FEIG LR1002 RFID Reader
FEIG LR1002 -
The FEIG HF Long Range Reader ID ISC.LR1002 identifies transponders according to ISO 15693 and HF Gen 2 with an operating frequency of 13.56 MHz. The ID ISC.LR1002''s combination of performance and affordability sets the ID ISC.LR1002 apart from any other long range reader. The ID ISC.LR1002 is suitable to be used in fields of applications like retail, industry and logistics with a small and medium number of tags inside the reading area. The ID ISC.LR1002 reader is designed for applications where the output power of mid range reader is insufficient such as conveyor belts, sorting systems and production lines.
Full specifications (PDF)
Price Match Guarantee
Found a better price? We'll match it within 60 days of your purchase.
for Qty Discount
Add to Quote
Starting at:
$1,158.24
Get help from a Barcoding Expert!
FEIG LR1002 RFID Reader Options
-
FEIG 4128.001.00 RFID Reader
RFID Readers, FEIG LRU1002-FCC, Fixed UHF LR Reader, UHF RFID, Ideal for Logistic/SCM, Vehicle Access Control, Tolling Systems.. Feig products require a $300 minimum order value. Orders below this amount will not be processed.$1,158.24 -
FEIG 3758.000.00 RFID Reader
RFID Readers, FEIG LR1002-E, HF LR Reader, HF RFID, Ideal for Logistic/SCM, Vehicle Access Control. -
FEIG 3757.000.00 RFID Reader
RFID Readers, FEIG LR1002, LRM1002-E HF LR Reader Unit, HF RFID, Ideal for Logistic/SCM, Vehicle Access Control. -
FEIG 3758.000.01 RFID Reader
RFID Reader, FEIG LR1002-E, HF LR Reader, HF RFID, Ideal for Logistic/SCM, Vehicle Access Control.
FEIG LR1002 RFID Reader Model Overview
The HF Long Range Reader ID ISC.LR(M)1002-E is a powerful and versatile solution for various applications in retail, industry, and logistics. With an optimal cost-performance ratio, it efficiently identifies transponders using ISO 15693 and HF Gen 2 at an operating frequency of 13.56 MHz. Perfectly suited for environments with a small to medium number of tags, this reliable device excels in settings such as conveyor belts, sorting systems, and production lines. Its adjustable output power, along with multiple interfaces, ensures a seamless integration into existing systems, making it a valuable addition to your operations.
Key features:
Specifications:
Key features:
- Powerful reader for diverse applications
- Adjustable output power for enhanced performance
- International certifications ensure compliance and reliability
- Multiple interfaces including Ethernet, USB, and RS232
- 4 different reader modes for tailored operation
- Compact design suitable for various settings
Specifications:
- Dimensions (wxhxd): 160 mm x 120 mm x 35 mm (ID ISC.LRM1002-E), 255 mm x 135 mm x 65 mm (ID ISC.LR1002-E)
- Weight: approx. 350 g (ID ISC.LRM1002-E), approx. 1,100 g (ID ISC.LR1002-E)
- Housing: Aluminium, grey
- Protection class: IP54
- Power supply: 24 V DC +15%
- Power consumption: max. 16 VA
- Operating frequency: 13.56 MHz
- Transmitting power: 1 W to 5 W (adjustable)
- Antenna connector: 1x SMA connector (50 Ohm)
- Output: 1 Relay (24 V, 1 A), 1 Optocoupler (24 V DC)
- Interfaces: Ethernet (TCP/IP), RS232
- Supported transponders: ISO 18000-3 MODE 1 & 3
- Operating temperature range: -25°C to +55°C
- Storage temperature range: -25°C to +85°C
- Relative humidity: 5% to 80% (non-condensing)
- Standard conformity: EN 300 330, FCC 47 CFR Part 15, IC RSS-GEN, RSS-210
