Symbol LS4005I-I100-0000Z Barcode Scanner

The Symbol LS4005I-I100-0000Z Barcode Scanner has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Symbol LS4004 i - Scanner Only.
  • Powerful laser scan source provides 100 scan/s decode rate
  • Scan barcodes with a staggering speed of 100 scan/s
Read More
Discontinued Need Assistance?
Add to Quote
Symbol LS4004 i Barcode Scanner Model Overview
The LS4004 i Series is the result of Symbol's experience in the design of innovative, high-performance scanning solutions. The LS4004 i incorporates a 650 nm laser that provides a bright scan line ensuring easy aiming even in high ambient light conditions. Combine this with a robust working range of contact out to more than 16 in. (40 cm) on 100% UPC codes and barcode data capture is a snap. Plus built-in Adaptive Logic Signal Processing decodes poorly printed and damaged barcodes. System integration is facilitated with Advanced Data Formatting (ADF), a Symbol innovation that enables the barcode data string to be modified before sending it on to the host computer. This enhances compatibility between barcoded data and the applications software by allowing the scanner to be programmed rather than modifying the host application which could be costly. All units ship with one product reference guide. All units feature Symbol's 5 year warranty.
Symbol LS4005I-I100-0000Z Barcode Scanner Overview

The LS 4005i Bar Code Reader is the result of Symbol's experience in the design of innovative, high-performance scanning solutions. It has built-in Adaptive Logic Signal Processing decodes poorly printed and damaged bar codes. To maximize user comfort, the LS 4005i Bar Code Reader features a lightweight design with the handle optimized to fit comfortably into hands of all sizes. Reduced finger fatigue, even over extended periods of use, is achieved with a patented two-finger trigger.

Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
  • UPC/EAN Supplementals
  • Code 39
  • Code 39 Full ASCII
  • Trioptic Code 39
  • Code 93
  • Codabar
  • Interleaved 2 of 5
  • Code 128
  • UCC/EAN 128
  • Discrete 2 of 5
  • MSI/PLESSEY
  • Bookland EAN
  • PDF 417
Light Source:
Laser
Scan Rate:
100 scan/s
Depth of Field:
  • 1" - 4.75"@5mil
  • 0.5" - 9"@7.5mil
  • 0" - 11"@80% UPC/EAN
  • 0" - 16"@100% UPC/EAN
  • 1" - 26"@20mil
  • 2" - 35"@40mil
  • 3" - 45"@55mil
Power Description
Input Voltage:
14 V DC
Physical Characteristics
Form Factor:
Handheld
Height:
6.3"
Width:
2.8"
Depth:
5"
Weight (Approximate):
6 oz
Miscellaneous
Additional Information:

Supported Interface:

  • IBM 468X/469X

USB Cable separate

Certifications & Standards:

Electrical Safety:

  • UL1950
  • CSA C22.2 No. 950
  • EN60950/IEC950

Laser Safety:

  • CDRH Class II
  • IEC Class 2IEC Class 2

EMI/RFI:

  • FCC Part 15 Class A
  • ICES-003 Class A
  • European Union EMC Directive
  • Australian SMA
Warranty
Limited Warranty:
5 Year
Item Numbers
UNSPSC: 43211701
Get help from a Barcoding Expert!

What type of Barcode are you scanning?

The Symbol LS4005I-I100-0000Z Barcode Scanner is also known as SYM-LS4005I
