Fargo 93251 ID Card Printer
Full specifications (PDF)
Fargo HDP5600 ID Card Printer Model Overview
The FARGO® HDP5600 High Definition Printer/Encoder combines precision with versatility, making it the ideal choice for organizations that require high-quality card printing. With a remarkable resolution of 600 dpi, the HDP5600 ensures sharper images and vibrant colors, enhancing your brand image. This dual-sided printer is modular and can be upgraded with lamination and encoding options to adapt to your needs. Enhanced with Wi-Fi® capabilities, it allows for seamless network printing in various environments, whether in retail chains or educational institutions, ensuring quick and efficient issuance of ID cards and smart cards.
Key Features
- High-Definition Printing: Achieves 600 dpi for crisp images and vibrant colors.
- Dual-Sided Printing/Encoding: Easily upgradeable for dual-sided applications.
- Modular Design: Expandable with additional lamination and encoding modules.
- Wi-Fi® Capable: Network printing capability allows for flexible card issuance.
- Durable Card Production: Produces long-lasting cards resistant to wear and tampering.
Specifications
- Print Method: HDP Dye-Sublimation / Resin Thermal Transfer
- Resolution: 600 dpi (23.6 dots/mm) or 300 dpi (11.8 dots/mm)
- Print Speed:
- Up to 24 seconds per card (150 cards/hour, YMC with transfer)
- Up to 29 seconds per card (124 cards/hour, YMCK with transfer)
- Up to 40 seconds per card (90 cards/hour, YMCKK with transfer)
- Accepted Card Sizes: CR-80 (3.375" L x 2.125" W)
- Input/Output Capacity: 200 cards input capacity; 100 cards output capacity
- Software Drivers: Compatible with Windows 10/8/7/Vista/XP, Mac OS X, Linux
- Warranty: Three years, including one year of free loaner support (U.S. only)
Recommended Accessories
Category
- ID Card Printer Accessories (4)
- Miscellaneous (1)
- Plastic ID Card Printer Printhead (1)
Recommended Accessories for Model: Fargo 93251 ID Card Printer
Top ID Card Printer Accessories Purchased With Fargo 93251
-
Fargo MDP-03001 AccessoryPrinter Spare Parts, HID, Asy-Cover-Frt-W-Cables HDP5600Ships from vendor — chat for lead time$315.44 -
Fargo 089022 AccessoryPrinter Spare Parts, HID, Dual-Side Printing Module For HDP5000 And HDP5600 With Included 5125 Encoder Module PreinstalledShips from vendor — chat for lead time$1,820.69 -
Fargo PCA-00324 AccessoryPrinter Spare Parts, HID, Asy PCB Controller With Prog HDP5600 P3Ships from vendor — chat for lead time$1,641.44
Top Miscellaneous Purchased With Fargo 93251
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Top Plastic ID Card Printer Printhead Purchased With Fargo 93251
-
Fargo 86091 PrintheadID Card Printer Printheads, HID, Thermal Printhead HDP5000, HDP5600, 300Dpi And HDPiiShips from vendor — chat for lead time$590.09
Frequently Asked Questions
What print resolution options are available on the Fargo HDP5600?
The Fargo HDP5600 offers two resolution options: 600 dpi (23.6 dots/mm) for superior image quality, or 300 dpi (11.8 dots/mm) as the base model. The 600 dpi option delivers exceptional text and image clarity, making it ideal for high-definition ID cards and multi-function smart cards. We offer both configurations to match your quality and budget requirements.
What encoding capabilities does the HDP5600 support?
The HDP5600 includes an ISO magnetic stripe encoder and smart card encoding for both contact and contactless cards, including HID Prox and the Omnikey Cardman 5125 encoder. This all-in-one solution allows you to produce multi-function smart cards without requiring separate encoding equipment. Contact us today to discuss your specific encoding needs.
How many cards per hour can the Fargo HDP5600 print?
Print speed depends on your ribbon configuration and lamination requirements. In batch mode, the HDP5600 can produce up to 150 cards per hour (YMC with transfer), 124 cards per hour (YMCK with transfer), or 90 cards per hour (YMCKK with transfer). With dual-sided simultaneous lamination, speeds range from 75 to 102 cards per hour depending on ribbon type. Visit barcodesinc.com to verify the exact speed for your configuration.
What card sizes and thicknesses does the HDP5600 accept?
The HDP5600 accepts standard CR-80 cards (3.375" L x 2.125" W / 85.6 mm L x 54 mm W) with thickness between 0.030" (30 mil) and 0.050" (50 mil). The input cartridge holds 100 cards and the output hopper accommodates 200 cards, making it suitable for high-volume production environments.
What operating systems are compatible with the HDP5600?
The HDP5600 supports Windows (XP through Server 2012 R2), Mac OS X (v10.6 through v10.10), and Linux. This broad compatibility ensures seamless integration with most enterprise IT environments. We can help you verify driver availability for your specific system—contact us today.
What lamination options are available for the HDP5600?
The HDP5600 offers optional card lamination modules for single-sided or dual-sided (simultaneous) lamination, allowing you to add durability and security to your ID cards. Lamination can be combined with various ribbon configurations to meet your production speed and protection requirements. We offer complete lamination solutions available from us.
