Newland NLS-FM430L-U Fixed Barcode Scanner

Part Number: NLS-FM430L-U
Model: FM430
to get Free Ground Shipping on your order.
3-year Premium Plus ($54.70)
No, stay at premium support package
Add to My Shopping List Add to Compare
$251.54

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity Technology
Cable
Scanning Capability
1D2D
Barcode Symbology Supported
1D: EAN-13 EAN-8 UPC-A UPC-E Code 128 Code 39 Codabar UCC/EAN 128 RSS ITF ITF-14 ITF6 Standard 25 Matrix 25 COOP 25 Industrial 25 Plessey MSI Plessey Code 11 Code93 Code 49 Code 16K 2D: PDF417 QR Code Data Matrix AZTEC CSC Maxicode Micro QR Micro PDF417 GM Code One
Image Sensor Type
CMOS

Product Description:

  Fixed Scanners, Newland FM430, 2D Megapixel Fixed Mount Scanner, 2-IR Sensors, Advanced Data Formatting, White Illumination, Laser Aiming, Trigger Button, 2m USB cable
Explore all Newland FM430 Fixed Barcode Scanners
Add to Quote
Newland NLS-FM430L-U Fixed Barcode Scanner
Newland NLS-FM430L-U Fixed Barcode Scanner
Newland NLS-FM430L-U Fixed Barcode Scanner
Newland NLS-FM430L-U Fixed Barcode Scanner Newland NLS-FM430L-U Fixed Barcode Scanner Newland NLS-FM430L-U Fixed Barcode Scanner
Full specifications (PDF)

Newland FM430 Fixed Barcode Scanner Model Overview

The NLS-FM430 Fixed Mount Barcode Scanner from Newland AIDC is designed to streamline your scanning needs with exceptional performance. Equipped with advanced UIMG® technology, it effortlessly captures 1D and 2D barcodes, even those under protective films. The scanner's robust IP54-sealed housing ensures durability against dust and moisture, and its highly visible laser aimer guarantees precise targeting in any lighting condition. Whether you’re automating your checkout processes or managing inventory, the NLS-FM430 enhances efficiency and accuracy, making your workflow smoother than ever.
Key features:
  • IR/Light Triggers: Improved sensitivity for faster scanning.
  • Automatic Exposure Control (AEC): Adapts to varying light conditions.
  • Unmatched Reading Performance: Reads protected 2D barcodes effortlessly.
  • 1.5m Drop Resistance: Built to withstand drops for added durability.

Specifications:
  • Performance:
    • Resolution: 1280*800 CMOS
    • Scan Angle: Horizontal 51°, Vertical 32°
    • Operating Voltage: 5VDC±5%
  • Physical:
    • Dimensions: 41.5(W)x49.5(D)×24.3(H)mm
    • Weight: 56g
  • Environmental:
    • Operating Temperature: -20°C to 60°C
    • Humidity: 5% to 95% (non-condensing)
    • Sealing: IP54 rated
Newland NLS-FM430L-U Fixed Barcode Scanner Overview

FM430 Barracuda 2D CMOS Mega Pixel Fixed Mounted Reader with 2 mtr. USB extension cable. Laser Aimer, white light and IR sensor.

Full specifications (PDF)
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
  • 1D
  • 2D
Barcode Symbology Supported:
1D:
  • EAN-13
  • EAN-8
  • UPC-A
  • UPC-E
  • Code 128
  • Code 39
  • Codabar
  • UCC/EAN 128
  • RSS
  • ITF
  • ITF-14
  • ITF6
  • Standard 25
  • Matrix 25
  • COOP 25
  • Industrial 25
  • Plessey
  • MSI Plessey
  • Code 11
  • Code93
  • Code 49
  • Code 16K
2D:
  • PDF417
  • QR Code
  • Data Matrix
  • AZTEC
  • CSC
  • Maxicode
  • Micro QR
  • Micro PDF417
  • GM
  • Code One
Image Sensor Type:
CMOS
Scanning Distance:
14.17"
Cable Type Included:
USB
Field of View (Horizontal):
51°
Field of View (Vertical):
32°
Reading Angle (Skew):
55°
Reading Angle (Pitch):
55°
Reading Angle (Roll):
360°
Drop Specification:

1.5m Drop

Minimum Print Contrast:
25%
Maximum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (PDF417):
6.7 mil
Network & Communication
Infrared:
Yes
Interfaces/Ports
Host Interface:
  • Serial
  • USB
Physical Characteristics
Form Factor:
Fixed Mount
Height:
1"
Width:
1.6"
Depth:
1.9"
Weight (Approximate):
2.65 oz
Miscellaneous
Ingress Protection (IP) Rating:
IP54
Application/Usage:
  • Industrial
  • Transportation
  • Ticketing
  • Outdoor
Item Numbers
UNSPSC: 43211701
