Full specifications (PDF)
Connectivity Technology:
Cable
Scanning Capability:
- 1D
- 2D
Barcode Symbology Supported:
- 1D: Code 39, code 128, code 93, code 11, code 32 Pharmaceutical, EAN, UPC, codabar, China Post, GS1 databar
- 2D: Aztec, Data Matrix, QR/Micro QR code, Maxicode, Chinese sensible (Han Xin) code, postal code, PDF417, DotCode,
Light Source:
LED
Image Sensor Type:
Imager
Scan Pattern:
Area
Scanner Range:
High Density
Features:
- Vibration
- Beep
- Notification LED
- Ergonomic Design
Field of View (Horizontal):
28°
Field of View (Vertical):
24°
Reading Angle (Skew):
65°
Reading Angle (Pitch):
65°
Reading Angle (Roll):
360°
Maximum Ambient Light:
100000 lux
Drop Specification:
- 3m (10 ft): MIL-STD-810G, 25° C (77° F), 55% relative humidity
- 2.5m (8.2 ft): 20 drops from -30° C to 50° C (-22° F to 122° F), 55% relative humidity
- 2m (6.5 ft): 50 drops from -30° C to 50° C (-22° F to 122° F), uncontrolled relative humidity
Minimum Print Contrast:
15%
Minimum Element Resolution (Code 39):
2 mil
Maximum Element Resolution (Code 39):
5 mil
Minimum Element Resolution (DataMatrix):
5 mil
Maximum Element Resolution (DataMatrix):
10 mil
Direct Part Marking (DPM) Decoding:
Yes
Image Sensor Resolution:
1280 x 1080
Illumination Type:
LED
Illumination Color:
White
Air Electrostatic Discharge (+/-):
20kV
Contact Electrostatic Discharge (+/-):
8kV
AI-powered:
Yes
