Intermec SG20 Series – Barcode Scanner – Corded – 2D

Part Number: SG20THP-USB001
Model: SG20 Series

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Connectivity
Corded
Form Factor
Handheld
Interface Options
USB
Scanner Capability
2D

Product Description:

  Intermec SG20T Handheld Barcode Scanner - Cable Connectivity - 2D - Imager

Honeywell SG20 Series Barcode Scanner Model Overview

The Intermec SG20 Series is an affordable, high-performance handheld scanner available in a range of models suited to the demands of general purpose countertop scanning. The SG20 Series Features the industry's fastest 2D-imaging technology for highly responsive, dependable scanning, a unique, ergonomic styling maximizes comfort that saves countertop space, a large LED indicator provides effective visual operational feedback, Bluetooth wireless or tethered (cabled) connectivity,integrates seamlessly with point-of-sale systems, personal computers, common software solutions and a wide range of multi-purpose accessories to increase scanner flexibility.
Intermec SG20THP-USB001 Barcode Scanner Overview
Speed up the customer checkout experience with the SG20 handheld scanner, available with the industry's fastest 2D bar code imaging technology for quick, flawless scans - every time. Ergonomically designed for the needs of countertop scanning applications in retail, office, library, and light manufacturing.
Technical Information
Connectivity Technology:
Cable
Scanning Capability:
2D
Barcode Symbology Supported:
1D:
  • Codabar
  • Code 11
  • Code 39
  • Code 93/93i
  • Code 128 / GS1-128
  • EAN/UPC
  • GS1 DataBar Limited
  • GS1 Composite (linear only)
  • GS1 DataBar Expanded
  • GS1 DataBar Omnidirectional
  • Interleaved 2 of 5
  • Matrix 2 of 5
  • MSI
  • Plessey
  • Standard 2 of 5
  • Telepen
2D:
  • Australian Post
  • Aztec
  • BPO
  • Canada Post
  • Codablock A
  • Codablock F
  • DataMatrix
  • Dutch Post
  • EAN/UPC
  • GS1 Composite
  • GS1 DataBar Stacked
  • Infomail
  • Intelligent Mail
  • Japan Post
  • Maxicode
  • Micro PDF417
  • Multicode
  • PDF417
  • Planet
  • Postnet
  • QR Code
  • Sweden Post
  • TLC 39
Image Sensor Type:
Imager
Interfaces/Ports
Host Interface:
USB
Physical Characteristics
Height:
2.6"
Width:
2.4"
Length:
7.9"
Weight (Approximate):
4.41 oz
Miscellaneous
Additional Information:

USB Cable separate

Environmental Certification:
  • RoHS
  • China RoHS
  • WEEE
  • REACH
Warranty
Limited Warranty:
5 Year
Item Numbers
GTIN: 0091803418833, 0641676218681, 0650361461455, 0682017464046, 0682276986372, 0735548764618, 0783555014882, 3609740037849, 4054318496150, 5711045699832
UPC: 091803418833, 641676218681, 650361461455, 682017464046, 682276986372, 735548764618, 783555014882
EAN: 0091803418833, 0641676218681, 0650361461455, 0682017464046, 0682276986372, 0735548764618, 0783555014882, 3609740037849, 4054318496150, 5711045699832
UNSPSC: 43211701
