Fargo 93624 ID Card Printer
Full specifications (PDF)
Fargo HDP5600 ID Card Printer Model Overview
The FARGO® HDP5600 High Definition Printer/Encoder combines precision with versatility, making it the ideal choice for organizations that require high-quality card printing. With a remarkable resolution of 600 dpi, the HDP5600 ensures sharper images and vibrant colors, enhancing your brand image. This dual-sided printer is modular and can be upgraded with lamination and encoding options to adapt to your needs. Enhanced with Wi-Fi® capabilities, it allows for seamless network printing in various environments, whether in retail chains or educational institutions, ensuring quick and efficient issuance of ID cards and smart cards.
Key Features
- High-Definition Printing: Achieves 600 dpi for crisp images and vibrant colors.
- Dual-Sided Printing/Encoding: Easily upgradeable for dual-sided applications.
- Modular Design: Expandable with additional lamination and encoding modules.
- Wi-Fi® Capable: Network printing capability allows for flexible card issuance.
- Durable Card Production: Produces long-lasting cards resistant to wear and tampering.
Specifications
- Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
- Resolution: 600 dpi (23.6 dots/mm) or 300 dpi (11.8 dots/mm)
- Print Speed:
- Up to 24 seconds per card (150 cards/hour, YMC with transfer)
- Up to 29 seconds per card (124 cards/hour, YMCK with transfer)
- Up to 40 seconds per card (90 cards/hour, YMCKK with transfer)
- Accepted Card Sizes: CR-80 (3.375" L x 2.125" W)
- Input/Output Capacity: 200 cards input capacity; 100 cards output capacity
- Software Drivers: Compatible with Windows 10/8/7/Vista/XP, Mac OS X, Linux
- Warranty: Three years, including one year of free loaner support (U.S. only)
Recommended Accessories
Category
- ID Card Printer Accessories (4)
- Miscellaneous (1)
- Plastic ID Card Printer Printhead (1)
Recommended Accessories for Model: Fargo 93624 ID Card Printer
Top ID Card Printer Accessories Purchased With Fargo 93624
-
Fargo MDP-03001 AccessoryPrinter Spare Parts, HID, Asy-Cover-Frt-W-Cables HDP5600Ships from vendor — chat for lead time$315.44 -
Fargo 089022 AccessoryPrinter Spare Parts, HID, Dual-Side Printing Module For HDP5000 And HDP5600 With Included 5125 Encoder Module PreinstalledShips from vendor — chat for lead time$1,820.69 -
Fargo PCA-00324 AccessoryPrinter Spare Parts, HID, Asy PCB Controller With Prog HDP5600 P3Ships from vendor — chat for lead time$1,641.44
Top Miscellaneous Purchased With Fargo 93624
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Top Plastic ID Card Printer Printhead Purchased With Fargo 93624
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Frequently Asked Questions
What printing resolution does the Fargo HDP5600 offer?
The Fargo HDP5600 features 600 dpi printing resolution for superior text and image quality. This high-resolution capability is ideal for producing sharp, detailed ID cards and multi-function smart cards for government agencies, universities, corporations, and healthcare facilities.
What encoding options are available with the Fargo HDP5600?
The Fargo HDP5600 comes equipped with an ISO magnetic stripe encoder and contactless smart card encoding support including iCLASS and MIFARE/DESFire (via Omnikey Cardman 5121). This all-in-one solution enables you to produce cards with multiple security and identification features.
What card sizes and thicknesses does the HDP5600 support?
The HDP5600 accepts standard CR-80 cards (3.375˝L x 2.125˝W) and CR-79 adhesive back cards. It supports card thicknesses from .009˝ to .040˝ (9 mil to 40 mil), making it compatible with PVC or polyester cards with polished PVC finish.
What connectivity options does the Fargo HDP5600 provide?
The HDP5600 features both USB 2.0 and Ethernet connectivity with an internal print server. This dual-interface design allows flexible integration into your existing network infrastructure for seamless card production workflows.
What ribbon options are available for the HDP5600?
The HDP5600 supports multiple ribbon configurations including full-color YMCKO (250 prints), full-color with dual black panels YMCKOK (200 prints), monochrome options, and specialty ribbons with fluorescing or heat seal capabilities. You can select the ribbon type that best matches your production volume and card design requirements.
Is the Fargo HDP5600 suitable for high-volume ID card production?
Yes, the HDP5600 is designed as a cost-effective solution ideal for organizations that need to routinely produce large volumes of high-definition IDs and smart cards. Its efficient print speeds and multiple encoding capabilities make it well-suited for government agencies, universities, corporations, and healthcare facilities with substantial card production demands. Contact us today to discuss your specific volume requirements and find the right configuration for your organization.
