Intermec SG20B2D-USB001 Barcode Scanner

Intermec SG20B: SG20 Series - USB Kit, 2D Imager, Cordless. Includes base, USB cable, and power supply. Line cord sold separately.
Perfectly Matched to Your Needs

The Intermec SG20 Series is an affordable, high-performance handheld scanner available in a range of models suited to the demands of general purpose countertop scanning. The SG20 Series Features the industry's fastest 2D-imaging technology for highly responsive, dependable scanning, a unique, ergonomic styling maximizes comfort that saves countertop space, a large LED indicator provides effective visual operational feedback, Bluetooth wireless or tethered (cabled) connectivity, integrates seamlessly with point-of-sale systems, personal computers, common software solutions and a wide range of multi-purpose accessories to increase scanner flexibility.

Technical Information

  • Barcode Dimension:
    • 1D
    • 2D
  • Scan Pattern: Omni-directional
  • Connectivity Technology: Wireless
  • Image Sensor: Imager
  • Barcode Symbology Supported:
    • 1D:
    • Codabar
    • Code 11
    • Code 39
    • Code 93/93i
    • Code 128 / GS1-128
    • EAN/UPC
    • GS1 DataBar Limited
    • GS1 Composite (linear only)
    • GS1 DataBar Expanded
    • GS1 DataBar Omnidirectional
    • Interleaved 2 of 5
    • Matrix 2 of 5
    • MSI
    • Plessey
    • Standard 2 of 5
    • Telepen
    • 2D:
    • Australian Post
    • Aztec
    • BPO
    • Canada Post
    • Codablock A
    • Codablock F
    • DataMatrix
    • Dutch Post
    • EAN/UPC
    • GS1 Composite
    • GS1 DataBar Stacked
    • Infomail
    • Intelligent Mail
    • Japan Post
    • Maxicode
    • Micro PDF417
    • Multicode
    • PDF417
    • Planet
    • Postnet
    • QR Code
    • Sweden Post
    • TLC 39
    • 1D:
    • Codabar
    • Code 11
    • Code 39
    • Code 93/93i
    • Code 128 / GS1-128
    • EAN/UPC
    • GS1 DataBar Limited
    • GS1 Composite (linear only)
    • GS1 DataBar Expanded
    • GS1 DataBar Omnidirectional
    • Interleaved 2 of 5
    • Matrix 2 of 5
    • MSI
    • Plessey
    • Standard 2 of 5
    • Telepen
    • 2D:
    • Australian Post
    • Aztec
    • BPO
    • Canada Post
    • Codablock A
    • Codablock F
    • DataMatrix
    • Dutch Post
    • EAN/UPC
    • GS1 Composite
    • GS1 DataBar Stacked
    • Infomail
    • Intelligent Mail
    • Japan Post
    • Maxicode
    • Micro PDF417
    • Multicode
    • PDF417
    • Planet
    • Postnet
    • QR Code
    • Sweden Post
    • TLC 39
  • Maximum Scan Resolution: 6.60 mil

General Information

  • Product Type: Handheld Barcode Scanner
  • Product Series: SG20
  • Brand Name: Intermec
  • Manufacturer: Intermec Technologies Corporation
  • Product Model: SG20B
  • Product Name: SG20 General Duty Imager

Physical Characteristics

  • Height: 2.6"
  • Width: 2.4"
  • Length: 7.9"
  • Weight (Approximate): 6.17 oz

Network & Communication

  • Bluetooth: Yes

Battery Information

  • Battery Chemistry: Lithium Ion (Li-Ion)

Other

  • Platform Supported: PC

Full specifications (PDF)

Full specifications (PDF)

Brand Intermec
Model SG20 Series
Scan Pattern Area
Connection USB
Scanner Type Imager
Connectivity Corded
Included Cables USB
Form Factor Handheld
Scanner Capability 2D
Color Black
Ruggedness General Purpose

Recommended Accessories for Model: Intermec SG20 Series Scanner
Intermec (HOLDER-SG20-01)
Holder, Desktop/Wall Mount, Compatible with SG20.
In Stock: Ships Same Day
$20.90
+ Add to Quote
Intermec (STAND-SG20HC-01)
SG20 HC Desktop Adjustable Stand
$27.80
+ Add to Quote
Intermec (FLEXSTAND-SG20-01)
FLEXSTAND FOR SG20
$41.90
+ Add to Quote
Intermec (CB-SG20HC-001)
G20HC Chrg Base, (no Bluetooth or I/F)
$84.00
+ Add to Quote
Intermec (CB-SG20-001)
SG20 CHARGE BASE, NO Bluetooth OR INTERFACE, REQUIRES POWER SUPPLY 851-089-306 AND POWER CORD.
$52.50
+ Add to Quote

The Intermec SG20B2D-USB001 is also known as Intermec Technologies INT-SG20B2DUSB001 or SG20B2DUSB001 .
