Full specifications (PDF)
Connectivity Technology:
Cable/Wireless
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
1D:
- Code 39, code 128, code 93, code 11, code 32 Pharmaceutical, codabar, EAN, UPC, China Post, GS1 databar
2D:
- Aztec, Data Matrix, QR/Micro QR code, Maxicode, Chinese sensible (Han Xin) code, postal code, PDF417, DotCode
Digital Watermarking:
- Digimarc
OCR:
- OCR A, OCR B, MICR E-13B and SEMI Font, in a 6 to 60 point OCR typeface
Light Source:
Laser
Image Sensor Type:
Imager
Scan Mode:
Trigger
Scan Pattern:
Area
Scanner Range:
Ultra Long Range
Scanning Distance:
98.43 ft
Features:
- Notification LED
- Beep
- Vibration
- Ergonomic Design
- Data Formatter
Field of View (Horizontal):
45°
Field of View (Vertical):
14°
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
- 3m (10 ft): MIL-STD-810G, 25° C (77° F), 55% relative humidity
- 2.5m (8.2 ft): 20 drops from -20° C to 50° C (4° F to 122° F), 55% relative humidity
- 2m (6.5 ft): 50 drops from -30° C to 50° C (-22° F to 122° F), uncontrolled relative humidity
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
5 mil
Maximum Element Resolution (Code 39):
100 mil
Minimum Element Resolution (DataMatrix):
10 mil
Maximum Element Resolution (DataMatrix):
100 mil
Image Sensor Resolution:
1900 x 800
Illumination Type:
LED
Illumination Color:
Green
Air Electrostatic Discharge (+/-):
20kV
Contact Electrostatic Discharge (+/-):
8kV
AI-powered:
Yes
