Printronix S52X4-3100-000 RFID Printer

Part Number: S52X4-3100-000
Model: SL5000r
Add to My Shopping List Add to Compare
Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

Print Resolution
203 dpi

Product Description:

  Printronix SmartLine SL5204r Direct Thermal/Thermal Transfer Printer - Monochrome - Desktop - RFID Label Print - Ethernet - USB - Serial - RFID - 4.10" Print Width - 10 in/s Mono - 203 dpi - Roll Fed, Fanfold, Tag, Ticket, Film, Synthetic Media, RFID Label, Thermal Transfer Label, Direct Thermal Label - 4.50" Label Width
Explore all Printronix SL5000r RFID Printers
Add to Quote
Printronix S52X4-3100-000 RFID Printer
Printronix S52X4-3100-000 RFID Printer
Printronix S52X4-3100-000 RFID Printer
Printronix S52X4-3100-000 RFID Printer
Printronix S52X4-3100-000 RFID Printer
Printronix S52X4-3100-000 RFID Printer Printronix S52X4-3100-000 RFID Printer Printronix S52X4-3100-000 RFID Printer Printronix S52X4-3100-000 RFID Printer Printronix S52X4-3100-000 RFID Printer
Full specifications (PDF)

Printronix SL5000r RFID Printer Model Overview

The SMARTLINE SL5000r is a cutting-edge RFID printer that blends innovation with industrial design for unmatched performance in diverse environments. Engineered with patented MP2 RFID Smart encoding technology, it adheres to the highest EPCglobal Gen 2 standards, ensuring impeccable reliability and compliance for your RFID printing needs. With its robust aluminum die-cast structure and multi-protocol capabilities, the SL5000r is designed for rugged settings, providing scalability and efficient tag management to enhance your workflow and operational efficiency.

Key features:
  • Multi-protocol capability supports the latest Gen 2 standards for seamless RFID integration.
  • Intelligent Media Detection prevents printing errors, reducing costs on media.
  • Advanced RFID calibration features custom tag configurator and auto inlay locator.
  • Integrated EPCglobal certified encoder meets global frequency requirements for versatility.
  • Robust design optimized for industrial usage with ventless cooling.


Specifications:
  • Memory: 32MB DRAM, 8MB Flash (16MB optional)
  • Print Speed: Up to 10 IPS @ 203 dpi
  • Printable Width: Max 4.1" (SL5204r) / 6.6" (SL5206r)
  • Media Compatibility: Labels, tags, and tickets; paper, film, or synthetic stock
  • Operating Temperature: 5°C to 40°C
  • Dimensions: 11.7" W x 20.5" L x 13.0" H (SL5204r)
  • Weight: 38lbs (Shipping: 47lbs)
Printronix S52X4-3100-000 RFID Printer Overview

The SL5000r MP2 is the next generation family of RFID printers delivering Class 1 Gen 2 UHF RFID encoding designed to EPCglobal specifications. Designed for demanding duty cycles and environments, these printers feature EPCglobal Certified smart encoding technology and address a wide range of applications and global frequency requirements. The SL5000r comes in both a 4-inch and 6-inch model. (Products that earn the ENERGY STAR prevent greenhouse gas emissions by meeting strict energy efficiency guidelines set by the U.S. Environmental Protection Agency and the U.S. Department of Energy.)

Full specifications (PDF)
Technical Information
Recommended Use:
RFID Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
10 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
4.10"
Barcode Symbology Supported:
  • AUSTPORT
  • Aztec Code
  • BC35
  • BC412
  • Codabar
  • Code 11
  • Code 35
  • Code 39
  • Code 93
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • EAN-8
  • EAN-13
  • FIM
  • German I-2/5
  • GS1-128
  • GS1 DataBar
  • GS1 DataMatrix
  • IMB
  • Interleaved 2 of 5
  • ITF-14
  • Matrix
  • Maxi Code
  • MSI
  • PDF-417
  • Planet Code
  • Plessey
  • POSTNET
  • PostBar
  • ROYALBAR
  • Telepen
  • UPC-A
  • UPC-E
  • UPC-EO
  • UPCSHIP
  • UPS11
Application/Usage:
Desktop
Memory
Standard Memory:
64 MB
Memory Technology:
DRAM
Flash Memory:
16 MB
Interfaces/Ports
Parallel Port:
Yes
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Ethernet
RFID:
Yes
Media Types & Handling
Media Type:
  • Roll Fed
  • Fanfold
  • Tag
  • Ticket
  • Film
  • Synthetic Media
  • RFID Label
  • Thermal Transfer Label
  • Direct Thermal Label
Media Sensor:
  • Reflective Media Sensor
  • Transmissive Media Sensor
Media Thickness:
10 mil
Maximum Roll Diameter:
8"
Maximum Label Width:
4.50"
Label Core Size:
3"
Fonts & Emulation
Language Emulation:
  • PGL
  • ZGL
  • TGL
  • IGL
  • STGL
  • DGL
  • IEGL
  • MGL
  • XML
  • ZPL
Power Description
Power Source:
AC Supply
Input Voltage:
  • 110 V AC
  • 220 V AC
Operating Power Consumption:
150 W
Physical Characteristics
Height:
13"
Width:
11.7"
Depth:
20.5"
Weight (Approximate):
38 lb
Miscellaneous
Platform Supported:
PC
Certifications & Standards:
  • IEC60950-2
  • EN55022 Class B
  • EN55024
  • EN61000-3-2
  • EN61000-3-3
  • FCC Part 15 Class B
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
ENERGY STAR
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 43212108

Recommended Accessories

Category

  • Barcode Label Rewinder (1)
  • Printer Accessories (1)
  • Printronix RFID Printer (2)

Recommended Accessories for Model: Printronix S52X4-3100-000 RFID Printer

Top Barcode Label Rewinder Purchased With Printronix S52X4-3100-000

Top Printer Accessories Purchased With Printronix S52X4-3100-000

Top Printronix RFID Printer Purchased With Printronix S52X4-3100-000

Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Printronix S52X4-3100-000 RFID Printer is also known as PTX-S52X43100000 or S52X43100000.
