Honeywell PM43 – Barcode Label Printer – 203 dpi – Thermal Transfer

Part Number: PM43A11010000201
Model: PM43
Add to My Shopping List Add to Compare
Discontinued See Replacement

Price Match Guarantee - We'll match any authorized retailer's price

Quantity:

Product Highlights

View All
Printer Type
Desktop
Printing Technology
Thermal Transfer
Interface Options
Ethernet, USB
Print Resolution
203 dpi

Product Description:

  Intermec PM43 Direct Thermal/Thermal Transfer Printer - Monochrome - Desktop - Label Print - Ethernet - USB - 4.25" Print Width - 12 in/s Mono - 203 dpi - Ticket, Tag, Linered Label, Linerless, Roll Fed, Fanfold, Gap, Notch, Black Mark, Continuous Label - 4.50" Label Width
Explore all Honeywell PM43 Barcode Label Printers
Add to Quote
Honeywell PM43A11010000201 Barcode Label Printer
Honeywell PM43A11010000201 Barcode Label Printer
Honeywell PM43A11010000201 Barcode Label Printer
Honeywell PM43A11010000201 Barcode Label Printer Honeywell PM43A11010000201 Barcode Label Printer

Full specifications (PDF)

Honeywell PM43 Barcode Label Printer Model Overview

The Honeywell PM43 mid-range industrial label printers are ready to perform. Reduce workforce training and support with the tamper-proof, 10-language, color touch-screen or universal-icon interface. The PM43 is a third-generation Honeywell industrial printer designed to maximize your uptime. Count on the PM43 to deliver quick deployment, the fastest print speed in its class, and proven reliability.
Honeywell PM43A11010000201 Barcode Label Printer Overview
PM43/PM43c mid-range industrial label printers are ready to perform. Reduce workforce training and support with the tamper-proof, 10-language, color touch-screen or universal-icon interface. The PM43/PM43c is a third-generation Intermec industrial printer designed to maximize your uptime. Count on the PM43/PM43c to deliver quick deployment, the fastest print speed in its class, and proven reliability.
Full specifications (PDF)
Technical Information
Recommended Use:
Label Print
Print Color Capability:
Monochrome
Maximum Mono Print Speed:
12 in/s
Maximum Print Resolution (dpi):
203
Maximum Print Width:
4.25"
Barcode Symbology Supported:
  • UPC/EAN Shipping Container
  • UCC/EAN 128 Serial Shipping Container
  • LOGMARS
  • POSTNET
  • HIBCC
  • ISBT-128
  • GM1724
  • Code 93
  • Matrix 2 of 5
  • Industrial 2 of 5
  • Code 39
  • UCC 128
  • EAN 128
  • Code 49
  • QR Code
  • Maxi Code
  • Aztec Code
  • Macro PDF-417
  • Codabar
  • Code 11
  • Code 128
  • Code 16K
  • UPC
  • Interleaved 2 of 5
  • PDF-417
  • MSI PLESSEY
  • Plessey
  • Data Matrix
  • Planet Code
  • Standard 2 of 5
  • Grid Matrix
  • EAN/JAN
Application/Usage:
Desktop
Print Technology:
Direct Thermal /Thermal Transfer
Memory
Standard Memory:
128 MB
Memory Technology:
SDRAM
Flash Memory:
128 MB
Interfaces/Ports
Parallel Port:
Yes
USB:
Yes
Network & Communication
Ethernet:
Yes
Ethernet Technology:
Fast Ethernet
Display & Graphics
Touchscreen:
Yes
Media Types & Handling
Media Type:
  • Ticket
  • Tag
  • Linered Label
  • Linerless
  • Roll Fed
  • Fanfold
  • Gap
  • Notch
  • Black Mark
  • Continuous Label
Media Sensor:
Transmissive Media Sensor
Media Thickness:
10.40 mil
Maximum Roll Diameter:
8.40"
Maximum Label Width:
4.50"
Label Core Size:
3"
Ribbon Core Size:
1"
Fonts & Emulation
Language Emulation:
  • IPL
  • Fingerprint
  • DSim
  • ZSim
  • XML
  • ZPL
Power Description
Power Source:
AC Supply
Input Voltage:
  • 110 V AC
  • 220 V AC
Maximum Power Consumption:
300 W
Standby Power Consumption:
9 W
Physical Characteristics
Height:
11.6"
Width:
11.2"
Depth:
19"
Weight (Approximate):
34.88 lb
Miscellaneous
Package Contents:
  • PFC Regulation: IEC320/C14
  • CE (EN55022 Class A)
  • FCC Class A
  • UL/cUL
  • C-Tick
  • D Mark
  • CCC
Platform Supported:
PC
Energy Star:
Yes
Environmentally Friendly:
Yes
Environmental Compliance:
Restriction of Hazardous Substances (RoHS)
Item Numbers
GTIN: 0735548763123, 0783555127728
UPC: 735548763123, 783555127728
EAN: 0735548763123, 0783555127728
UNSPSC: 43212108
