Fargo 93256 ID Card Printer
Full specifications (PDF)
Fargo HDP5600 ID Card Printer Model Overview
The FARGO® HDP5600 High Definition Printer/Encoder combines precision with versatility, making it the ideal choice for organizations that require high-quality card printing. With a remarkable resolution of 600 dpi, the HDP5600 ensures sharper images and vibrant colors, enhancing your brand image. This dual-sided printer is modular and can be upgraded with lamination and encoding options to adapt to your needs. Enhanced with Wi-Fi® capabilities, it allows for seamless network printing in various environments, whether in retail chains or educational institutions, ensuring quick and efficient issuance of ID cards and smart cards.
Key Features
- High-Definition Printing: Achieves 600 dpi for crisp images and vibrant colors.
- Dual-Sided Printing/Encoding: Easily upgradeable for dual-sided applications.
- Modular Design: Expandable with additional lamination and encoding modules.
- Wi-Fi® Capable: Network printing capability allows for flexible card issuance.
- Durable Card Production: Produces long-lasting cards resistant to wear and tampering.
Specifications
- Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
- Resolution: 600 dpi (23.6 dots/mm) or 300 dpi (11.8 dots/mm)
- Print Speed:
- Up to 24 seconds per card (150 cards/hour, YMC with transfer)
- Up to 29 seconds per card (124 cards/hour, YMCK with transfer)
- Up to 40 seconds per card (90 cards/hour, YMCKK with transfer)
- Accepted Card Sizes: CR-80 (3.375" L x 2.125" W)
- Input/Output Capacity: 200 cards input capacity; 100 cards output capacity
- Software Drivers: Compatible with Windows 10/8/7/Vista/XP, Mac OS X, Linux
- Warranty: Three years, including one year of free loaner support (U.S. only)
Recommended Accessories
Category
- ID Card Printer Accessories (4)
- Miscellaneous (1)
- Plastic ID Card Printer Printhead (1)
Recommended Accessories for Model: Fargo 93256 ID Card Printer
Top ID Card Printer Accessories Purchased With Fargo 93256
-
Fargo MDP-03001 AccessoryPrinter Spare Parts, HID, Asy-Cover-Frt-W-Cables HDP5600Ships from vendor — chat for lead time$315.44 -
Fargo 089022 AccessoryPrinter Spare Parts, HID, Dual-Side Printing Module For HDP5000 And HDP5600 With Included 5125 Encoder Module PreinstalledShips from vendor — chat for lead time$1,820.69 -
Fargo PCA-00324 AccessoryPrinter Spare Parts, HID, Asy PCB Controller With Prog HDP5600 P3Ships from vendor — chat for lead time$1,641.44
Top Miscellaneous Purchased With Fargo 93256
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Top Plastic ID Card Printer Printhead Purchased With Fargo 93256
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Frequently Asked Questions
What printing resolution does the Fargo HDP5600 offer?
The Fargo HDP5600 ID Card Printer features a base model resolution of 300 dpi (11.8 dots/mm) with continuous tone capability, delivering up to 16.7 million colors with 256 shades per pixel. We also offer a high resolution 600 dpi printing option for superior text and image quality when you need enhanced detail and clarity.
What encoding options are available with the Fargo HDP5600?
The Fargo HDP5600 comes equipped with multiple encoding capabilities including ISO Magnetic Stripe Encoder, iCLASS SE, iCLASS, MIFARE/DESFire, and HID Prox Encoder (Omnikey 5127). This all-in-one solution supports both contact and contactless smart card encoding, making it ideal for multi-function card applications across government, universities, corporations, and healthcare facilities.
What print speeds can I expect from the Fargo HDP5600?
Print speeds vary based on ribbon configuration: 7 seconds per card for single-color resin black (K*), 12 seconds for black with overlay (KO*), 24 seconds for full-color YMCKO*, and 31 seconds for dual black panel YMCKOK* configurations. These speeds are measured from card drop to output hopper and do not include encoding time or PC processing time.
What card sizes and types does the Fargo HDP5600 support?
The Fargo HDP5600 accepts standard CR-80 cards (3.375˝L x 2.125˝W) and CR-79 adhesive back cards, with card thickness ranging from .009˝ to .040˝ (9 mil to 40 mil). The printer works with PVC or polyester cards with polished PVC finish, and monochrome resin is required for 100% polyester cards.
What connectivity options does the Fargo HDP5600 provide?
The Fargo HDP5600 offers both USB 2.0 and Ethernet connectivity with an internal print server, allowing flexible integration into your existing network infrastructure. This dual-interface design supports both direct connection to individual workstations and centralized networked deployment for high-volume production environments.
What ribbon options are available for the Fargo HDP5600?
We offer multiple ribbon configurations including full-color YMCKO* (250 prints), full-color YMCKOK* with dual black panels (200 prints), fluorescing options YMCFKO* and YMCFKOK*, single-color resin or dye-sublimation (500 prints), and specialty color ribbons in green, blue, red, white, silver, and gold (1000 prints each). The printer also supports rewrite technology that requires no ribbon for specific applications.
