Fargo 93692 ID Card Printer
Full specifications (PDF)
Fargo HDP5600 ID Card Printer Model Overview
The FARGO® HDP5600 High Definition Printer/Encoder combines precision with versatility, making it the ideal choice for organizations that require high-quality card printing. With a remarkable resolution of 600 dpi, the HDP5600 ensures sharper images and vibrant colors, enhancing your brand image. This dual-sided printer is modular and can be upgraded with lamination and encoding options to adapt to your needs. Enhanced with Wi-Fi® capabilities, it allows for seamless network printing in various environments, whether in retail chains or educational institutions, ensuring quick and efficient issuance of ID cards and smart cards.
Key Features
- High-Definition Printing: Achieves 600 dpi for crisp images and vibrant colors.
- Dual-Sided Printing/Encoding: Easily upgradeable for dual-sided applications.
- Modular Design: Expandable with additional lamination and encoding modules.
- Wi-Fi® Capable: Network printing capability allows for flexible card issuance.
- Durable Card Production: Produces long-lasting cards resistant to wear and tampering.
Specifications
- Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
- Resolution: 600 dpi (23.6 dots/mm) or 300 dpi (11.8 dots/mm)
- Print Speed:
- Up to 24 seconds per card (150 cards/hour, YMC with transfer)
- Up to 29 seconds per card (124 cards/hour, YMCK with transfer)
- Up to 40 seconds per card (90 cards/hour, YMCKK with transfer)
- Accepted Card Sizes: CR-80 (3.375" L x 2.125" W)
- Input/Output Capacity: 200 cards input capacity; 100 cards output capacity
- Software Drivers: Compatible with Windows 10/8/7/Vista/XP, Mac OS X, Linux
- Warranty: Three years, including one year of free loaner support (U.S. only)
Recommended Accessories
Category
- ID Card Printer Accessories (4)
- Miscellaneous (1)
- Plastic ID Card Printer Printhead (1)
Recommended Accessories for Model: Fargo 93692 ID Card Printer
Top ID Card Printer Accessories Purchased With Fargo 93692
-
Fargo MDP-03001 AccessoryPrinter Spare Parts, HID, Asy-Cover-Frt-W-Cables HDP5600Ships from vendor — chat for lead time$315.44 -
Fargo 089022 AccessoryPrinter Spare Parts, HID, Dual-Side Printing Module For HDP5000 And HDP5600 With Included 5125 Encoder Module PreinstalledShips from vendor — chat for lead time$1,820.69 -
Fargo PCA-00324 AccessoryPrinter Spare Parts, HID, Asy PCB Controller With Prog HDP5600 P3Ships from vendor — chat for lead time$1,641.44
Top Miscellaneous Purchased With Fargo 93692
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Top Plastic ID Card Printer Printhead Purchased With Fargo 93692
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Frequently Asked Questions
What printing resolution and color capabilities does the Fargo HDP5600 offer?
The Fargo HDP5600 features 600 dpi printing resolution for superior text and image quality, with support for up to 16.7 million colors and 256 shades per pixel. This high-resolution capability makes it ideal for producing detailed ID cards and multi-function smart cards that require crisp, professional output.
What smart card encoding options are available on this printer?
The HDP5600 supports multiple encoding standards including HID Prox (125 kHz), iCLASS, MIFARE/DESFire, and contact smart card encoders. We offer this model with Omnikey Cardman 5121 and 5125 smart card encoder options to meet diverse organizational security requirements.
What card sizes and types can the Fargo HDP5600 print on?
The printer accepts standard CR-80 cards (3.375˝L x 2.125˝W) and CR-79 adhesive back cards, with print area coverage of edge-to-edge on CR-80 cards. It supports PVC or polyester cards with polished PVC finish, and accepts card thicknesses ranging from .009˝ to .040˝ (9 mil to 40 mil).
What ribbon options are available for the HDP5600?
We offer multiple ribbon configurations including full-color YMCKO (250 prints), full-color with dual black panels YMCKOK (200 prints), monochrome options with 500-1000 print yields, and specialized options with fluorescing panels. The variety of ribbon choices allows customization for different card designs and production volumes.
What connectivity and software support does this printer provide?
The HDP5600 features USB 2.0 and Ethernet connectivity with an internal print server for flexible deployment. It includes FARGO Workbench diagnostic utility software and supports Windows XP, Vista, Server 2003 & 2008, Windows 7, and Linux operating systems.
Is the Fargo HDP5600 suitable for high-volume ID card production?
Yes, the HDP5600 is designed as an all-in-one solution ideal for government agencies, universities, corporations, and healthcare facilities that need to routinely produce large volumes of high-definition IDs. Its combination of 600 dpi resolution, multiple encoding capabilities, and various ribbon options makes it well-suited for organizations with demanding production requirements. Contact us today to discuss your volume needs and find the right configuration available from us.
