Printronix C6815-0101-000 Products

Part Number: C6815-0101-000
Model:
Discontinued Need Assistance?
Item on backorder — chat for lead time

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Print Color Capability
Monochrome
Maximum Mono Print Speed
25 lps
Maximum Print Resolution (dpi)
180 x 144
Serial Port
Yes

Product Description:

  TallyGenicom 6800 6815 Line Matrix Printer - Monochrome - 25 lps Mono - 180 x 144 dpi - Serial Port - USB - Fast Ethernet

Printronix Parts Accessory Model Overview

Products and parts from Printronix.
Printronix C6815-0101-000 Products Overview

The 6800 Cabinet is your choice when reducing noise within your industrial printing environment is an objective. With the 6800 Cabinet, Talley Genicom has designed a modular enclosure that improves reliability and reduces noise emission, making it ideal for office environments. It is the quietest and most versatile choice in our mission-critical line matrix printer series. This industrial-strength printer is ideal for noise-adverse areas running large, unattended print applications. Its genius lies in its design. Talley Genicom configured the 6800 Cabinet to operate in a sturdy, fully enclosed sound-reduction cabinet.

Technical Information
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
25 lps
Maximum Print Resolution (dpi):
180 x 144
Interfaces/Ports
Serial Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Media Types & Handling
Media Type:
  • Fanfold
  • Continuous Form
Media Size:
3" x 17"
Fonts & Emulation
Language Emulation:
  • Tally ANSI
  • Genicom ANSI
  • P5000
  • P6000
  • P600
  • Epson FX-1180
  • IBM ProPrinter
  • MTPL
  • PGL
  • QMS Code V
  • PCL3
  • HP2564C
  • DEC LG01
Reliability
MTBF:
10000 Hour
Power Description
Power Source:
AC Supply
Input Voltage:
  • 110 V AC
  • 220 V AC
Maximum Power Consumption:
601 W
Operating Power Consumption:
435 W
Physical Characteristics
Form Factor:
Floor Standing
Height:
40.5"
Width:
27"
Depth:
29"
Weight (Approximate):
200 lb
Miscellaneous
Platform Supported:
PC
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Certification:
ENERGY STAR
Item Numbers
UNSPSC: 43212106

Frequently Asked Questions

The Datalogic 95B066330 is an inductive proximity sensor designed for automated identification and product profiling applications. It's commonly used in warehouse automation, logistics, and manufacturing environments to detect items, trigger scanning processes, and support accurate product identification workflows that keep supply chain operations running efficiently.

This sensor features a 2mm diameter, short-range design with 8mm flush mounting capability and double-range detection. It offers NPN output with 3-wire connectivity, operates in NO (normally open) mode, and includes a 2-meter cable for flexible installation in tight spaces and automated systems.

Yes, Datalogic sensors are engineered for demanding industrial environments. The 95B066330's robust construction and sealed design make it suitable for warehouse, manufacturing, and logistics applications where reliability and durability are critical to maintaining continuous operations.

The sensor features 3-wire connectivity with a 2-meter cable, allowing straightforward integration into industrial control systems and barcode scanning networks. This standard configuration works with most warehouse automation platforms and PLC systems we support.

The inductive proximity sensor works alongside barcode readers and identification products to automate detection and triggering of scanning processes. When integrated with Datalogic scanners available from us, it enables seamless product identification workflows from detection through barcode reading and data capture.

We offer the Datalogic 95B066330 Sensor as part of our comprehensive AIDC product line. Contact us today or visit barcodesinc.com for pricing, availability, technical specifications, and expert guidance on integrating this sensor into your warehouse automation or logistics systems.

The Printronix C6815-0101-000 Products is also known as PTX-C6815-0101-000
