Intermec PM43A12000000401 Barcode Printer


0.0

(No reviews)

Be the first to

Write a Review
Intermec PM43 - Thermal transfer Printer, 406 dpi, Touch Screen Display. Wi-Fi (802.11a/b/g), Serial, USB Interfaces. Fixed media hanger.
Fastest to Deploy. Seamlessly Fits Any Environment.

The Intermec PM43 mid-range industrial label printers are ready to perform. Reduce workforce training and support with the tamper-proof, 10-language, color touch-screen or universal-icon interface. The PM43 is a third-generation Intermec industrial printer designed to maximize your uptime. Count on the PM43 to deliver quick deployment, the fastest print speed in its class, and proven reliability.

Technical Information

  • Maximum Mono Print Speed: 10 in/s
  • Maximum Print Resolution: 406 dpi
  • Print Color: Monochrome
  • Maximum Print Width: 4.09"
  • Recommended Use: Label Print
  • Barcode Symbology Supported:
    • UPC/EAN Shipping Container
    • UCC/EAN 128 Serial Shipping Container
    • LOGMARS
    • POSTNET
    • HIBCC
    • ISBT-128
    • GM1724

General Information

  • Product Type: Direct Thermal/Thermal Transfer Printer
  • Product Series: PM
  • Brand Name: Intermec
  • Manufacturer: Intermec Technologies Corporation
  • Product Model: PM43
  • Product Name: PM43 Mid-Range Printer

Physical Characteristics

  • Height: 11.6"
  • Width: 11.2"
  • Depth: 19"
  • Form Factor: Desktop
  • Weight (Approximate): 34.88 lb

Interfaces/Ports

  • USB: Yes
  • Serial Port: Yes

Media Types & Handling

  • Maximum Label Width: 4.50"
  • Media Type:
    • Label
    • Tag
    • Linered Label
    • Linerless
    • Roll Fed
    • Fanfold
    • Gap
    • Notch
    • Black Mark
    • Continuous Label
    • Tag Stock
    • Ticket
  • Media Thickness: 10.40 mil
  • Media Sensor: Transmissive Media Sensor
  • Label Core Size: 3"
  • Ribbon Core Size: 1"
  • Maximum Roll Diameter: 8.38"

Other

  • Green Compliant: Yes
  • Green Compliance Certificate/Authority:
    • ENERGY STAR
    • RoHS
  • Platform Supported: PC
  • Certifications & Standards:
    • PFC Regulation: IEC320/C14
    • CE (EN55022 Class A)
    • FCC Class A
    • UL/cUL
    • C-Tick
    • D Mark
    • CCC

Power Description

  • Input Voltage:
    • 110 V AC
    • 220 V AC
  • Standby Power Consumption: 9 W
  • Maximum Power Consumption: 300 W
  • Power Source: AC Supply

Fonts & Emulation

  • Language Emulation:
    • Fingerprint
    • IPL
    • ZSim
    • DSim
    • XML

Memory

  • Standard Memory: 128 MB
  • Memory Technology: SDRAM
  • Flash Memory: 128 MB

Network & Communication

  • Wireless LAN: Yes
  • Wireless LAN Standard: IEEE 802.11b/g/n

Display & Graphics

  • Touchscreen: Yes

Warranty

  • Limited Warranty: 1 Year

Full specifications (PDF)

Full specifications (PDF)

Brand Intermec
Model PM43
Max Roll Outer Diameter 8
Print Speed 12, 10
Interface Options Wireless, Serial, USB, Ethernet
Maximum Print Width 4.25
Max Label Width 4.50
Print Resolution 400 dpi
Printer Type Industrial
Label Core 1.5 inches, 3 inches
Included Features Media Hanger
Print Method Thermal Transfer
Printer Mobility Not Mobile
Ribbon Core 1


