Fargo 93651 ID Card Printer
Full specifications (PDF)
Fargo HDP5600 ID Card Printer Model Overview
The FARGO® HDP5600 High Definition Printer/Encoder combines precision with versatility, making it the ideal choice for organizations that require high-quality card printing. With a remarkable resolution of 600 dpi, the HDP5600 ensures sharper images and vibrant colors, enhancing your brand image. This dual-sided printer is modular and can be upgraded with lamination and encoding options to adapt to your needs. Enhanced with Wi-Fi® capabilities, it allows for seamless network printing in various environments, whether in retail chains or educational institutions, ensuring quick and efficient issuance of ID cards and smart cards.
Key Features
- High-Definition Printing: Achieves 600 dpi for crisp images and vibrant colors.
- Dual-Sided Printing/Encoding: Easily upgradeable for dual-sided applications.
- Modular Design: Expandable with additional lamination and encoding modules.
- Wi-Fi® Capable: Network printing capability allows for flexible card issuance.
- Durable Card Production: Produces long-lasting cards resistant to wear and tampering.
Specifications
- Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
- Resolution: 600 dpi (23.6 dots/mm) or 300 dpi (11.8 dots/mm)
- Print Speed:
- Up to 24 seconds per card (150 cards/hour, YMC with transfer)
- Up to 29 seconds per card (124 cards/hour, YMCK with transfer)
- Up to 40 seconds per card (90 cards/hour, YMCKK with transfer)
- Accepted Card Sizes: CR-80 (3.375" L x 2.125" W)
- Input/Output Capacity: 200 cards input capacity; 100 cards output capacity
- Software Drivers: Compatible with Windows 10/8/7/Vista/XP, Mac OS X, Linux
- Warranty: Three years, including one year of free loaner support (U.S. only)
Recommended Accessories
Category
- ID Card Printer Accessories (4)
- Miscellaneous (1)
- Plastic ID Card Printer Printhead (1)
Recommended Accessories for Model: Fargo 93651 ID Card Printer
Top ID Card Printer Accessories Purchased With Fargo 93651
-
Fargo MDP-03001 AccessoryPrinter Spare Parts, HID, Asy-Cover-Frt-W-Cables HDP5600Ships from vendor — chat for lead time$315.44 -
Fargo 089022 AccessoryPrinter Spare Parts, HID, Dual-Side Printing Module For HDP5000 And HDP5600 With Included 5125 Encoder Module PreinstalledShips from vendor — chat for lead time$1,820.69 -
Fargo PCA-00324 AccessoryPrinter Spare Parts, HID, Asy PCB Controller With Prog HDP5600 P3Ships from vendor — chat for lead time$1,641.44
Top Miscellaneous Purchased With Fargo 93651
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Top Plastic ID Card Printer Printhead Purchased With Fargo 93651
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Frequently Asked Questions
What printing resolution does the Fargo HDP5600 offer?
The Fargo HDP5600 features a 600 dpi printing option for superior text and image quality. This high resolution capability ensures crisp, detailed output suitable for government IDs, university credentials, corporate badges, and healthcare facility cards.
What encoding options are included with the Fargo 93651 HDP5600?
The Fargo 93651 comes equipped with an ISO Magnetic Stripe Encoder, HID Prox encoder (125 kHz), and a Contact Smart Card Encoder (Omnikey Cardman 5125) for reading and writing to ISO7816 smart cards. This all-in-one encoding capability eliminates the need for separate equipment and streamlines multi-function card production.
What card sizes and thicknesses does the HDP5600 accept?
The HDP5600 accepts standard CR-80 cards (3.375˝L x 2.125˝W) and CR-79 adhesive back cards, with a supported thickness range of .009˝ to .040˝ (9 mil to 40 mil). The printer supports PVC or polyester cards with polished PVC finish for optimal print quality.
What connectivity options are available on the Fargo HDP5600?
The HDP5600 provides both USB 2.0 and Ethernet connectivity with an internal print server, allowing flexible integration into your existing network infrastructure. These dual interface options support both standalone and networked deployment scenarios.
What ribbon options are available for the HDP5600?
We offer multiple ribbon configurations including full-color YMCKO (250 prints), full-color with dual black panels YMCKOK (200 prints), monochrome options like KO and BO (500 prints each), and specialty options with fluorescing or resin colors. Print speeds vary from 7 seconds per card for black-only to 31 seconds for full-color dual black ribbon configurations.
Is the Fargo HDP5600 suitable for high-volume ID card production?
Yes, the HDP5600 is specifically designed as an all-in-one solution for organizations that need to routinely produce large volumes of high-definition IDs and multi-function smart cards. The combination of 600 dpi resolution, multiple encoding options, and flexible ribbon configurations makes it ideal for government agencies, universities, corporations, and healthcare facilities managing high-throughput card programs. Contact us today to discuss your volume requirements and find the right configuration for your needs.
