Fargo 93296 ID Card Printer
Full specifications (PDF)
Fargo HDP5600 ID Card Printer Model Overview
The FARGO® HDP5600 High Definition Printer/Encoder combines precision with versatility, making it the ideal choice for organizations that require high-quality card printing. With a remarkable resolution of 600 dpi, the HDP5600 ensures sharper images and vibrant colors, enhancing your brand image. This dual-sided printer is modular and can be upgraded with lamination and encoding options to adapt to your needs. Enhanced with Wi-Fi® capabilities, it allows for seamless network printing in various environments, whether in retail chains or educational institutions, ensuring quick and efficient issuance of ID cards and smart cards.
Key Features
- High-Definition Printing: Achieves 600 dpi for crisp images and vibrant colors.
- Dual-Sided Printing/Encoding: Easily upgradeable for dual-sided applications.
- Modular Design: Expandable with additional lamination and encoding modules.
- Wi-Fi® Capable: Network printing capability allows for flexible card issuance.
- Durable Card Production: Produces long-lasting cards resistant to wear and tampering.
Specifications
- Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
- Resolution: 600 dpi (23.6 dots/mm) or 300 dpi (11.8 dots/mm)
- Print Speed:
- Up to 24 seconds per card (150 cards/hour, YMC with transfer)
- Up to 29 seconds per card (124 cards/hour, YMCK with transfer)
- Up to 40 seconds per card (90 cards/hour, YMCKK with transfer)
- Accepted Card Sizes: CR-80 (3.375" L x 2.125" W)
- Input/Output Capacity: 200 cards input capacity; 100 cards output capacity
- Software Drivers: Compatible with Windows 10/8/7/Vista/XP, Mac OS X, Linux
- Warranty: Three years, including one year of free loaner support (U.S. only)
Recommended Accessories
Category
- ID Card Printer Accessories (4)
- Miscellaneous (1)
- Plastic ID Card Printer Printhead (1)
Recommended Accessories for Model: Fargo 93296 ID Card Printer
Top ID Card Printer Accessories Purchased With Fargo 93296
-
Fargo MDP-03001 AccessoryPrinter Spare Parts, HID, Asy-Cover-Frt-W-Cables HDP5600Ships from vendor — chat for lead time$315.44 -
Fargo 089022 AccessoryPrinter Spare Parts, HID, Dual-Side Printing Module For HDP5000 And HDP5600 With Included 5125 Encoder Module PreinstalledShips from vendor — chat for lead time$1,820.69 -
Fargo PCA-00324 AccessoryPrinter Spare Parts, HID, Asy PCB Controller With Prog HDP5600 P3Ships from vendor — chat for lead time$1,641.44
Top Miscellaneous Purchased With Fargo 93296
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Top Plastic ID Card Printer Printhead Purchased With Fargo 93296
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Frequently Asked Questions
What print resolution options are available on the Fargo HDP5600?
The Fargo HDP5600 offers two resolution options: 600 dpi (23.6 dots/mm) for superior text and image quality, or 300 dpi (11.8 dots/mm) as the base model. The 600 dpi option is ideal when you need high-definition output for detailed graphics, fine text, or security features on your ID cards.
What encoding capabilities does the Fargo HDP5600 support?
The HDP5600 includes an all-in-one encoder that supports ISO Magnetic Stripe encoding, iCLASS SE, iCLASS, MIFARE/DESFire, and HID Prox encoding via the Omnikey 5127 module. This makes it suitable for organizations requiring multi-function smart card and credential production.
How fast can the Fargo HDP5600 print ID cards?
Print speed varies by ribbon configuration and lamination options. Standard YMC color printing delivers up to 150 cards per hour (24 seconds per card), while dual-sided simultaneous lamination with YMCK produces approximately 102 cards per hour. Contact us today for detailed speed specifications based on your specific ribbon and lamination requirements.
What card sizes and thicknesses does the Fargo HDP5600 accept?
The HDP5600 accepts standard CR-80 cards (3.375" L x 2.125" W / 85.6 mm L x 54 mm W) with thicknesses ranging from 0.030" to 0.050" (0.762 mm to 1.27 mm). The input cartridge holds 100 cards, and the output hopper accommodates up to 200 cards.
Is the Fargo HDP5600 compatible with Mac and Linux systems?
Yes, the HDP5600 includes software drivers for Windows, Mac OS X (v10.6 through v10.10), and Linux. This cross-platform compatibility makes it flexible for diverse IT environments in government, education, healthcare, and corporate settings.
What is the warranty coverage for the Fargo HDP5600?
The Fargo HDP5600 includes a three-year printer warranty, demonstrating our confidence in its reliability for high-volume production environments. Visit barcodesinc.com or contact us today to discuss warranty options and extended coverage plans available from our team.
