Printronix M4LWG-00 Portable Barcode Printer

The Printronix M4LWG-00 Portable Barcode Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.
Printronix - Printronix M4L Direct Thermal Printer - Monochrome - Portable - Label/Receipt Print - USB - Battery Included - Peel Facility - 2" Print Width - 4 in/s Mono - 203 dpi - Wireless LAN - Label, Receipt, Die-cut Label, Roll Fed, Fanfold - 4.40" Label Width - 90" Label Length
Printer Type
Mobile
Printing Technology
Direct Thermal
Print Resolution
203 dpi
  • This printer produces high-quality labels and receipts
  • Produce high-quality documents with this monochrome printer to increase your productivity
  • Print your documents from the comfort of your couch with Wireless LAN connectivity enabled
Read More
Discontinued Need Assistance?
Add to Quote
Printronix M4L Portable Barcode Printer Model Overview
For the past 40 years, Printronix has delivered printers designed to address all of your industrial printing needs. And now, the M4L mobile thermal printer emerges to address yet another issue that will improve your bottom line: efficiency. Ready to run all shift long thanks to a long battery life, and fully compatible with other competitive models, the M4L is factory-ready for ZPL 2 or CPCL, and connects directly to your legacy host systems and peripheral devices for quick and easy integration.
Printronix M4LWG-00 Portable Barcode Printer Overview
The M4L extended battery life, reliable performance, exceptional print quality, simplified user interface and rugged, compact construction will change the way high-volume business is done. Experience the best of Printronix's product durability, customer support, and service longevity with the latest portable innovation in warehouse efficiency and accuracy. Your extreme industrial environments - from a high-traffic warehouse floor to manufacturing plants - is what the M4L was designed for, and it allows workers to create, print and apply labels right where they're needed, all shift long.
Technical Information
Recommended Use:
Label/Receipt Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
4 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
2"
Barcode Symbology Supported:
  • Code 11
  • Code 39
  • Code 93
  • Code 128 UCC
  • Code 128-A
  • Code 128-B
  • Code 128-C
  • Codabar
  • Interleaved 2 of 5
  • EAN-8
  • EAN-13
  • EAN-14
  • EAN 128
  • UPC-A
  • UPC-E
  • EAN and UPC 2(5) Digits Add-On
  • MSI PLESSEY
  • POSTNET
  • China Post
  • ITF-14
  • Telepen
  • Planet Code
  • LOGMARS
  • Code 49
  • PDF-417
  • Micro PDF-417
  • Maxi Code
  • Data Matrix
  • QR Code
  • Aztec Code
  • Codablock
  • GS1 DataBar
Peel Facility:
Yes
Application/Usage:
Mobile
Features:
  • Drop Resistant
  • Tear-off
Memory
Standard Memory:
32 MB
Flash Memory:
16 MB
Memory Card Slot:
Yes
Memory Card Supported:
SDHC
Interfaces/Ports
USB:
Yes
Network & Communication
Bluetooth:
Yes
Wireless LAN:
Yes
Wireless LAN Standard:
IEEE 802.11b/g/n
Display & Graphics
Display Screen:
Yes
Screen Size:
2"
Display Screen Type:
LCD
Media Types & Handling
Media Type:
  • Label
  • Receipt
  • Die-cut Label
  • Roll Fed
  • Fanfold
Media Sensor:
  • Cover Open Sensor
  • Label Taken Sensor
Media Thickness:
6.50 mil
Maximum Roll Diameter:
2.65"
Maximum Label Width:
4.40"
Maximum Label Length:
90"
Fonts & Emulation
Language Emulation:
  • CPCL
  • ZPL II
Power Description
Power Source:
Battery
Input Voltage:
7.2 V AC
Battery Information
Battery Chemistry:
Lithium Ion (Li-Ion)
Battery Included:
Yes
Battery Rechargeable:
Yes
Physical Characteristics
Form Factor:
Portable
Height:
7.5"
Width:
6.3"
Depth:
3.1"
Weight (Approximate):
2.43 lb
Miscellaneous
Package Contents:
  • M4L Mobile Thermal Printer
  • Lithium-Ion Battery
  • M4L Configuration Utility Software
  • Software CD
Platform Supported:
PC
Certifications & Standards:
  • FCC
  • CE
  • TUV
Environmentally Friendly:
Yes
Environmental Certification:
  • RoHS
  • WEEE
Warranty
Limited Warranty:
1 Year
Item Numbers
UNSPSC: 45101512
Questions? Get help from a
Printer Expert!

How many labels will you print per day?

The Printronix M4LWG-00 Portable Barcode Printer is also known as PTX-M4LWG00
