Elo E999454 Touchscreen

Part Number: E999454

Model: 1517L

Discontinued Need Assistance?

Price Match Guarantee - We'll match any authorized retailer's price i

Quantity:

Product Highlights

View All

Screen Size Class

15"

Viewable Screen Size

15"

Screen Mode

XGA-2

Screen Surface

Anti-glare

Product Description:

Elo 1517L 15" LCD Touchscreen Monitor - 4:3 - 25 ms - 15" Class - 5-wire Resistive - 1024 x 768 - XGA-2 - 16.2 Million Colors - 700:1 - 250 Nit - LED Backlight - USB - VGA - Black - RoHS, China RoHS, WEEE - 3 Year

Explore all Elo 1517L Touchscreens

Add to Quote

Overview

Full specifications (PDF)

Elo 1517L Touchscreen Model Overview

The 1517L 15-inch LED Desktop Touchmonitor from Elo Touch Solutions is a stylish and robust solution designed for high-traffic commercial environments. With its "built for touch" reliability, this monitor withstands continuous public use while offering sleek aesthetics and energy efficiency. Enhanced by LED technology for 60% energy savings, it delivers exceptional performance in retail, hospitality, and interactive digital signage applications. The monitor is available in various touch technologies to meet diverse user needs, ensuring an engaging and intuitive experience.

Key Features:

Sleek and thin design with built for touch reliability
60% Energy Savings using LED Technology
Integrated cable management for a tidy workspace
Available with Antiglare or Clear glass
Black or White color options
Mountable on desktop, wall, or VESA
3-Year Standard Warranty

Specifications:

Model: 1517L
Color: Black or White
Active Display Area: 11.97 x 8.98 inches
Monitor Dimensions (with stand): 14.1 x 7.8 x 12.5 inches
Panel Thickness: 1.7 inches
Diagonal Size: 15.0 inches
Native Resolution: 1024 x 768
Brightness: Up to 250 nits
Response Time: 16 msec
Viewing Angle: Horizontal +/-80° / Vertical +/-70°
Contrast Ratio: 700:1
Touch Interface: Serial (RS232) and USB
Warranty: 3 Years Standard

Elo E999454 Touchscreen Overview

The 1517L zero-bezel touchmonitor is built to withstand the rigors of continuous public use with a rugged, "built for touch" industrial design. It delivers style and performance with a wide variety of features for a higher level of functionality. It is well suited for public venues where point-of-sale (POS), point-of-information (POI), point-of-service, shelf-level and countertop interactive digital signage, loyalty systems, kiosk information systems are found.

The optional 3-track magnetic stripe reader (MSR), programmable to either HID or Keyboard Emulation, is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments. The 1517L features two leading zero-bezel touch touchscreen technologies for a smooth, easy-clean surface: AccuTouch five-wire resistive technology, the most widely used for retail applications and proven to survive splashing liquids, food and grease; iTouch pure-glass surface wave technology, for the ultimate in optical quality for dry retail and hospitality applications.

Detailed Specs

Full specifications (PDF)

Technical Information

Screen Size Class:

15"

Viewable Screen Size:

15"

Screen Mode:

XGA-2

Screen Surface:

Anti-glare

Response Time:

25 ms

Aspect Ratio:

4:3

Horizontal Viewing Angle:

160°

Vertical Viewing Angle:

140°

Mount Type:

Desk Mountable

Backlight Technology:

LED

Features:

Security Lock

Video

Maximum Resolution:

1024 x 768

Standard Refresh Rate:

75 Hz

Color Supported:

16.2 Million Colors

Contrast Ratio:

700:1

Brightness:

250 Nit

Touchscreen Information

Touchscreen:

Yes

Touchscreen Type:

5-wire Resistive

Interfaces/Ports

USB:

Yes

USB Standard:

USB 1.1

VGA:

Yes

Power Description

Input Voltage:

110 V AC
220 V AC

Operating Power Consumption:

10 W

Physical Characteristics

VESA Mount Compatible:

Yes

VESA Mount Standard:

75 x 75

Product Color:

Black

Height with Stand:

12.50"

Width with Stand:

14.10"

Depth with Stand:

6.80"

Weight with Stand (Approximate):

9 lb

Miscellaneous

Package Contents:

1517L Rev A Multifunction 15-inch Desktop Touchmonitor
Detachable touch cable
Video cable
Power Cable

Certifications & Standards:

IEC 60320 C6
C-Tick
Canada cUL
IC
China CCC
Europe CE
Japan VCCI
Korea KCC
e-Standby
Mexico CoC
Taiwan BSMI Mark
United States UL
FCC
International CB
IMERC

Environmentally Friendly:

Yes

Environmental Certification:

RoHS
China RoHS
WEEE

Warranty

Limited Warranty:

3 Year

Item Numbers

GTIN: 5711045585722, 7411493290022

EAN: 5711045585722, 7411493290022

UNSPSC: 43211903
