Printronix SL5204-03 RFID Printer

Part Number: SL5204-03
Model: SL5000r
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Print Resolution
203 dpi

Product Description:

  Printronix Smartline SL5204r MP2 Network Thermal Label Printer with RFID - Monochrome - 10 in/s Mono - 203 dpi - Serial, Parallel, USB - Fast Ethernet
Explore all Printronix SL5000r RFID Printers
Add to Quote
Printronix SL5204-03 RFID Printer
Printronix SL5204-03 RFID Printer
Printronix SL5204-03 RFID Printer
Printronix SL5204-03 RFID Printer
Printronix SL5204-03 RFID Printer
Printronix SL5204-03 RFID Printer Printronix SL5204-03 RFID Printer Printronix SL5204-03 RFID Printer Printronix SL5204-03 RFID Printer Printronix SL5204-03 RFID Printer
Full specifications (PDF)

Printronix SL5000r RFID Printer Model Overview

The Printronix SL5000r MP2 is the next generation family of RFID printers delivering true Gen 2 RFID encoding designed to EPCglobal Gen specifications. These printers feature EPCglobal Gen 2 Certified Hardware RFID Smart encoding technology and address a wide range of applications and global frequency requirements. The SL5000r MP2 is available in both a 4-inch and 6-inch model.
Printronix SL5204-03 RFID Printer Overview

The SL5204r MP2 is the next generation family of RFID printers delivering true Gen 2 RFID encoding designed to EPCglobal Gen specifications. This printer features EPCglobal Gen 2 Certified Hardware RFID Smart encoding technology and addresses a wide range of applications and global frequency requirements. The Printronix SL5204r MP2 smart label printer provides RFID solutions compliant to today's standards and compatible for growth to expand to tomorrow's needs.

Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
10 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
4.10"
Barcode Symbology Supported:
  • Australia Post
  • Aztec Code
  • BC35
  • BC412
  • Codabar
  • Code 11
  • Code 35
  • Code 39
  • Code 93
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • Data Matrix
  • EAN-8
  • EAN-13
  • FIM
  • 125 German
  • Interleaved 2 of 5
  • ITF-14
  • Matrix
  • Maxi Code
  • MSI
  • PDF-417
  • Planet Code
  • Plessey
  • POSTNET
  • PostBar
  • ROYALBAR
  • RSS-14
  • Telepen
  • UCC/EAN 128
  • UPC-A
  • UPC-E
  • UPC-E0
  • UPCSHIP
  • UPS11
Rewinder:
Yes
Memory
Standard Memory:
32 MB
Memory Technology:
DRAM
Flash Memory:
8 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
RFID:
Yes
Media Types & Handling
Media Type:
  • Roll Paper
  • Fanfold
  • Tag
  • Ticket
  • Film
  • Synthetic Media
  • Direct Thermal Paper
  • Thermal Transfer Label
Media Size:
Custom Size
Media Thickness:
10 mil
Maximum Roll Diameter:
8"
Power Description
Input Voltage:
  • 110 V AC
  • 220 V AC
Physical Characteristics
Height:
13"
Width:
11.7"
Depth:
20.5"
Miscellaneous
Additional Information:

Media Width: 1.0" to 4.5"

Platform Supported:
PC
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108
