Unitech MS146-3 Barcode Card Reader

Unitech MS146-3PS2G Barcode Card Reader A newer version of this item is available.
It is replaced by the Unitech MS146-3PS2G Barcode Card Reader.
Unitech MS146 - Unitech MS146 Bar Code Slot Reader - Wired - Photo Diode
Discontinued See Replacement
Add to Quote
Unitech MS146 Barcode Card Reader Model Overview
The Unitech MS146 barcode slot reader is a flexible, cost effective solution when reliability is essential. With a resolution of up to 6 mils (0.15 mm), the MS146 is capable of reading any barcoded identification badge. The MS146's sealed optical system is available in both visible light or infrared. The infrared units ensure accurate reading of either visible and laminated badges. The convenient USB interface, water resistant base, rugged housing, and IP54 rated sealing make the MS146 a popular choice in any environment.
Unitech MS146-3 Barcode Card Reader Overview

The MS146 Bar Code Reader is a flexible, cost effective solution when you demand a reliable and rugged slot reader. With a resolution of up to 6 mils (0.15 mm), the MS146 is capable of reading any bar coded identification badge. It's sealed optical system is visible light. The infrared units ensure accurate reading of either visible and laminated badges. Its water resistant base, rugged housing, and IP54 rated sealing make the MS146 a popular choice in any environment.

Technical Information
Connectivity Technology:
Cable
Barcode Symbology Supported:
  • China Postal Code
  • Codabar
  • Code 11
  • Code 32
  • Code 39 Full ASCII
  • Code 39 (Standard)
  • Code 93
  • Code 128
  • Delta Code
  • EAN-8 with Add-on Code
  • EAN-13 with Add-on Code
  • EAN-128
  • Interleaved 2 of 5
  • ISBN / Bookland EAN
  • ISBT 128
  • Italian Pharmacy
  • Label Code IV
  • Label Code V
  • MSI/PLESSEY
  • Standard 2 of 5
  • Toshiba Code
  • UPC-A with Add-on Code
  • UPC-E with Add-on Code
Light Source:
LED
Maximum Scan Resolution:
6 mil
Depth of Field:
  • 2mm
Interfaces/Ports
Host Interface:
Keyboard Wedge
Physical Characteristics
Form Factor:
Swipe
Height:
1.9"
Width:
1.4"
Depth:
3.8"
Weight (Approximate):
6.70 oz
Miscellaneous
Additional Information:

6 ft Keyboard Wedge Cable

USB Cable separate

Platform Supported:
PC
Warranty
Limited Warranty:
2 Year
Item Numbers
UNSPSC: 43211701
Questions? Get help from
an ID Expert!

How many IDs will you
print per year?

The Unitech MS146-3 Barcode Card Reader is also known as UNI-MS1463 or MS1463.
