Honeywell HF81X Barcode Scanner
Honeywell HF81X -
The Honeywell HF81X Series provides fixed mount scanners designed with flexibility and enhanced performance in mind. The HF810 and HF811 2D industrial scanners offer powerful perfomance, including DPM capabilities, all in a compact form factor. With the ability to be networked, the HF810 and HF811 scanners allow you to build a complete manufacturing or warehouse management solution. The HF810 and HF811 scanners enable rapid setup through the DataMax Plus configuration tool and their Autotune function that optimizes scanning parameters with the press of a button.
Full specifications (PDF)
Price Match Guarantee
Found a better price? We'll match it within 60 days of your purchase.
for Qty Discount
Add to Quote
Starting at:
$1,369.72
Get help from a Barcoding Expert!
Accessories For Honeywell HF81X Barcode Scanner
Color
- Blue (1)
Honeywell HF81X Barcode Scanner Options
-
Honeywell HF810-01BT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF810, 0.5 megapixel, Narrow FOV, Blue LED illumination$1,369.72 -
Honeywell HF810-01RT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF810, 0.5 megapixel, Narrow FOV, Red LED illumination$1,369.72 -
Honeywell HF810-11WT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF810, 0.5 megapixel, Wide FOV, White LED illumination$1,369.72 -
Honeywell HF810-01WT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF810, 0.5 megapixel, Narrow FOV, White LED illumination$1,369.72 -
Honeywell HF810-11BT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF810, 0.5 megapixel, Wide FOV, Blue LED illumination$1,369.72 -
Honeywell HF810-11RT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF810, 0.5 megapixel, Wide FOV, Red LED illumination$1,369.72 -
Honeywell HF811-11WT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF811, 2 megapixel, Wide FOV, White LED illumination$1,433.10 -
Honeywell HF811-01BT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF811, 2 megapixel, Narrow FOV, Blue LED illumination$1,518.66 -
Honeywell HF811-11RT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF811, 2 megapixel, Wide FOV, Red LED illumination$1,518.66 -
Honeywell HF811-01WT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF811, 2 megapixel, Narrow FOV, White LED illumination$1,565.38 -
Honeywell HF811-01RT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF811, 2 megapixel, Narrow FOV, Red LED illumination$1,565.38 -
Honeywell HF811-11BT00004K-R Barcode Scanner
Barcode Scanners, Honeywell HF811, 2 megapixel, Wide FOV, Blue LED illumination$1,565.38
Honeywell HF81X Barcode Scanner Model Overview
The HF810 and HF811 Fixed Mount Scanners by Honeywell are engineered for versatility and high performance in diverse environments. Featuring advanced encoding and decoding technologies, these compact 2D industrial scanners excel in package sorting and light manufacturing workflows. With dedicated DPM capabilities and easy integration into factory settings, the HF810 and HF811 are ideal for businesses seeking efficiency and reliability in their operations.
Key Features:
Specifications:
Key Features:
- Enhanced performance: Dedicated DPM algorithm for rapid scanning in manufacturing workflows.
- Flexible configuration: Network-ready with I/O functionality for accessories like external triggers and auxiliary lighting.
- Plug and Play: DataMax Plus configuration tool enables rapid setup with an autotune function for optimizing scanning parameters.
Specifications:
- Mechanical:
- Dimensions (H x W x D): 70 mm x 55 mm x 45 mm
- Weight: 180g
- Lens: Liquid Lens
- Electrical:
- Input Voltage: 240V
- Output Current: 24VDC/5A
- Communication: RS232, RS485, TCP/IP, Field Bus Protocol (Profinet, EthernetIP, Modbus TCP)
- Environmental:
- Operating Temperature: 0°C to 50°C
- Storage Temperature: -20°C to 70°C
- Humidity: 5% to 95% relative humidity, non-condensing
- IP Rating: IP65
- Scan Performance:
- Scan Pattern: Area image
- HF811 Resolution: 2 MP
- HF810 Resolution: 0.5 MP
- Scan Angle: Horizontal: 20-39° (Narrow vs. Wide FOV), Vertical: 11-22° (Narrow vs. Wide FOV)
- Decode Capability: Reads standard 1D, PDF, 2D (QR, Datamatrix, Maxicode, Aztec) DPM
- Warranty: 3-year factory warranty
Recommended Accessories
Category
- Cables, Connectors, and Adapters (11)
- Spare Parts (1)
Recommended Accessories for Model: Honeywell HF81X Barcode Scanner
Top Cables, Connectors, and Adapters Purchased With Honeywell HF81X
-
Honeywell HF8TCB-ETHER-005 Cables, Connectors, and AdaptersCables, Connectors, and Adapters, Honeywell, HF81X Ethernet Cable, M12 Connector, 5 meters$77.54 -
Honeywell HF8TCB-SERIAL-005 Cables, Connectors, and AdaptersCables, Connectors, and Adapters, Honeywell, HF81X Serial Cable, M12/DB9 connectors, 5 meters$149.55
-
Honeywell HF8TCB-ETHER-002 Cables, Connectors, and AdaptersCables, Connectors, and Adapters, Honeywell, HF81X Ethernet Cable, M12 Connector, 2 meters$46.54
Top Spare Parts Purchased With Honeywell HF81X
-
Honeywell HF8OPT-PRF-00 Spare PartsSpare Parts, Honeywell, FM Optical, Polarizer, Compatible with HF810, CNPlease Call for Pricing or to Purchase
