Printronix 199388-001 Barcode Label Printer

The Printronix 199388-001 Barcode Label Printer has been discontinued.
No direct replacement is available.
Please contact us for a suitable substitute.

Printronix T5204 - Printronix T5204r Thermal Label Printer - 203 dpi - Serial, Parallel, USB

Printer Type

Industrial

Printing Technology

Thermal Transfer

Interface Options

Ethernet

Print Resolution

203 dpi

Max Print Width

4.5 inch

A smart choice for carrying out high volume label printing in multiple areas with reduced cost of ownership
Delivers high-speed, hassle-free labeling solution for your business needs
Optimize your workflows by sharing the resources of the printer via Ethernet connectivity

Need a different version? See all Printronix T5204 Barcode Label Printers

Discontinued Need Assistance?

Add to Quote

Printronix 199388-001 Barcode Label Printer

Overview

Full specifications (PDF)

Printronix T5204 Barcode Label Printer Model Overview

The T5204 delivers dependable and reliable 4" wide barcode printing at 203 dpi for compliance labeling and accommodates higher density barcodes, increased graphics or smaller text with snap-in print heads. When used in conjunction with ODV technology (Online Data Validation), the T5204 provides verification of scannable barcodes at the point of label creation. Designed as RFID Smart Ready, the T5204 converts to an UHF RFID printer encoder as RFID requirements enter the supply chain. Combining barcode compliance and RFID technology the T5204 links barcode and EPC data together for storage, retrieval, electronic audits and data synchronization.

Printronix 199388-001 Barcode Label Printer Overview

T5204r Label Printer, based on the world-class 5r Multi-Technology Platform, are web-enabled, industrial-grade thermal printer designed to operate in demanding manufacturing or distribution environments. T5204r Label Printer enable the rollout of bar code label printing.

Detailed Specs

Full specifications (PDF)

Technical Information

Recommended Use:

Label Print

Maximum Mono Print Speed:

10 in/s

Maximum Print Resolution (dpi):

203

Maximum Print Width:

4.10"

Barcode Symbology Supported:

Australia Post
Aztec Code
BC35
BC412
Codabar
Code 11
Code 35
Code 39
Code 93
Code 128-A
Code 128-B
Code 128-C
Data Matrix
EAN-8
EAN-13
FIM
125 German
Interleaved 2 of 5
ITF-14
Matrix
Maxi Code
MSI
PDF-417
Planet Code
Plessey
POSTNET
PostBar
ROYALBAR
RSS-14
Telepen
UCC/EAN 128
UPC-A
UPC-E
UPC-E0
UPCSHIP
UPS11

Memory

Standard Memory:

32 MB

Memory Technology:

DRAM

Flash Memory:

8 MB

Interfaces/Ports

Parallel Port:

Yes

Serial Port:

Yes

USB:

Yes

Network & Communication

Ethernet:

Yes

Ethernet Technology:

Fast Ethernet

Media Types & Handling

Media Type:

Roll Paper
Fanfold
Ticket
Film
Synthetic Media
Direct Thermal Paper
Thermal Transfer Label

Media Size:

4.50" x Roll Paper

Media Sensor:

Transmissive Media Sensor
Reflective Media Sensor

Maximum Roll Diameter:

Maximum Label Width:

4.50"

Label Core Size:

Fonts & Emulation

Language Emulation:

PGL
ZGL
TGL
IGL
STGL
DGL

Power Description

Input Voltage:

110 V AC
220 V AC

Physical Characteristics

Height:

13"

Width:

11.7"

Miscellaneous

Additional Information:

Sensing Methods:

Transmissive
Reflective

Platform Supported:

Certifications & Standards:

FCC-B
UL
CSA
ETSI EN 300 220
CE

Warranty

Limited Warranty:

1 Year

Item Numbers

UNSPSC: 43212108

Q&A

Get help from a Barcoding Expert!

The Printronix 199388-001 Barcode Label Printer is also known as PTX-199388-001 or 199388001.