Customer Review Summary

Recommended Accessories for Model: Intermec PM43 Printer
Intermec (321-576-004)
Cable, USB-A to USB-B, 2meter (Use with CK30/31 225-709-001/225-709-002 comm dock for connection to PC.)
In Stock: Ships Same Day
$39.00
+ Add to Quote
Intermec (203-974-001)
KIT, PEEL-OFF
In Stock: Ships Same Day
$118.90
+ Add to Quote
Intermec (710-180S-001)
REPLACMENT PRINTHEAD FOR PM43 THP, 406 DPI 4, Assembly Spare
In Stock: Ships Same Day
$721.90
+ Add to Quote
Intermec (1-110501-00)
Printhead Cleaning Kit (25 Individual cleaner units per box)
In Stock: Ships Same Day
$31.40
+ Add to Quote
Intermec PM43 Accessories (710-090S-001)
Rewinder, Media Internal Sub - Assembly PM43
In Stock: Ships Same Day
$249.30
+ Add to Quote
Recommended Labels for Model: Intermec PM43 Printer
Intermec Duratran Pro (E03444)
4" x 6" Thermal transfer paper label. 895 labels/roll, 4 roll case. Also available as a roll (Part# E03444-R.)
In Stock: Ships Same Day
$298.90
+ Add to Quote
Intermec INdelible (E23068)
3" x 1" Thermal transfer polyester label. 5333 labels/roll, 4 roll case.
In Stock: Ships Same Day
$418.90
+ Add to Quote
Intermec Duratherm III (E22748)
2" x 3" Direct thermal paper label. 1920 labels/roll, 8 roll case.
In Stock: Ships Same Day
$210.00
+ Add to Quote
Intermec Duratran Pro (E02202)
3" x 1" Thermal transfer paper label. 4,885 labels/roll, 8 roll case.
In Stock: Ships Same Day
$448.30
+ Add to Quote
Intermec Duratran II (E06724)
4" x 1" Thermal transfer paper label. 5333 labels/roll, 8 roll case. Also available as a roll (Part# E06724-R).
In Stock: Ships Same Day
$227.30
+ Add to Quote
Recommended Ribbons for Model: Intermec PM43 Printer
Intermec ThermaMax 2202 Mid-Range (12084106)
4.1" x 500' Black Wax-Resin Ribbon, Compatible with Industrial printers and Polypropylene Labels, rolls/case: 12, Core Size: 1"
In Stock: Ships Same Day
$192.80
+ Add to Quote
Intermec ThermaMax 1407 Wax (11084106-R)
4.1" x 500' Black Wax Ribbon. Compatible with Industrial Printers. Single ribbon. Used with paper labels.
In Stock: Ships Same Day
$14.80
+ Add to Quote
Intermec ThermaMax 3202 Resin (13023006)
3" x 500' Black Resin Ribbon, Compatible with Industrial printers and Polyester Labels, rolls/case: 36, Core Size: 1"
Ships in 3-5 Days
$938.10
+ Add to Quote
Intermec ThermaMax 2202 Mid-Range (12234118-R)
4.09" x 1502' Black Wax-Resin Ribbon. Compatible with Industrial Printers. Single ribbon. Used with polypropylene labels.
In Stock: Ships Same Day
$42.30
+ Add to Quote
Intermec ThermaMax 2202 Mid-Range (12023006-R)
3" x 500' Black Wax-Resin Ribbon. Compatible with Industrial Printers. Single ribbon. Used with polypropylene labels.
In Stock: Ships Same Day
$17.00
+ Add to Quote
Recommended Printheads for Model: Intermec PM43 Printer
Intermec PM43 (710-179S-001)
Replacement Printhead Kit, 300 dpi, Compatible Printer Model PM43
In Stock: Ships Same Day
$505.30
+ Add to Quote
Intermec PM43 (710-129S-001)
Replacement Printhead Kit, 203 dpi, Compatible Printer Model PM43
In Stock: Ships Same Day
$433.10
+ Add to Quote
Protect Your Product
Intermec Service Contracts (SVCPM43CR-OS2WT3)
PM43, with CUTTER, 2 DAY RESPONSE, On-site, 3 YEAR
Ships in 3-5 Days
$664.90
+ Add to Quote
Intermec Service Contracts (SVCPM43CR-OS1WT3)
PM43, with CUTTER, 1 DAY, On-site, 3 YEAR
Ships in 3-5 Days
$758.90
+ Add to Quote
Intermec Service Contracts (SVCPM43CR-5FC5)
PM43, CUTTER, Full Comprehensi ve, 5 Day Turn, 5 Year DayOne
Ships in 3-5 Days
$544.70
+ Add to Quote
Intermec Service Contracts (SVCPM43CR-5FC3)
PM43, CUTTER, Full Comprehensi ve, 5 Day Turn, 3 Year DayOne
Ships in 3-5 Days
$414.80
+ Add to Quote
Intermec Service Contracts (SVCPM43-OS2WT5)
PM43, 2 Day Response, On-site, 5 Year
Ships in 3-5 Days
$860.20
+ Add to Quote

The Intermec PM43A12000000401 is also known as Intermec Technologies INT-PM43A12000000401 .
