deliver cross-promotions right to their customers at the point-of-sale. That means users can now complete transactions at the highest and most reliable level possible, while optimizing their time in front of the MX870.
VeriFone M090-107-01-R Payment Terminal Overview

Now VeriFone empowers retailers with a revolutionary new way to broadcast advertising and corporate messaging directly to customers. VeriFone's PCI PED and EMV Level 1 and 2 Type-approved MX870 goes well beyond standard PIN pad technology and merges full motion video, a 65,536 color display, high quality digital sound, and highly secure payment capabilities into a single, easy-to-use networking device.

Technical Information
Signature Capture:
Yes
Pin Pad:
Yes
Processor & Chipset
Processor Speed:
200 MHz
Memory
Standard Memory:
64 MB
Flash Memory:
64 MB
Display & Graphics
Screen Size:
5.7"
Display Color:
Color
Screen Mode:
QVGA
Display Screen Type:
Active Matrix TFT LCD
Touchscreen:
Yes
Network & Communication
Ethernet Technology:
Ethernet
Interfaces/Ports
Network (RJ-45):
Yes
USB:
Yes
Number of Network (RJ-45) Ports:
1
Number of USB Ports:
1
Built-in Devices
Built-in Devices:
  • Magnetic Stripe Reader
  • Speaker
  • Smart Card Reader
  • Media Player
Software
Operating System:
Linux
Physical Characteristics
Color:
Black
Miscellaneous
Additional Information:
  • VisualPayments completes the solution
  • Built for the long run
  • Smart, secure, sophisticated, and flexible
  • Features that present your message brilliantly

Cable Connectivity:

  • Supports VeriFone multi-port cables with cable sensing: 1 RS-485/RS-232 port and 2 RS-232 ports; EverestPlus/Omni 7xxx cables or MX multi-port cable for enhanced functionality
Item Numbers
UNSPSC: 43211720
Questions? Get help from
a POS Expert!

What is your POS application?

The VeriFone M090-107-01-R Payment Terminal is also known as M09010701R
