SATO WM8460031 Barcode Printer

0.0

(No reviews)

Be the first to

SATO M84Pro (6) - Thermal transfer, 609 dpi, 6" ips, 4.1" print width, serial interface, 16MB RAM & 2MB Flash. Includes US power cord. Order cables separately. See accessories.

~~$2,771.25~~

In Stock:

Protect Your Product

Service Contract - 1 year
+ 860.00

Service Contract - 3 year
+ 782.00

Your satisfaction is guaranteed!

We want to make sure you are completely satisfied with your purchase. Customers must return their product within 30 days of shipment to receive a full credit less a 15% restocking fee. Returns must be presented in new condition with all of the original packaging.

+ Add to Quote

Allows user to switch print resolution simply by changing printheads.

The M84Pro(6) delivers 4.1" print width at rapid 10 ips with virtually Zero-Compile time by using the latest generation of 32-bit RISC 133 MHz CPU. The M84Pro(6) has a 609 dots-per-inch print resolution, which can be changed to either 203 or 305 dpi simply by switching printheads. All resolutions support the full 4.1" print width. All SATO Pro Series printers come with a minimum of 16MB RAM and 2MB Flash for storage of forms, fonts and graphics. Optional Flash module or PCMCIA memory card expands the printer storage capabilities even further. The M84Pro(6) is available with a vast array of interface connection plug-in modules making integration connectivity issues disappear.

Technical Information

Maximum Mono Print Speed: 6 in/s
Maximum Print Resolution: 609 dpi
Print Color: Monochrome
Maximum Print Width: 4.10"
Recommended Use: Label Print
Barcode Symbology Supported:
- UPC-A
- UPC-E
- EAN-8
- EAN-13
- Code 39
- Code 93
- Code 128
- Codabar
- MSI
- Bookland
- ITF-14
- Interleaved 2 of 5
- Matrix 25
- POSTNET
- UCC/EAN 128
- RSS
- PDF-417
- Micro PDF-417
- Maxi Code
- Data Matrix
- QR Code

General Information

Product Type: Direct Thermal/Thermal Transfer Printer
Product Series: Pro
Brand Name: Sato
Manufacturer: Sato Corporation
Product Model: M84Pro(6)
Product Name: M84Pro(6) Thermal Label Printer

Physical Characteristics

Height: 13.4"
Width: 10.4"
Depth: 17.1"

Interfaces/Ports

Serial Port: Yes

Media Types & Handling

Maximum Label Width: 5"
Maximum Label Length: 14"
Media Type:
- Fanfold
- Roll Fed
- Die-cut Label
- Continuous Form
- Direct Thermal Label
- Synthetic Media
- Notched
- Black Bar
- Tag Stock
Media Sensor:
- Reflective Media Sensor
- Transmissive Media Sensor
Maximum Roll Diameter: 8.60"

Other

Platform Supported: PC
Certifications & Standards:
- CE
- UL
- CSA
- TÜV
Additional Information:
- Label present sensor
- Reflective sensor for black mark
- Adjustable transmissive sensor for gap
- Automatic programmable setting of top of form

Power Description

Input Voltage:
- 110 V AC
- 220 V AC

Network & Communication

Ethernet: Yes
Ethernet Technology: Ethernet

Memory

Standard Memory: 16 MB
Flash Memory: 2 MB

Warranty

Limited Warranty: 1 Year

Full specifications (PDF)

See all SATO M84Pro(6) options »

Brand	SATO
Model	M84Pro(6)
Print Method	Thermal Transfer
Print Speed	6
Max Roll Outer Diameter	8.6
Label Core	3 inches
Printer Type	Industrial
Max Label Width	5.00
Maximum Print Width	4.10
Interface Options	Serial
Labels Per Day	5,001 - 10,000
Print Resolution	609 dpi
Printer Mobility	Not Mobile
Ribbon Core	1
